Marantz PM6002 - Page 27

P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
U-PRO C693 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
U-PRO C694 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
U-PRO C695 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
U-PRO D601 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
U-PRO D606 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
U-PRO D613 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
U-PRO D621 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
U-PRO D622 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
U-PRO D623 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
U-PRO D651 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO D652 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO D653 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO D654 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO D655 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO D656 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO D657 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO D675 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO IC52 90M-HC109460R 90M-HC109460R IC NJM2114M HVINJM2114M
U-PRO IC53 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
U-PRO IC54 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
U-PRO IC55 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
U-PRO IC61 90M-HS44CWT0R 90M-HS44CWT0R U-PRO TMP86FH12MG PM6002 CVITMP86FH12MG
U-PRO J101 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J102 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J103 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J107 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J108 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J109 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J111 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J112 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J113 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J114 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J117 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J118 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J119 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J120 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J121 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J123 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J125 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J126 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J127 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J128 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J201 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J203 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J204 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J205 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J206 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J207 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J209 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J210 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J211 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J212 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J213 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J218 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J220 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J221 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J223 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J224 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J225 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J226 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J227 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J301 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J302 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J304 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J305 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J307 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
U-PRO J308 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
33
