88
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS.
NO.
VERS.
COLOR
QTY PART NO. PART NAME DESCRIPTION
P301 C747 1 00MOA10701620 100µF M 16V RA-2
P301
C755 1 00MDF17224570 # ECQU2A224ML 0.22µF/250V #DE1E3KX152MB4BL01
P301
D700 1 00MHD20031290 S1WB(A)60 30A 600V S1WB(A)60 30A 600V
P301
D701 1 00MHV00001290 ST03D-170 TRANKILLER ST03D-170 TRANKILLER
P301 D702 1 00MHE10010080 !FMB26L
P301 D703 1 00D2760560901 DAN202KT146 +C DAN202K ROHM
P301
D705 1 00D2623047008 PC123Y22 PC-123Y22 PHOTO CUPLER
P301 D706 /N1S 251010002108P ERZV09D270
P301 D709 1 00D2760559909 DAP202KT146 +C
P301 D710 1 00D2760683943 UDZS3.6B-TE17
P301 D711 1 00D2760560901 DAN202KT146 +C DAN202K ROHM
P301 D712 1 00D2760684900 RB051L-40TE25 +C
P301 D715 1 00D2760684900 RB051L-40TE25 +C
P301 D717 1 00D2760684900 RB051L-40TE25 +C
P301 D720 1 00MHW10036320 GP1S58V PHOTE INTERLUPTER
P301
F700 /F1S 1 00D2061035067 FUSE(2.5A)T(A)MINI
P301
F700 /N1S 1 00D2061089013 #FUSE (ET1.25A)
P301 F700 /U1S 1 00D2061039076 #FUSE 2.5A
P301
G700 1 00MHV00033020 #ERZV07D471 # ERZV07D471
P301
J701 1 00D2050581001 2P VH CON BASE (White) CONNECTOR 2P B3P-VH
P301 J702 1 00MYJ07019780 B8B-PH-SM4-TB (LF)(SN) B8B-PH-SM3-TB JST
P301 J703 1 00MYJ07019720 B2B-PH-SM4-TB (LF)(SN) B2B-PH-SM3-TB JST
P301 J704 1 00MYJ07014130 7P FFC CONNECTOR FMN-BMTTN -TD 7P FFC CONNECTOR FMN-BMTTN -TD
P301 J705 1 00MYL01010240 GND TERMINAL FOR PCB EARTH LUG
P301 J707 1 00MYL01010240 GND TERMINAL FOR PCB EARTH LUG
P301 J708 1 00D2020040909 FUSE CLIP(TAPE) FUSE CLIP
P301 J709 1 00D2020040909 FUSE CLIP(TAPE) FUSE CLIP
P301 J710 1 00MYP06010450 B5B-EH-TS (LF)(SN) 5P RADIAL TAPING B5B-EH 5P RADIAL TAPING
P301
L700 1 00MLC25060010 LF-4Z-E503H # LF-4Z-E503H
P301 L701 1 00MLU80333070 CDRH8D43-330NC CDRH8D43-330NC
P301 L702 1 00MLC11040190 100UH COM.MODE COIL 100UH COM.MODE COIL
P301 L703 1 00D2140195006 RELAY FTR-F1
P301 L704 1 00MLU80563010 CDRH127/LDNP-560MC
P301 L705 1 00MLU80683020 CDRH8D43-680NC
P301 L706 1 00MLU12103010 NL322522-100J NL322522-100K
P301 L707 1 00MLU80683020 CDRH8D43-680NC
P301 L708 1 00MLU12103010 NL322522-100J NL322522-100K
P301 Q700 1 00MHC10180020 MIP3E50MY
P301 Q701 1 00MHC33036590 TL431CZ PROG.VOLTAGE REFERENCE
P301 Q702 1 00D2690082902 DTC114EKT96 +C
P301 Q703 1 00MHC12252090 NJM2387DL2
P301 Q704 1 00D2623506905 BD9781HFP-TR
P301 Q705 1 00D2690082902 DTC114EKT96 +C
P301 Q706 1 00D2690082902 DTC114EKT96 +C
P301 Q707 1 00D2690082902 DTC114EKT96 +C
P301 Q708 1 00MHX341161C0 2SC4116GR
P301 Q709 1 00MHS43BSN01F UPD78F9222(DNC640)
P301 Q710 1 00D2690082902 DTC114EKT96 +C
P301 Q711 1 00D2690082902 DTC114EKT96 +C
P301 Q712 1 00D2622785905 SN74LV125APWRG4 +C
