Marantz PM6002 - Page 29

P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
U-PRO R504 ns
p
ns
p
RES. 2.7K OHM 1/5W J CRD20TJ272T
U-PRO R505 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
U-PRO R506 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
U-PRO R507 ns
p
ns
p
RES. 2.7K OHM 1/5W J CRD20TJ272T
U-PRO R508 ns
p
ns
p
RES. 2.7K OHM 1/5W J CRD20TJ272T
U-PRO R509 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
U-PRO R510 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
U-PRO R511 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
U-PRO R512 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
U-PRO R513 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
U-PRO R514 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
U-PRO R515 ns
p
ns
p
RES. 1.2K OHM 1/5W J CRD20TJ122T
U-PRO R516 ns
p
ns
p
RES. 1.2K OHM 1/5W J CRD20TJ122T
U-PRO R517 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
U-PRO R518 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
U-PRO R519 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221T
U-PRO R520 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221T
U-PRO R530 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
U-PRO R531 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
U-PRO R541 ns
p
ns
p
RES. 2.7K OHM 1/5W J CRD20TJ272T
U-PRO R542 ns
p
ns
p
RES. 2.7K OHM 1/5W J CRD20TJ272T
U-PRO R543 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
U-PRO R544 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
U-PRO R545 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
U-PRO R546 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
U-PRO R601 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
U-PRO R602 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
U-PRO R603 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
U-PRO R604 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
U-PRO R605 ns
p
ns
p
RES. 2.2K OHM 1/5W J CRD20TJ222T
U-PRO R606 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
U-PRO R607 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
U-PRO R608 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
U-PRO R611 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
U-PRO R612 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
U-PRO R613 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
U-PRO R614 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
U-PRO R615 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
U-PRO R617 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
U-PRO R618 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100T
U-PRO R619 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
U-PRO R620 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100T
U-PRO R623 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
U-PRO R624 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
U-PRO R625 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
U-PRO R626 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
U-PRO R627 ns
p
ns
p
RES. 120 OHM 1/5W J CRD20TJ121T
U-PRO R628 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
U-PRO R635 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
U-PRO R636 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
U-PRO R637 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
U-PRO R648 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
U-PRO R649 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
U-PRO R650 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
U-PRO R651 ns
p
ns
p
RES. 470K OHM 1/5W J CRD20TJ474T
U-PRO R652 ns
p
ns
p
RES. 470K OHM 1/5W J CRD20TJ474T
U-PRO R653 ns
p
ns
p
RES. 470K OHM 1/5W J CRD20TJ474T
U-PRO R654 ns
p
ns
p
RES. 470K OHM 1/5W J CRD20TJ474T
U-PRO R655 ns
p
ns
p
RES. 470K OHM 1/5W J CRD20TJ474T
U-PRO R656 ns
p
ns
p
RES. 470K OHM 1/5W J CRD20TJ474T
U-PRO R657 ns
p
ns
p
RES. 470K OHM 1/5W J CRD20TJ474T
U-PRO R658 ns
p
ns
p
RES. 390 OHM 1/5W J CRD20TJ391T
U-PRO R659 ns
p
ns
p
RES. 390 OHM 1/5W J CRD20TJ391T
U-PRO R660 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
U-PRO R675 ns
p
ns
p
RES. 560 OHM 1/5W J CRD20TJ561T
U-PRO R681 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100T
U-PRO R683 ns
p
ns
p
RES. 2.2K OHM 1/5W J CRD20TJ222T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
35
