NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS.
NO.
VERS.
COLOR
QTY PART NO. PART NAME DESCRIPTION
P302 Q804 1 00D2730414906 2SC3326(A/B) +C
P302 Q805 1 00D2730414906 2SC3326(A/B) +C
P302 R802 1 00MRM01031250 RK0971220 10K A (D-CUT REV) RK0971220 10K A (D-CUT REV)
5303 nsp
PARALLEL IO PCB ASSY
P303 C650 1 00MOA10701620 100µF M 16V RA-2
P303 C651 1 00MDK98104200 GRM39F104Z16 0.1UF MURATA
P303 C652 1 00MOA10701620 100µF M 16V RA-2
P303 D655 1 00D2760560901 DAN202KT146 +C DAN202K ROHM
P303 D656 1 00D2760560901 DAN202KT146 +C DAN202K ROHM
P303 D657 1 00D2760560901 DAN202KT146 +C DAN202K ROHM
P303 D658 1 00D2760560901 DAN202KT146 +C DAN202K ROHM
P303 D659 1 00D2760559909 DAP202KT146 +C DAP202K
P303 D660 1 00D2760559909 DAP202KT146 +C DAP202K
P303 D661 1 00D2760559909 DAP202KT146 +C DAP202K
P303 D662 1 00D2760559909 DAP202KT146 +C DAP202K
P303 J651 1 00MYJ90001550 YKF42-8524N
P303 J652 1 00MYJ07014200 14P FFC CONNECTOR FMN-BMTTN-TP
