Marantz SA-15S1 - IC Data and Electrical Parts List

1-38
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PCB
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
PA16 R842 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
PA16 R851 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
PA16 R852 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
PA16 R853 ns
p
00MGD05272160 RES. 2.7K OHM +- 5% 1/6
W
PA16 R854 ns
p
00MGD05332160 RES. 3.3K OHM +- 5% 1/6
W
PA16 R855 ns
p
00MGD05272160 RES. 2.7K OHM +- 5% 1/6
W
PA16 R856 ns
p
00MGD05332160 RES. 3.3K OHM +- 5% 1/6
W
PA16 R857 ns
p
00MGD05332160 RES. 3.3K OHM +- 5% 1/6
W
PA16 R858 ns
p
00MGD05332160 RES. 3.3K OHM +- 5% 1/6
W
PA16 R961 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
PA16 R962 ns
p
00MGD05682160 RES. 6.8K OHM +-5% 1/6
W
PA16 R963 ns
p
00MGD05682160 RES. 6.8K OHM +-5% 1/6
W
PA16 R965 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
PA16 R966 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
PA16 R967 ns
p
00MGD05104160 RES. 100K OHM +- 5% 1/6
W
PA16 R971 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
PA16 R972 ns
p
00MGD05682160 RES. 6.8K OHM +-5% 1/6
W
PA16 R973 ns
p
00MGD05682160 RES. 6.8K OHM +-5% 1/6
W
PA16 R975 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
PA16 R976 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
PA16 R977 ns
p
00MGD05104160 RES. 100K OHM +- 5% 1/6
W
PA16 RF51 ns
p
00MGD05220160 RES. 22 OHM +- 5% 1/6
W
PA16 RF52 ns
p
00MGD05472160 RES. 4.7K OHM +- 5% 1/6
W
PA16 RF53 ns
p
00MGD05472160 RES. 4.7K OHM +- 5% 1/6
W
PA16 RF54 ns
p
00MGD05473160 RES. 47K OHM +- 5% 1/6
W
PA16 RF55 ns
p
00MGD05183160 RES. 18K OHM +- 5% 1/6
W
PA16 RF56 ns
p
00MGD05472160 RES. 4.7K OHM +- 5% 1/6
W
PA16 RF57 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
PA16 RF58 ns
p
00MGD05822160 RES. 8.2K OHM +- 5% 1/6
W
PA16 RN01 ns
p
00MGD05122160 RES. 1.2K OHM +- 5% 1/6
W
PA16 RN02 ns
p
00MGD05153160 RES. 15K OHM +- 5% 1/6
W
PA16 RN03 ns
p
00MGD05225160 RES. 2.2M OHM +- 5% 1/6
W
PA16 RN04 ns
p
00MGD05473160 RES. 47K OHM +- 5% 1/6
W
PA16 RN05 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
PA16 RN15 ns
p
00MGD05472160 RES. 4.7K OHM +- 5% 1/6
W
PA16 RN16 ns
p
00MGD05332160 RES. 3.3K OHM +- 5% 1/6
W
PA16 RN17 ns
p
00MGD05224160 RES. 220K OHM +- 5% 1/6
W
PA16 RN18 ns
p
00MGD05472160 RES. 4.7K OHM +-1% 1/6
W
PA16 RT01 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
PA16 RT02 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
PA16 RT03 ns
p
00MGD05750160 RES. 75 OHM +- 5% 1/6
W
PA16 RT04 ns
p
00MGD05220160 RES. 22 OHM +- 5% 1/6
W
PA16 RT05 ns
p
00MGD05122160 RES. 1.2K OHM +- 5% 1/6
W
PA16 RT06 ns
p
00MGD05104160 RES. 100K OHM +- 5% 1/6
W
PA16 SF51 00MSS02021150 00MSS02021150 SLIDE SW SLIDE SWITCH INT/EXT
PA16 SH01 00MSP01011990 00MSP01011990 PUSH SW !SDDLD1 POWER SWITCH TV-3
DAC
,
CLOCK
,
HP BUFFER PCB
(
00MWG24AK201-
)
PD16 C101 ns
p
00MDK96102300 CER. CAP. 1000 PF +- 10 % B 50V GR3
6
PD16 C102 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C103 ns
p
00MOA227016R0 ELECT. CAP. ROA-16V227M-T2 #5
(
LF
)
CERAFINE
PD16 C104 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C105 ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V227M-T2 #5
(
LF
)
SILMI
C
PD16 C106 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C107 ns
p
00MOA106025R0 ELECT. CAP. ROA-25V106M-T2 #5
(
LF
)
CERAFINE
PD16 C108 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C109 ns
p
00MOA107010R0 ELECT. CAP. ROA-10V107M-T2 #5
(
LF
)
CERAFINE
PD16 C110 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C121 ns
p
00MDD91100300 CER. CAP. 10 PF +- 0.5 PF CH 50V GR39
PD16 C122 ns
p
00MDD91100300 CER. CAP. 10 PF +- 0.5 PF CH 50V GR39
PD16 C124 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C125 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C126 ns
p
00MOA107025Z0 ELECT. CAP. 100UF 25V ARS
PD16 C127 ns
p
00MOA106035Z0 ELECT. CAP. ROS-35V106M-T2 #5
(
LF
)
SILMI
C
PD16 C128 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C151 ns
p
00MOA477016R0 ELECT. CAP. ROA-16V471M-S1 #5
(
LF
)
CERAFINE
PD16 C152 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C153 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
