1. TECHNICAL SPECIFICATIONS
RMS Power output
(20 Hz – 20 kHz simultaneous drive of both channels)
....................................................... 45 W x 2 (8 Ω load)
....................................................... 60 W x 2 (4 Ω load)
Headphone rated output
(When speaker rated output set to 8 Ω load)
....................................................... 160mW (32 Ω load)
Total harmonic distortion
(1 kHz simultaneous drive of both channels, 8 Ω load)
........................................................................... 0.08 %
Output band width (8 Ω load, 0.08 %) ........ 10 Hz – 50 kHz
Frequency response (CD, 1 W, 8 Ω load)
.........................................10 Hz – 70 kHz +0 dB, -1 dB
Dumping factor (8 Ω load, 100 Hz – 10 kHz) ................ 100
Input sensitivity/Input impedance
PHONO (MM) .............................................2.2 mV/47 kΩ
CD, LINE, TUNER, AUX/DVD, RECORDER
............................................................200 mV/20 kΩ
Maximum allowable PHONO input level (1 kHz)
MM ...................................................................... 100 mV
RIAA deviation (20 Hz ~ 20 kHz) ........................ ±0.5 dB
S/N (IHF-A, 1 W, 8 Ω load)
PHONO (MM) .................................... 84 dB (5 mV input)
CD, LINE, TUNER, AUX/DVD, RECORDER
................................................ 87 dB (500 mV input)
Tone control
Bass (100 Hz) ...................................................... ±10 dB
Treble (10 kHz) .................................................... ±10 dB
Power requirement ...............................AC 230 V 50/60 Hz
Power consumption (EN60065)................................ 150 W
Standby power consumption ..................................... 0.4 W
Accessories
Remote controller (RC003PM) ...................................... 1
AAA batteries ................................................................ 2
Detachable AC power cable .......................................... 1
Dimensions (unit: mm)
