Marantz SA-15S1 - Page 31

1-39
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PCB
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
PD16 C154 ns
p
00MOA477016R0 ELECT. CAP. ROA-16V471M-S1 #5
(
LF
)
CERAFINE
PD16 C155 ns
p
00MOA106025R0 ELECT. CAP. ROA-25V106M-T2 #5
(
LF
)
CERAFINE
PD16 C156 ns
p
00MOA107010R0 ELECT. CAP. ROA-10V107M-T2 #5
(
LF
)
CERAFINE
PD16 C162 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C163 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C164 ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PD16 C181 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C182 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C183 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C184 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF MURAT
A
PD16 C185 ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V227M-T2 #5
(
LF
)
SILMI
C
PD16 C902 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PD16 C921 ns
p
00MOA22701620 ELECT. CAP. 220 UF M 16V RA-2
PD16 C922 ns
p
00MOA22701620 ELECT. CAP. 220 UF M 16V RA-2
PD16 C932 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PD16 D154 00MHZ20028050 00MHZ20028050 CHIP DIODE 1SS301
PD16 D181 00MHZ20028050 00MHZ20028050 CHIP DIODE 1SS301
PD16 D901 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PD16 D931 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PD16 J105 00MYJ1000500
0
00MYJ1000500
0
JACK 10R-FJ
(
10P RECEPTACLE
)
PD16 J106 00MYJ1000500
0
00MYJ1000500
0
JACK 10R-FJ
(
10P RECEPTACLE
)
PD16 J107 00MYJ1000500
0
00MYJ1000500
0
JACK 10R-FJ
(
10P RECEPTACLE
)
PD16 L101 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PD16 L103 00MFC90020100 00MFC90020100 FERRITE CORE FB M J2125HM330-
T
PD16 L104 00MFC90020100 00MFC90020100 FERRITE CORE FB M J2125HM330-
T
PD16 L105 00MFC90020100 00MFC90020100 FERRITE CORE FB M J2125HM330-
T
PD16 Q101 00MHC10008880 00MHC10008880 IC CS4397 24/192 DAC CIRRUS LOGIC
PD16 Q121 00MHC010305K0 00MHC010305K0 IC TC7SHU04FU
PD16 Q122 00MHC010305K0 00MHC010305K0 IC TC7SHU04FU
PD16 Q123 00MHC005605K0 00MHC005605K0 IC TC74VHC74FS
PD16 Q151 00MHC98905090 00MHC98905090 IC NJM7805DLIA
(
TE1
)
PD16 Q152 00MHX111622A0 00MHX111622A0 CHIP TRS. 2SA1162 0,
Y
PD16 Q153 00MBA20019210 00MBA20019210 SEMICON.COMP DTC114TU
(
ROHM
)
PD16 Q154 00MBA20016050 00MBA20016050 SEMICON.COMP HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PD16 Q161 00MHC98403980 00MHC98403980 IC XC6203P332PR 3.3V 0.4A REG.
PD16 Q901 00MHX115862A0 00MHX115862A0 CHIP TRS. 2SA1586
(
O,Y
)
PD16 Q902 00MHX341162B0 00MHX341162B0 CHIP TRS. 2SC4116
(
TOSHIBA
)
PD16 Q903 00MHX341162B0 00MHX341162B0 CHIP TRS. 2SC4116
(
TOSHIBA
)
PD16 Q904 00MHX115862A0 00MHX115862A0 CHIP TRS. 2SA1586
(
O,Y
)
PD16 Q905 00MHX115862A0 00MHX115862A0 CHIP TRS. 2SA1586
(
O,Y
)
PD16 Q906 00MHX341162B0 00MHX341162B0 CHIP TRS. 2SC4116
(
TOSHIBA
)
PD16 Q907 00MHX341162B0 00MHX341162B0 CHIP TRS. 2SC4116
(
TOSHIBA
)
PD16 Q908 00MHX115862A0 00MHX115862A0 CHIP TRS. 2SA1586
(
O,Y
)
PD16 Q931 00MHX115862A0 00MHX115862A0 CHIP TRS. 2SA1586
(
O,Y
)
PD16 Q932 00MHX341162B0 00MHX341162B0 CHIP TRS. 2SC4116
(
TOSHIBA
)
PD16 Q933 00MHX341162B0 00MHX341162B0 CHIP TRS. 2SC4116
(
TOSHIBA
)
PD16 Q934 00MHX115862A0 00MHX115862A0 CHIP TRS. 2SA1586
(
O,Y
)
PD16 Q935 00MHX115862A0 00MHX115862A0 CHIP TRS. 2SA1586
(
O,Y
)
PD16 Q936 00MHX341162B0 00MHX341162B0 CHIP TRS. 2SC4116
(
TOSHIBA
)
PD16 Q937 00MHX341162B0 00MHX341162B0 CHIP TRS. 2SC4116
(
TOSHIBA
)
PD16 Q938 00MHX115862A0 00MHX115862A0 CHIP TRS. 2SA1586
(
O,Y
)
PD16 R101 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PD16 R102 ns
p
00MNN05223610 CHIP RES. 22K OHM +- 5% 1/16
W
PD16 R103 ns
p
00MNN05223610 CHIP RES. 22K OHM +- 5% 1/16
W
PD16 R121 ns
p
00MNN05154610 CHIP RES. 150K OHM +- 5% 1/16
W
PD16 R122 ns
p
00MNN05821610 CHIP RES. 820 OHM +- 5% 1/16
W
PD16 R123 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
PD16 R124 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PD16 R125 ns
p
00MNN05100610 CHIP RES. 10 OHM +- 5% 1/16
W
PD16 R151 00MNI05472110 00MNI05472110 CHIP RES. 4.7K OHM +- 5% 1/10
W
PD16 R152 00MNI05122110 00MNI05122110 CHIP RES. 1.2K OHM +- 5% 1/10
W
PD16 R153 00MNI05152110 00MNI05152110 CHIP RES. 1.5K OHM +- 5% 1/10
W
PD16 R154 00MNI05392110 00MNI05392110 CHIP RES. 3.9K OHM +- 5% 1/10
W
PD16 R155 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
PD16 R181 ns
p
00MNN05223610 CHIP RES. 22K OHM +- 5% 1/16
W
PD16 R182 ns
p
00MNN05223610 CHIP RES. 22K OHM +- 5% 1/16
W
PD16 R183 ns
p
00MNN05223610 CHIP RES. 22K OHM +- 5% 1/16
W
