NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
INPUT R499
/
N1B ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
INPUT R499
/
N1G ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
INPUT R499
/
N1S ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
INPUT R501 ns
p
00MNN05047610 CHIP RES. 4.7 OHM 1/10W J CRJ10DJ4R7T
INPUT R502 ns
p
00MNN05047610 CHIP RES. 4.7 OHM 1/10W J CRJ10DJ4R7T
INPUT R503 ns
p
00MNN05047610 CHIP RES. 4.7 OHM 1/10W J CRJ10DJ4R7T
INPUT R504 ns
p
00MNN05047610 CHIP RES. 4.7 OHM 1/10W J CRJ10DJ4R7T
INPUT R505 ns
p
00MNN05047610 CHIP RES. 4.7 OHM 1/10W J CRJ10DJ4R7T
INPUT R506 ns
p
00MNN05047610 CHIP RES. 4.7 OHM 1/10W J CRJ10DJ4R7T
INPUT R507 ns
p
00MNN05047610 CHIP RES. 4.7 OHM 1/10W J CRJ10DJ4R7T
INPUT R508 ns
p
00MNN05047610 CHIP RES. 4.7 OHM 1/10W J CRJ10DJ4R7T
INPUT R509 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
INPUT R510 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
INPUT R511 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
INPUT R512 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
INPUT R513 ns
p
00MNN05832610 CHIP RES. 82K OHM 1/10W J CRJ10DJ823T
INPUT R514 ns
p
00MNN05832610 CHIP RES. 82K OHM 1/10W J CRJ10DJ823T
INPUT R515 ns
p
00MNN05832610 CHIP RES. 82K OHM 1/10W J CRJ10DJ823T
INPUT R516 ns
p
00MNN05832610 CHIP RES. 82K OHM 1/10W J CRJ10DJ823T
INPUT R517 ns
p
00MNN05047610 CHIP RES. 4.7 OHM 1/10W J CRJ10DJ4R7T
INPUT R531 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
INPUT R532 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
INPUT R533 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
INPUT R534 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
INPUT R535 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
INPUT R536 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
INPUT R537 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
INPUT R538 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
INPUT R539 ns
p
00MNN05332610 CHIP RES. 3.3K OHM 1/10W J CRJ10DJ332T
INPUT R903 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
INPUT R907 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
INPUT X101 90M-JX001180R 90M-JX001180R X'TAL 12288MHZ HOX12288E320TF
INPUT XC11 90M-JX001190R 90M-JX001190R X'TAL 20MHZ HOX20000E220TF
MAIN PWB
(
CUP11928Z-1
)
MAIN BN20 ns
p
ns
p
CORD WIRE ASSY CWB3FB03280UP
MAIN BN81 ns
p
ns
p
CORD WIRE ASSY CWB1C902050EN
MAIN BN87 ns
p
ns
p
CORD WIRE ASSY CWB2B905650EN
MAIN BN90 F N ns
p
ns
p
CORD WIRE ASSY CWB4F232550PU
MAIN BN90
/
N1B ns
p
ns
p
CORD WIRE ASSY CWB4F232550PU
MAIN BN90
/
N1G ns
p
ns
p
CORD WIRE ASSY CWB4F232550PU
MAIN BN90
/
N1S ns
p
ns
p
CORD WIRE ASSY CWB4F232550PU
MAIN BN93 ns
p
ns
p
CORD WIRE ASSY CWB1C902250BM
MAIN BN98 90M-YJ002810R 90M-YJ002810R CONN. 8P HJP08GA130ZK
MAIN C120 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C501 ns
p
00MOA10603540 ELECT CAP. 10UF 35V CCEA1VH100T
MAIN C502 ns
p
00MOA10603540 ELECT CAP. 10UF 35V CCEA1VH100T
MAIN C503 ns
p
00MOA10603540 ELECT CAP. 10UF 35V CCEA1VH100T
MAIN C504 ns
p
00MOA10603540 ELECT CAP. 10UF 35V CCEA1VH100T
MAIN C505 ns
p
00MOA10603540 ELECT CAP. 10UF 35V CCEA1VH100T
MAIN C506 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C507 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C508 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C509 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C510 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C561 ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
MAIN C562 ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
MAIN C563 ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
MAIN C564 ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
MAIN C565 ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
MAIN C566 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C569 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C570 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C571 ns
p
ns
p
CER. CAP. 680PF 50V KB HCBS1H681KBT
MAIN C572 ns
p
ns
p
CER. CAP. 680PF 50V KB HCBS1H681KBT
MAIN C573 ns
p
ns
p
CER. CAP. 680PF 50V KB HCBS1H681KBT
MAIN C574 ns
p
ns
p
CER. CAP. 680PF 50V KB HCBS1H681KBT
MAIN C575 ns
p
ns
p
CER. CAP. 680PF 50V KB HCBS1H681KBT
