NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
1-35
PWB
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PY16 CY08 ns
p
00D257051290
3
CER. CAP. CK73F1E104ZT +1608
PY16 CY09 ns
p
00D257051290
3
CER. CAP. CK73F1E104ZT +1608
PY16 DY02 263010001009
0
263010001009
0
L.E.D. LT3D8B RED LED
PY16 DY07 202050001507S 202050001507S ZENER DIODE 02CZ3.9-X
(
TE85L
)
PY16 LY01 119010001409
0
119010001409
0
COIL BL02RN2R1N1A FERRITE BEAD
PY16 LY02 119010001409
0
119010001409
0
COIL BL02RN2R1N1A FERRITE BEAD
PY16 LY03 119010001409
0
119010001409
0
COIL BL02RN2R1N1A FERRITE BEAD
PY16 LY04 119010001409
0
119010001409
0
COIL BL02RN2R1N1A FERRITE BEAD
PY16 QY01 239010002009S 239010002009S IC ML9207-01GP
PY16 QY02 214050003506S 214050003506S TRS. 2SC4081
(
Q_R
)(
312000451210
)
PY16 QY05 212050002507S 212050002507S TRS. 2SA1586
(
Y_GR
)
TE85
L
PY16 RY01 ns
p
00D2472006915 CHIP RES. RM73B--271JT +1608
PY16 RY02 ns
p
00D2472006915 CHIP RES. RM73B--271JT +1608
PY16 RY03 ns
p
00D247200694
4
CHIP RES. RM73B--391JT +1608
PY16 RY04 ns
p
00D2472005961 CHIP RES. RM73B--181JT +1608
PY16 RY05 ns
p
00D2472005961 CHIP RES. RM73B--181JT +1608
PY16 RY06 ns
p
00D2472005945 CHIP RES. RM73B--151JT +1608
PY16 RY09 ns
p
00D247200694
4
CHIP RES. RM73B--391JT +1608
PY16 RY10 ns
p
00D2472005945 CHIP RES. RM73B--151JT +1608
PY16 RY13 ns
p
00D247200794
3
CHIP RES. RM73B--102JT +1608
PY16 RY14 ns
p
00D247200998
3
CHIP RES. RM73B--103JT +1608
PY16 RY15 ns
p
00D2472008968 CHIP RES. RM73B--332JT +1608
PY16 RY18 ns
p
00D2472006960 CHIP RES. RM73B--471JT +1608
PY16 RY19 ns
p
00D247200794
3
CHIP RES. RM73B--102JT +1608
PY16 RY20 ns
p
00D247200794
3
CHIP RES. RM73B--102JT +1608
PY16 RY22 ns
p
00D247200590
3
CHIP RES. RM73B--101JT +1608
PY16 RY23 ns
p
00D247200794
3
CHIP RES. RM73B--102JT +1608
PY16 RY24 ns
p
00D2472007901 CHIP RES. RM73B--681JT +1608
PY16 RY25 ns
p
00D247201296
7
CHIP RES. RM73B--154JT +1608
PY16 RY26 ns
p
00D247200998
3
CHIP RES. RM73B--103JT +1608
PY16 RY41 ns
p
00D247200590
3
CHIP RES. RM73B--101JT +1608
PY16 SY01 662010001408S 662010001408S SW SKHVBF F0052759M
PY16 SY02 662010001408S 662010001408S SW SKHVBF F0052759M
PY16 SY03 662010001408S 662010001408S SW SKHVBF F0052759M
PY16 SY04 662010001408S 662010001408S SW SKHVBF F0052759M
PY16 SY05 662010001408S 662010001408S SW SKHVBF F0052759M
PY16 SY06 662010001408S 662010001408S SW SKHVBF F0052759M
PY16 SY07 662010001408S 662010001408S SW SKHVBF F0052759M
PY16 SY10 662010001408S 662010001408S SW SKHVBF F0052759M
PY16 VX01 172010001004M 172010001004M DISPLAY CH2163C
PY16 XY01 142010002402S 142010002402S FILTER CSTLF4M00G55-A0
PY16 ZY01 262010001006
0
262010001006
0
PHOTO UNIT RPM6936-V4
(
IR SENSOR
)
