Marantz PMD580 - Page 59

81
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS.
NO.
VERS.
COLOR
QTY PART NO. PART NAME DESCRIPTION
P101 R008 1 00MNI05000110 0
Ω
±5% 1/10W 0
Ω
± 5% 1/10W
P101 R014 1 00MNI05000110 0
Ω
±5% 1/10W 0
Ω
± 5% 1/10W
P101 R256 1 00MNI05000110 0
Ω
±5% 1/10W 0
Ω
± 5% 1/10W
P101 R450 1 00MNI05000110 0
Ω
±5% 1/10W 0
Ω
± 5% 1/10W
P101 R451 1 00MNI05000110 0
Ω
±5% 1/10W 0
Ω
± 5% 1/10W
P101 RU01 1 00MRI05000180 0
Ω
±5% 1/8W
P101 RU07 1 00MNM11202020 GRT1060120210 12kW ±1% GRT1060120210 12K
Ω
±1%
P101 RU08 1 00MRI05000180 0
Ω
±5% 1/8W
P101 RU11 1 00MRI05000180 0
Ω
±5% 1/8W 0
Ω
± 5% 1/8W
P101 RU12 1 00MRI05000180 0
Ω
±5% 1/8W 0
Ω
± 5% 1/8W
P101 RU74 1 00MNI05000110 0
Ω
±5% 1/10W 0
Ω
± 5% 1/10W
P101 X001 1 00MJX14005100 XTAL 14.7456MHz (HC-49/U03C)
P101 X002 1 00MJX00002460 TFX-02(32.768kHz)
P101 X004 1 00MJX25003460 25.000MHz X'TAL (FCX-03)
P101 X103 1 00MJX12009350 12MHz(SMD-49)
5200 nsp
MOTHER PWB ASSY
5201 nsp
AUDIO IO PCB ASSY
P201 CA07 1 00MOA47602520 47µF M 25V RA-2 47 µF M 25V RA-2
P201 CA08 1 00MOA47602520 47µF M 25V RA-2 47 µF M 25V RA-2
P201 CA19 1 00MOA47602520 47µF M 25V RA-2 47 µF M 25V RA-2
P201 CA20 1 00MOA47602520 47µF M 25V RA-2 47 µF M 25V RA-2
P201 CA27 1 00MOA47602520 47µF M 25V RA-2 47 µF M 25V RA-2
P201 CA28 1 00MOA47602520 47µF M 25V RA-2 47 µF M 25V RA-2
P201 CA32 1 00MOA47602520 47µF M 25V RA-2
P201 CA33 1 00MOA47602520 47µF M 25V RA-2
P201 CA41 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA42 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA43 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA44 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA55 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA56 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA57 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA58 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA59 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA60 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA61 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA62 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA63 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA64 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA65 1 00MOA10702520 100µF M 25V RA-2 10 µF M 25V RA-2
P201 CA66 1 00MOA10702520 100µF M 25V RA-2 10 µF M 25V RA-2
P201 CA67 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA68 1 00MOA10602520 10µF M 25V RA-2 10 µF M 25V RA-2
P201 CA83 1 00MOA47602520 47µF M 25V RA-2 47 µF M 25V RA-2
P201 CA84 1 00MOA47602520 47µF M 25V RA-2 47 µF M 25V RA-2
P201 CA89 1 00MOA47602520 47µF M 25V RA-2 47 µF M 25V RA-2
P201 CA90 1 00MOA47602520 47µF M 25V RA-2 47 µF M 25V RA-2
