89
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS.
NO.
VERS.
COLOR
QTY PART NO. PART NAME DESCRIPTION
P301 Q713 1 00D2690083901 DTA114EKT96 +C
P301 Q714 1 00D2690082902 DTC114EKT96 +C
P301 Q715 1 00MHC10226210 BA9741FS-E2 2CH DC/DC
P301 Q716 1 00MHX117971A0 2SA1797 2SA1797
P301 Q717 1 00MHX117971A0 2SA1797 2SA1797
P301 Q718 1 00MHX346721A0 2SC4672 Q 2SC4672 Q
P301 Q719 1 00D2680077901 ICP-N50T
P301 Q720 1 00D2690082902 DTC114EKT96 +C
P301 R700 1 00MRC05105012 1M
Ω
±5% 1W RCR60 L15 1M
Ω
±5% 1W RCR60 L15
P301 R703 1 00MRI05150140 15
Ω
±5% 1/4W 15
Ω
± 5% 1/4W
P301 R704 /F1S 00MNN05150610
P301 R704 /N1S 00MNN05561610
P301 R704 /U1S 00MNN05150610
P301 R711 1 00MRI05330120 33
Ω
±5% 1/2W 33
Ω
± 5% 1/2W
P301 R722 1 00MNI05000110 0
Ω
±5% 1/10W
P301 R723 1 00MNI05000110 0
Ω
±5% 1/10W
P301 R724 1 00MNN05000610 0
Ω
±5% 1/16W
P301 R726 1 00MNI05000110 0
Ω
±5% 1/10W
P301 R727 1 00MNI05000110 0
Ω
±5% 1/10W
P301 R831 1 00MFC90090010 ZBF503D-00(TA)-01 ZBF503D-00(TA)-01
P301 R993 /F1S 00MNI05000110 0
Ω
±5% 1/10W
P301 R993 /N1S 1 00MNI05561110 560
Ω
±5% 1/10W
P301 R993 /U1S 1 00MNI05000110 0
Ω
±5% 1/10W
P301 S700 1 00MSP01013820 SDKLA1-BP1 TV5 250V 5A 1SDKLA10200
P301 T700 1 00MTS12900110 #ER SW TRANS
P301 X700 1 00D3990796900 X'TAL(10MHZ/SMT) +REF
5302 nsp
HEAD PHONES PCB ASSY
P302 C801 1 00MOA47602520 47µF M 25V RA-2
P302 C802 1 00MOA47602520 47µF M 25V RA-2
P302 C803 1 00MEG47601650 47µF/ 16V 47µF 16V
P302 C804 1 00MEG47601650 47µF/ 16V 47µF 16V
P302 C809 1 00MOA22701620 220µF M 16V RA-2
P302 C810 1 00MOA22701620 220µF M 16V RA-2
P302 C813 1 00MDK96222300 2200PF (GR39)
P302 D801 1 00D2760560901 DAN202KT146 +C DAN202K ROHM
P302 D802 1 00D2760559909 DAP202KT146 +C DAP202K
P302 J800 1 00D2050863994 6P PH CON.BASE(L) +REF
P302 J801 1 00MYJ01080220 YKB21-5265 6.3mm STREO PHONE JACK
P302 L803 1 00MFN31010030 BLM18B102SN1D BLM11B102S 1608 EMIFILTER
P302 L804 1 00MFN31010030 BLM18B102SN1D BLM11B102S 1608 EMIFILTER
P302 L806 1 00D2350147909 E.FIL(BLM21PG221SN1)+2125
P302 L807 1 00D2350147909 E.FIL(BLM21PG221SN1)+2125
P302 L808 1 00MFN31010030 BLM18B102SN1D BLM11B102S 1608 EMIFILTER
P302 L810 1 00MFN31010030 BLM18B102SN1D BLM11B102S 1608 EMIFILTER
P302 L811 1 00MFN31010030 BLM18B102SN1D BLM11B102S 1608 EMIFILTER
P302 Q801 1 00MHC10045090 NJM4556AM-TE1
P302 Q802 1 00D2730414906 2SC3326(A/B) +C
P302 Q803 1 00D2730414906 2SC3326(A/B) +C
