NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS.
NO.
VERS.
COLOR
QTY PART NO. PART NAME DESCRIPTION
P203 C510 1 00MOA47505020 4.7µF M 50V RA-2
P203 C512 1 00MOA47505020 4.7µF M 50V RA-2
P203 C514 1 00MOA47505020 4.7µF M 50V RA-2
P203 C516 1 00MOA47505020 4.7µF M 50V RA-2
P203 C521 1 00MOA10601620 10µF M 16V RA-2
P203 D500 1 00D3939631903 TLGU1002A(T02)
P203 J501 1 00MYJ07014130 7P FFC CONNECTOR FMN-BMTTN -TD 7P FFC CONNECTOR FMN-BMTTN -TD
P203 J502 1 00MYJ07019770 B7B-PH-SM4-TB (LF)(SN) B7B-PH-SM3-TB
P203 J503 1 00D2051243005 9P DSUB KIT
P203 L500 1 00MFC90020110 BLM18BD601SN1D BLM11B601
P203 L501 1 00MFC90020110 BLM18BD601SN1D BLM11B601
P203 L502 1 00MFC90020110 BLM18BD601SN1D BLM11B601
P203 L503 1 00MFC90020110 BLM18BD601SN1D BLM11B601
P203 Q500 1 00MHC10292060 UPD4721GS-GJG IC RS232C
P203 Q501 1 00D2622785905 SN74LV125APWRG4 +C
5204 nsp
ENCODER PCB ASSY
P204 J970 1 00MYJ06006450 S5B-PH-K-S (LF)(SN) S5B-PH-K-S
P204 S970 1 00MSR01030150 EC11B15242AE EC11B15242AE ENCODER
5205 nsp
STANDBY LED PCB ASSY
P205 D980 1 00MHI10127210 SML312BC4TT86
P205 W980 1 00MYB00183300 PHR2/JB20-02HG UL1571 AWG28 CONNECTIVE W
5300 nsp
POWER & HP/PARALLEL PWB ASSY
5301 nsp
POWER PCB ASSY
P301
C701 1 00MDF17224570 # ECQU2A224ML 0.22µF/250V #DE1E3KX152MB4BL01
P301 C702 1 00MDK17471527 DE0910 B 471K -KX 470PF 250V #DE0910 B 471K -KX 470PF 250V
P301
C703 1 00MDK17471527 DE0910 B 471K -KX 470PF 250V #DE0910 B 471K -KX 470PF 250V
P301
C704 1 00MEA12740090 ! 120µF 400V SIDE-TYPE
P301
C705 1 00MDK17681527 #DE1B3KX681KB5B
P301 C707 1 00MOA47602520 47µF M 25V RA-2
P301 C708 1 00MDK48474200 0.47µF 50V GRM42-6 F 474Z50PT 0.47µF 50V GRM42-6 F 474Z50PT
P301 C709 1 00MDK48474200 0.47µF 50V GRM42-6 F 474Z50PT 0.47µF 50V GRM42-6 F 474Z50PT
P301
C710 1 00MDK17471527 DE0910 B 471K -KX 470PF 250V DE0910 B 471K -KX 470PF 250V
P301 C712 1 00MOA47603520 47µF M 35V RA-2
P301 C715 1 00MEF56703526 RJH-35V561MI5#-S1
P301 C719 1 00MOA10701620 100µF M 16V RA-2
P301 C720 1 00MOA10605020 10µF M 50V RA-2
P301 C723 1 00MOA10701620 100µF M 16V RA-2
P301 C724 1 00MEF68703516 RJH-35V681MI6#-S1
P301 C728 1 00MEF68703516 RJH-35V681MI6#-S1
P301 C736 1 00MOA33602520 33µF M 25V RA-2
P301 C741 1 00MEF56703526 RJH-35V561MI5#-S1
P301 C743 1 00MOA10602520 10µF M 25V RA-2
P301 C744 1 00MEF56703526 RJH-35V561MI5#-S1
P301 C746 1 00MOA10602520 10µF M 25V RA-2
