Marantz PM8200 - Page 14

20
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
P101-MAIN BOARD
CIRCUIT BOARD
P101-CAPACITORS
C301 4822 126 14166 FILM 330pF J 100V OF15331540
C302 4822 126 14166 FILM 330pF J 100V OF15331540
C303 9965 000 01581 ELECT 22
F M 25V OA22602520
C304 9965 000 01581 ELECT 22
F M 25V OA22602520
C305 4822 124 41535 ELECT 100
F M 25V OA10702520
C306 4822 124 41535 ELECT 100
F M 25V OA10702520
C307 4822 124 41534 ELECT 10
F M 25V OA10602520
C308 4822 124 41534 ELECT 10
F M 25V OA10602520
C317
4822 122 30043 CER. 0.01 F Z 50V DK18103310
C323
C325
9965 000 01344 FILM 100pF J 100V OF15101540
C338
C401 4822 121 10792 FILM 220pF J 100V OF15221540
C402 4822 121 10792 FILM 220pF J 100V OF15221540
C403 4822 124 80543 ELECT 10
F 35V OA10603540
C404 4822 124 80543 ELECT 10
F 35V OA10603540
C405 4822 124 90371 ELECT 470
F M 10V OA47701020
C406 4822 124 90371 ELECT 470
F M 10V OA47701020
C411 4822 121 70437 FILM 1000pF J 100V OF15102540
C412 4822 121 70437 FILM 1000pF J 100V OF15102540
C413 9965 000 02015 ELECT 22
F M 25V OA22602540
C414 9965 000 02015 ELECT 22
F M 25V OA22602540
C417 9965 000 09801 ELECT 47
F 25V OA47602540
C418 9965 000 09801 ELECT 47
F 25V OA47602540
C419 8220 200 62290 FILM 100pF J 100V OF15101550
C420 8220 200 62290 FILM 100pF J 100V OF15101550
C421 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C701 4822 124 80543 ELECT 10
F 35V OA10603540
C702 4822 124 80543 ELECT 10
F 35V OA10603540
C703 9965 000 09806 FILM 330pF J 100V OF15331550
C704 9965 000 09806 FILM 330pF J 100V OF15331550
C705 4822 124 41535 ELECT 100
F M 25V OA10702520
C706 4822 124 41535 ELECT 100
F M 25V OA10702520
C707
4822 124 90365 ELECT 220 F M 25V OA22702520
C710
C711 9965 000 09807 FILM 680pF
5% 100V OF55681570
C712 9965 000 09807 FILM 680pF
5% 100V OF55681570
C713 4822 124 41534 ELECT 10
F M 25V OA10602520
C714 4822 124 41534 ELECT 10
F M 25V OA10602520
C715
4822 124 90366 ELECT 220 F M 50V OA22705020
C718
C723 4822 124 12276 FILM 0.01
F J 100V OF15103540
C724 4822 124 12276 FILM 0.01
F J 100V OF15103540
C727 4822 124 22273 ELECT 0.47
F M 50V OA47405020
C728 4822 124 22273 ELECT 0.47
F M 50V OA47405020
C729 9965 000 09803 FILM 22pF J 630V OF55220560
C730 9965 000 09803 FILM 22pF J 630V OF55220560
C801 9965 000 09756 ELECT 15000 F 56V OB15905610
C802 9965 000 09756 ELECT 15000 F 56V OB15905610
C803 4822 124 12056 ELECT ELNA RA2 16X25 OA10805020
C804 4822 124 12056 ELECT ELNA RA2 16X25 OA10805020
C805 4822 124 22698 ELECT 47
F M 25V OA47602520
C806 4822 124 22698 ELECT 47
F M 25V OA47602520
C807 9965 000 09801 ELECT 47
F 25V OA47602540
C808 9965 000 09801 ELECT 47
F 25V OA47602540
C809 4822 124 90366 ELECT 220
F M 50V OA22705020
C810 4822 124 22698 ELECT 47
F M 50V OA47602520
C811 4822 124 41535 ELECT 100
F M 50V OA10702520
C812 4822 124 41534 ELECT 10
F M 50V OA10602520
C813 4822 124 41543 ELECT 1
F M 50V OA10505020
C814 4822 124 41543 ELECT 1
F M 50V OA10505020
C815 4822 124 90355 ELECT 100
F M 50V OA10705020
C901 9965 000 01344 FILM 100pF J 100V OF15101540
C902 9965 000 01344 FILM 100pF J 100V OF15101540
C911 4822 124 12276 FILM 0.01
F J 100V OF15103540
C912 4822 124 22698 ELECT 47
F M 25V OA47602520
C913 4822 124 22698 ELECT 47
F M 25V OA47602520
C915 4822 122 40617 CER. 0.1
F +80 -20% 50V DD38104010
C916 4822 124 22273 ELECT 0.47
F M 50V OA47405020
C917 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C918 4822 122 30043 CER. 0.01
F Z 50V DK18103310
P101-CAPACITORS(COMMON)
C
PLASTIC FILM CAPACITOR
5% 50V : C309-C312
C407-C410 C415 C416
C719-C722 C725 C726
P101-RESISTORS
R328 4822 052 10229 22 5% 1/6W GG05220160
R329 4822 052 10229 22 5% 1/6W GG05220160
R330 4822 052 10229 22 5% 1/6W GG05220160
R331 4822 111 31001 330
5% 1/6W GG05331160
R332 4822 111 31001 330
5% 1/6W GG05331160
R333 4822 052 10229 22 5% 1/6W GG05220160
R419 4822 111 31001 330
5% 1/6W GG05331160
R420 4822 111 31001 330
5% 1/6W GG05331160
R723
4822 053 10152 1.5k 5% 1W GA05152010
R726
R731
4822 052 10471 470 5% 1/6W GG05471160
R734
R739
4822 052 10151 150 5% 1/6W GG05151160
R742
R751 4822 100 20681 TRIM. 2.2k
RH0638CJ3R RA02220780
R752 4822 100 20681 TRIM. 2.2k
RH0638CJ3R RA02220780
R753
4822 052 10101 100 5% 1/6W GG05101160
R756
R757 4822 052 10102 1k
5% 1/6W GG05102160
R758 4822 052 10102 1k
5% 1/6W GG05102160
R759
4822 052 10479 47 5% 1/6W GG05470160
R762
R763
4822 052 10109 10 5% 1/6W GG05100160
R766
R767 4822 052 10221 220
5% 1/6W GG05221160
R768 4822 052 10221 220
5% 1/6W GG05221160
R769 4822 111 91402 FIXED 0.1 X2 3 W BZ10102010
R770 4822 111 91402 FIXED 0.1 X2 3 W BZ10102010
R771 4822 052 10102 1k
5% 1/6W GG05102160
R772 4822 052 10102 1k
5% 1/6W GG05102160
R773 4.7k
5% 1/6W GG05472160
R774 4.7k
5% 1/6W GG05472160
R777 4822 053 10109 10
5% 1W GA05100010
R778 4822 053 10109 10
5% 1W GA05100010
R785
4822 052 10109 10 5% 1/4W GG05100140
R788
R789 4822 116 60494 METAL 330
5% 2W NK05331020
R790 4822 116 60494 METAL 330
5% 2W NK05331020
R791 4822 050 21022 1k
5% 1/2W GG05102120
R792 4822 050 22262 2.2k
5% 1/4W GG05222140
R801 4822 050 21108 1
5% 1/2W GG05010120
R802 4822 050 21108 1
5% 1/2W GG05010120
R809 4822 052 10478 4.7
5% 1/6W GG05047160
R810 4822 052 10478 4.7
5% 1/6W GG05047160
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
