Marantz PMD661 Service Manual

39 40
POS.
No.
QTY
VERS.
COLOR
PART No.
(FOR EUR)
PART No.
(D&M)
PART NAME DESCRIPTION
014G 4 407010008008P 407010008008P RUBBER LEG LEG
016G 1 445310043000P 445310043000P SHIELD BOTTOM SHIELD
024G 1 415510003009P 415510003009P BATTERY LID BATTERY LID
026G 1 544510104008P 544510104008P LABEL MEIHAN SIRIAL LABEL
027G 2 00M11AJ107110 00M11AJ107110 SHEET 5×10 t0.15 HIMERON 10×5 FOR BATT BOX
028G 1 00M17CS107010 00M17CS107010 HIMERON 15×7×0.15t HIMERON 15×7 FOR BATT WIRE
029G 2 451510063007P 451510063007P SPACER 10×5×1.5T
SPACER 10×5 1.5T FOR BOTTOM
CASE
900G 1 406310047007P 406310047007P REAR PANEL REAR PANEL
902G 3 512350002006P 512350002006P SCREW (2.9×8) FOR XLR JACK
903G 1 512350002006P 512350002006P SCREW (2.9×8) FOR XLR JACK(TOMO)
905G 2 00M149S056010 00M149S056010 BUFFER 10×5×1.0T
10×5×1.0T BUFFER FOR REAR
PANEL
Z209 1 179010002008P 179010002008P OLED ASSY(2.2INCH) OLED
020B 1 454510011005P 454510011005P OLED HOLDER OLED HOLDER
Z201 1 323010002003S 323010002003S SPEAKER 388239 SPEAKER UNIT
Z203 1 323010002003S 323010002003S SPEAKER 388239 SPEAKER UNIT
Z205 1 00MMS50090110 00MMS50090110 MIC KUB4223 MIC UNIT
Z207 1 00MMS50090110 00MMS50090110 MIC KUB4223 MIC UNIT
W001 1 606050055007S 606050055007S
SML2CD-36x50-BDx6_BL-
P0.5-S4_M_UL20861
FPC
W002
W003
2 612050162009P 612050162009P WIRE 2P SH-BARA L=60MM MIC WIRE
W004
W005
2 612050163002P 612050163002P WIRE 2P SH-BARA L=35MM SPEAKER WIRE
W006 1 612050164005P 612050164005P
WIRE 2P ZH-BARA
L=150MM,100MM
BATTERY-PCB WIRE
W007 1 nsp 602010014006P BATTERY WIRE L=30MM BATTERY WIRE
PWB
P100 1 99M17CS510000 99M17CS510000 ! MAIN PCB KIT(PMD661) ! MAIN PCB KIT(PMD661)
P200 1 99M17CS520000 99M17CS520000 ! SUB PCB KIT ! SUB PCB KIT
PACKING
001T 1 F1B nsp 541110208004P DFU JP DFU JP
001T 1 U1B nsp 541110207001P DFU (4LANGUAGES) DFU US, EU
001T 1 N1B 541110207001P 541110207001P DFU (4LANGUAGES) DFU US, EU
002T 1 541510209003P 541510209003P DFU (CD-ROM) DFU (CD-ROM)
001Z 1 00MAA90005163 00MAA90005163 !AC ADAPTER (5V 1.5A) ! AC ADAPTER (5V 1.5A)
002Z 1 F1B nsp 00MZC01001010 ! MAINS CORD F ! MAINS CORD F
002Z 1 U1B nsp 00MZC01002010 ! MAINS CORD U ! MAINS CORD U
002Z 1 N1B 00MZC01003010 00MZC01003010 ! MAINS CORD EU ! MAINS CORD EU
003Z 1 N1B 00MZC01004020 00MZC01004020
KP-624, LTCE-2F, 0.75mm
2
,
KS-15F, L=1M, BL
! MAINS CORD UK
012Z 1 00M20BS156010 00M20BS156010 STRAP STRAP
NOT STANDARD SPARE PARTS
001S 1 nsp 531210072009P PACKING CASE PACKING CASE
002S 2 nsp 533610044006P CUSHION CUSHION
014S 1 nsp 531210071006P MASTER CARTON MASTER CARTON

Marantz PMD661 Specifications

General

Recording Format	MP3, WAV
Storage Media	SD/SDHC card
Microphone Input	XLR/TRS combo jack
USB	USB 2.0
Microphone	Built-in stereo microphones
Battery Life	Approximately 4 hours with alkaline batteries
Weight	650 g (without batteries)
Sampling Rate	44.1 kHz, 48 kHz
Bit Rate	32kbps to 320kbps (MP3)
Inputs	2 x XLR microphone inputs, 1 x 1/8" (3.5mm) line input
Outputs	1 x 3.5 mm headphone
Power	4 x AA batteries or AC adapter
