Marantz SA7001KI - SECTION 2 MECHA LOADER AND MECHA TRAVERSE; 1. EXPLODED VIEW AND PARTS LIST

1. EXPLODED VIEW AND PARTS LIST
PWB
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
1ns
p
ns
p
CHASSIS MAIN CHASSIS ASSY 9KC 1A01 7
2 90M13AK160210 90M13AK160210 BRAKET CLAMPER BRACKET 9KA 7P08 5
3ns
p
ns
p
BRAKET GUIDE CLAMP BRACKET
4 90M-MM001290R 90M-MM001290R MOTOR LOADING MOTOR ASSY 9KC 2A00 3
5 90M13AK058230 90M13AK058230 GEAR LOADING GEAR 9KC 2G02 9
6 90M13AK058210 90M13AK058210 GEAR LOADING GEAR 2ND 9KB 9G03 0
7 90M13AK058220 90M13AK058220 GEAR LOADING GEAR 3RD 9KB 9G03 1
8 90M13AK105210 90M13AK105210 CHASSIS SUB CHASSIS-L 9KA 2G41 7
9 90M13AK105220 90M13AK105220 CHASSIS SUB CHASSIS-R 9KA 2G41 8
10 90M13AK163210 90M13AK163210 TRAY TRAY-D4 9KA 2G778
11 90M13AK054210 90M13AK054210 CAM SLIDE-CAM 9KC 1G00 3
12 90M13AK002210 90M13AK002210 ARM TRAVERSE ARM 9KC 1G00 4
14 90M13AK005210 90M13AK005210 CLAMPER CLAMPER H 9KA 7G20 2
15 90M13AK005220 90M13AK005220 CLAMPER CLAMPER L 9KA 7G20 3
16 90M13AK264210 90M13AK264210 BELT LOADING BELT 9KB 9G01 5
17
nsp nsp
PWB ASSY SWITCH P.W.B. 9KC 1P01 4
18
nsp nsp
CORD 5P PH WIRE 9KC 2G04 3
19 90M-SP001260R 90M-SP001260R SWITCH SWITCH ESE22MH21 9KS 01W2 04
20 90M-SP001270R 90M-SP001270R SWITCH SWITCH ESE22MH23 9KS 01W2 05
21 90M13AK012210 90M13AK012210 WASHER POLY.SLIT WASHER 2.6X6X0.25C 9KP 26C6 25
22
nsp nsp
CLAMPER WIRE CLAMPER 445 8004 00
7
23
nsp nsp
SCREW PRECISION SCREW 1.7X2.2 TYPE3 9KS 17N0 22
24
nsp nsp
SCREW SCREW 2.6X6 CBTS
(
B
)
-Z 9KB 26BK 06
25
nsp nsp
SCREW PRECISION SCREW 2X3
(
S
)
TYPE3 9KS 20TK 33
26
nsp nsp
SCREW SCREW 2X6 CBTS
(
P
)
-Z 9KB 20PK 06
27A 90M13AK304210 90M13AK304210 MECHANISM TRAVERSE MECHA
(
FEED
)
ASSY 9KC 2A06 3
A
27
nsp nsp
CHASSIS PU CHASSIS ASSY
28
nsp nsp
HOLDER SHAFT HOLDER L
29
nsp nsp
HOLDER SHAFT HOLDER R
30
nsp nsp
BRAKET SHAFT TILT BASE
31
nsp nsp
RETAINER SHAFT TILT PLATE
32
nsp nsp
SPRING TILT SPRING
33
nsp nsp
SHAFT MAIN SHAFT
34
nsp nsp
SHAFT SUB SHAFT
35
nsp nsp
GEAR PU RACK GEAR
36 nsp nsp GEAR FEED GEAR 2ND ASSY
37
nsp nsp
MECHANISM PICK UP HOP-1200R
38
nsp nsp
SPRING PU SPRING
39
nsp nsp
SPRING SHAFT SPRING
40
nsp nsp
SPRING RACK GEAR SPRING
41 nsp nsp MOTOR FEED MOTOR ASSY
42
nsp nsp
MOTOR T/T MOTOR ASSY
43
nsp nsp
SCREW SCREW 2.6X6 CBTS
(
S
)
-Z
44
nsp nsp
SCREW SCREW 2.6X4 CBTS
(
S
)
-Z
46
nsp nsp
SCREW SCREW 2.6X15 CFTS
(
S
)
-Z
47
nsp nsp
SCREW SCREW 3X4 BSS
48
nsp nsp
SCREW SCREW 3X8 BSS
(
A
)
49 90M13AK130220 90M13AK130220 DAMPER DAMPER-IDLE HARD-40 C2G083B
50 nsp nsp WASHER POLY.SLIT WASHER 2.1X4X0.25C
51 nsp nsp SCREW SPECIAL SCREW (FRONT)
52 nsp nsp SCREW SPECIAL SCREW (REAR)
53 nsp nsp GEAR FEED GEAR 3RD
54 90M13AK116210 90M13AK116210 LEAF SPRING TRAY-SPRING-VXF 9KB 7P02 4
60 90M13AK104210 90M13AK104210 RETAINER PLATE-RE-2HPC 9KC 2P03 1
61 90M13AK104220 90M13AK104220 RETAINER WF-PLATE-RE-2HPC 9KC 2P03 2
62 nsp nsp SCREW PRECISION SCREW 2X4(P) TYPE1 9KS 20P1 04
63
nsp nsp
SCREW PRECISION SCREW 1.7X5 TYPE3
64 nsp nsp CUSHION RUBBER CUSHION 9KC 1G04 2
66 90M-YU001350R 90M-YU001350R FFC FFC-0.5-24 L=80 9KA 2P70 6
68 nsp nsp TAPE TAPE W10X45 (NITTO NO.156)
70 nsp nsp CUSHION CUSHION L 6X3Xt4 9KC 2G07 6
71 nsp nsp CUSHION CUSHION R 6X3Xt2 9KC 2G07 7
POS. NO.
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
2-2
