Marantz PMD580 - Page 58

80
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS.
NO.
VERS.
COLOR
QTY PART NO. PART NAME DESCRIPTION
P101 L152 1 00MFN31030030 BLM21PG600SN1D 2012 3A BLM21PG600SN1
P101 L650 1 00MTP93570010 PULSE TRANS. TLA-6T118LF-T TDK
P101 Q001 1 00MHC12252090 NJM2387DL2
P101 Q002 1 00MHC12252090 NJM2387DL2
P101 Q003 1 00MHC12252090 NJM2387DL2
P101 Q004 1 00MHC12252090 NJM2387DL2
P101 Q005 1 00D2622785905 SN74LV125APWRG4 +C
P101 Q009 1 00MHC10259990 AT24C16BN-SH-T
P101 Q010 1 00D2622515900 SN74LV04APW-EL2 +C
P101 Q015 1 00D2622517908 SN74LV08APW-EL2 +REF
P101 Q020 1 00MHC1048099F MT48LC32M16A2P-75
P101 Q021 1 00MHC1048099F MT48LC32M16A2P-75
P101 Q022 1 00MHJ09CSX02F JS28F128P30T85(FOR PMD580) JS28F128P30T85(FOR PMD580)
P101 Q024 1 00MHC10234210 BD45302G RESET 3.0V
P101 Q026 1 00D2622785905 SN74LV125APWRG4 +C
P101 Q029 1 00MHC10474050 TC74LCX14FT TC74LCX14FT
P101 Q036 1 00MHC011705K0 TC74LCX00FT(EL.K)
P101 Q037 1 00D2622514901 SN74LV138APW-EL2 +C
P101 Q038 1 00D2622514901 SN74LV138APW-EL2 +C
P101 Q039 1 00D2622641900 SN74LV541APW-EL2 +C
P101 Q040 1 00D2620945909 SN7438NS-R +C
P101 Q042 1 00MHC10003600
78Q2120C09A-64GCT (ETHERNET
TRANSCEIVER)
P101 Q043 1 00D2690083901 DTA114EKT96 +C DTA114YK (ROHM)
P101 Q105 1 00MHC10036770 RS5C372A-E2
P101 Q112 1 00D2622519906 SN74LV00APW-EL2 +C
P101 Q117 1 00MHC011705K0 TC74LCX00FT(EL.K)
P101 Q118 1 00MHC712300Z0 CMOS LOGIC IC 74HC123 (FLAT) CMOS LOGIC IC 74HC123 (FLAT)
P101 Q119 1 00MHC011705K0 TC74LCX00FT(EL.K)
P101 Q120 1 00MHC10244090 NJU3716AM-TE1
P101 Q121 1 00MHC10244090 NJU3716AM-TE1
P101 Q122 1 00MHC10488050 TC74LCX16244FT
P101 Q123 1 00MHC10197050 TC74LCX16245FT
P101 Q124 1 234810006503S TC74VCX32FT
P101 Q125 1 234810007506S TC74VCX08FT
P101 Q126 1 00MHX327121A0 2SC2712(G) PKG TE85L
P101 Q157 1 00MHC10258990 MAX3207E
P101 Q159 1 00MHC012505K0 TC7SZ32F(TE85L) TC7SZ32F(TE85L)
P101 Q160 1 00D2623415902 TC7SZU04F TC7SZU04F
P101 Q161 1 00D2623415902 TC7SZU04F TC7SZU04F
P101 Q300 1 00D2622785905 SN74LV125APWRG4 +C
P101 Q401 1 00D2690082902 DTC114EKT96 +C
P101 Q402 1 00D2623242900 SN74LV273APW-EL2 +REF
P101 Q403 1 00D2623242900 SN74LV273APW-EL2 +REF
P101 Q404 1 00D2622959906 SN74LV244APW +REF
P101 Q406 1 00MBA10012210 DTA114TU (ROHM)
P101 R003 1 00MNI05000110 0
Ω
±5% 1/10W 0
Ω
± 5% 1/10W
P101 R007 1 00MNI05047110 4.7
Ω
±5% 1/10W 4.7
Ω
± 5% 1/10W
