Marantz PM6007 Quick Start Guide

2
EN
FR
ES
There are six steps to the setup process.
Setup
Install batteries in the remote control unit
Connect the speakers to PM6007
Connect the CD player to PM6007
Plug the power cord into a power outlet
Turn on the power of PM6007 and then set the
speakers for audio output to SPEAKERS A
Begin CD playback
Install batteries
in the remote control unit
Batteries

Marantz PM6007 Specifications

General

Frequency Response	10 Hz - 70 kHz
Dimensions	440 x 105 x 370 mm
Weight	7.8 kg
Channels	2
Damping Factor	100
Signal to Noise Ratio High level	102 dB
DAC chip	AK4490
Total Harmonic Distortion (20Hz-20kHz, 45W/8Ω)	0.02%
Signal-to-Noise Ratio MM	83 dB
Input Impedance MM	47 kΩ
Power Consumption	155 W
Standby Power Consumption	0.3 W
Dimensions (W x H x D)	440 x 105 x 370 mm
Power Output	45 W
Total Harmonic Distortion	0.02%
Input Sensitivity	200mV
Integrated Amplifier Power Output	45W per channel (8Ω)
Input Sensitivity MM	2.5mV
Signal to Noise Ratio MM/MC	83 dB (MM)
Input Sensitivity High level	200mV
Digital Inputs	1 Coaxial
Phono Input	Yes (MM)
Power Output (8Ω, 20Hz-20kHz, 0.02% THD)	45 W
Signal-to-Noise Ratio MC	64dB
Input Impedance MC	100Ω
