Marantz PM6007 Quick Start Guide

3
Connect the speakers to PM6007
(R) (L)
w q w q
Connecting the speaker cables
q Peel o about 3/8 inch (10 mm) of
sheathing from the tip of the speaker
cable, then either twist the core wire
tightly or apply solder to it.
w Turn the speaker terminal
counterclockwise to loosen it.
e Insert the speaker cable’s core wire to
all the way into the speaker terminal.
r Turn the speaker terminal clockwise to
tighten it.

Marantz PM6007 Specifications

General

Frequency Response	10 Hz - 70 kHz
Dimensions	440 x 105 x 370 mm
Weight	7.8 kg
Channels	2
Damping Factor	100
Signal to Noise Ratio High level	102 dB
DAC chip	AK4490
Total Harmonic Distortion (20Hz-20kHz, 45W/8Ω)	0.02%
Signal-to-Noise Ratio MM	83 dB
Input Impedance MM	47 kΩ
Power Consumption	155 W
Standby Power Consumption	0.3 W
Dimensions (W x H x D)	440 x 105 x 370 mm
Power Output	45 W
Total Harmonic Distortion	0.02%
Input Sensitivity	200mV
Integrated Amplifier Power Output	45W per channel (8Ω)
Input Sensitivity MM	2.5mV
Signal to Noise Ratio MM/MC	83 dB (MM)
Input Sensitivity High level	200mV
Digital Inputs	1 Coaxial
Phono Input	Yes (MM)
Power Output (8Ω, 20Hz-20kHz, 0.02% THD)	45 W
Signal-to-Noise Ratio MC	64dB
Input Impedance MC	100Ω
