Marantz PS3001 - Page 57

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
INPUT C485 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C486 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C487 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C488 ns
p
00MOA10701020 ELECT CAP. 100UF 10V ZF CCEA1AH101T
INPUT C489 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C490 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C491 ns
p
00MOA10701020 ELECT CAP. 100UF 10V ZF CCEA1AH101T
INPUT C493 ns
p
00MDK96474200 CER. CAP. 0.47UF 10V KC CCUS1A474KC
INPUT C494 ns
p
00MOA47701020 ELECT CAP. 470UF 10V CCEA1AH471T
INPUT C496 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C497 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C498 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C499 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C500 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C501 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C502 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C503 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT CN15
/
N1B ns
p
ns
p
CONN. 17P WAFER CARD CABLE CJP17GA115ZY
INPUT CN15
/
N1G ns
p
ns
p
CONN. 17P WAFER CARD CABLE CJP17GA115ZY
INPUT CN15
/
N1S ns
p
ns
p
CONN. 17P WAFER CARD CABLE CJP17GA115ZY
INPUT CN15
/
U1B ns
p
ns
p
CONN. 15P CARD CABLE CJP15GA115ZY
INPUT CN26 ns
p
ns
p
CONN. 7P WAFER CJP07GA117ZY
INPUT CN27 ns
p
ns
p
CONN. 27P WAFER FPC CJP27GA115ZY
INPUT CN29 90M-YP100230R 90M-YP100230R CONN. 2110-DR12-G KJP12GB142ZP
INPUT CN80 ns
p
ns
p
CONN. 15P WAFER FPC CJP15GA117ZY
INPUT CN83 ns
p
ns
p
CONN. 15P WAFER FPC CJP15GA117ZY
INPUT D301 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D302 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D303 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D304 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D305 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D306 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D309 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D310 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D311 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D401 ns
p
90M-HD201730R DIODE 1N4003 KVD1N4003ST
INPUT D402 ns
p
90M-HD201730R DIODE 1N4003 KVD1N4003ST
INPUT D403 ns
p
90M-HD201730R DIODE 1N4003 KVD1N4003ST
INPUT D405 ns
p
90M-HD201730R DIODE 1N4003 KVD1N4003ST
INPUT D406 ns
p
90M-HD201730R DIODE 1N4003 KVD1N4003ST
INPUT D411 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D412 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D413 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D414 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D415 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D416 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D417 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D418 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D419 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D420 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D421 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D422 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D423 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D424 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D425 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D426 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D427 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D428 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D451 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D452 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT IC11 90M-HC108920R 90M-HC108920R IC CS42428-CQ HVICS42428CQ
INPUT IC12 90M-HC700550R 90M-HC700550R IC TC74HCU04AFNG HVI74HCU04AFNG
INPUT IC13 00MHC10418030 00MHC10418030 IC LC89057W-VF4-E HVILC89057WVF4E
INPUT IC15 90M-HC108910R 90M-HC108910R IC 74VHC08 HVI74VHC08TTR
INPUT IC16 90M-HC108930R 90M-HC108930R IC 74LCX32 HVI74LCX32TTR
INPUT IC17 90M-HC108910R 90M-HC108910R IC 74VHC08 HVI74VHC08TTR
INPUT IC18 90M-HC108430R 90M-HC108430R IC TC74HC7007AFEL HVITC74HCT7007F
71
