10. MECHA LOADER ASS'Y
NO
VERS.
COLOR
PART NO. DESCRIPTION
1 nsp CHASSIS-MAIN 62-210-1015
2 01AK054010 CAM SLIDER 62-239-2017
3 01AK058010 GEAR LOAD A 62-222-4003
4 01AK058020 PULLEY GEAR 62-223-4004
5 01AK058030 GEAR LOAD TRY 62-222-3005
6 01AK058040 GEAR B 62-222-4006
7 KM01AK13J3 ASS'Y MOTOR 62-093-4023
8 01AK401010 CHASSIS SUB 62-211-2007
9 01AK163010 TRAY 62-218-1016
10 nsp
11 01AK004010 CLAMPER-2 62-223-3041
12 nsp
13 nsp YOKE 56-119-4030
14 nsp PWB 62-070-3018
15 nsp CONNECTOR 6FESTVKN
16 *SM000380R LEVER SWITCH F501-0012
17 nsp
18 nsp
19 nsp SCREW GSP14A25027
20 nsp
21 nsp SCREW 03-300-4525
22 nsp
23 nsp
24 01AK264010 BELT LOADING 02-084228
25 nsp WASHER GWP52X100025
26 nsp
27 nsp
28 nsp
29 nsp
30 nsp
31 nsp
2
5
3
21
6
4
11
13
9
HOOK TO NO. 4
24
16
7
14
15
1
8
25
19
