Marantz SR4600 - Page 63

77
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
MAIN J766
nsp nsp
CORD SN95/PB5, 0.6 C3A206
MAIN J767
nsp nsp
CORD SN95/PB5, 0.6 C3A206
MAIN J768
nsp nsp
CORD SN95/PB5, 0.6 C3A206
MAIN J769
nsp nsp
CORD SN95/PB5, 0.6 C3A206
MAIN J997
nsp nsp
CORD SN95/PB5, 0.6 C3A206
MAIN JK91
90M-YT003530R 90M-YT003530R
TERMINAL SPEAKER 6P CJJ5R006Z
MAIN JK92
90M-YT004020R 90M-YT004020R
TERMINAL SPEAKER 8P CJJ5Q012Z
MAIN JK97
90M-YT003990R 90M-YT003990R
TERMINAL CINCH JACK 4P AUDIO CJJ4P041
W
MAIN JK98
90M-YT004000R 90M-YT004000R
TERMINAL CINCH JACK 4P AUDIO CJJ4P042
W
MAIN JW90
nsp nsp
CORD WIRE ASS'Y CWEE212120VV
MAIN JW91
nsp nsp
CORD WIRE ASS'Y CWE8202150A
A
MAIN JW92
nsp nsp
CORD WIRE ASS'Y CWEE212080VV
MAIN L501
90M-LC107310R 90M-LC107310R
COIL 0.5UH
K
CLEY0R5KA
K
MAIN L502
90M-LC107310R 90M-LC107310R
COIL 0.5UH
K
CLEY0R5KA
K
MAIN L503
90M-LC107310R 90M-LC107310R
COIL 0.5UH
K
CLEY0R5KA
K
MAIN L504
90M-LC107310R 90M-LC107310R
COIL 0.5UH
K
CLEY0R5KA
K
MAIN L505
90M-LC107310R 90M-LC107310R
COIL 0.5UH
K
CLEY0R5KA
K
MAIN L506
90M-LC107310R 90M-LC107310R
COIL 0.5UH
K
CLEY0R5KA
K
MAIN L507
90M-LC107310R 90M-LC107310R
COIL 0.5UH
K
CLEY0R5KA
K
MAIN OL91
/
N1B
90M-YT002430R 90M-YT002430R
TERMINAL ! A302D0061P KJJ7A022Z
MAIN OL91
/
N1G
90M-YT002430R 90M-YT002430R
TERMINAL ! A302D0061P KJJ7A022Z
MAIN OL91
/
N1S
90M-YT002430R 90M-YT002430R
TERMINAL ! A302D0061P KJJ7A022Z
MAIN OL91
/
U1B
nsp 90M-YT002410R
TERMINAL ! A204D0041P KJJ7A015Z
MAIN OL91
/
U1S
nsp 90M-YT002410R
TERMINAL ! A204D0041P KJJ7A015Z
MAIN Q501
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q502
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q503
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q504
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q505
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q511
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q512
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q513
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q514
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q515
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q516
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q517
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q518
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q519
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q520
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q541
90M-HT800050R 90M-HT800050R
TRS. KTC3198Y HVTKTC3198Y
T
MAIN Q544
90M-HT800050R 90M-HT800050R
TRS. KTC3198Y HVTKTC3198Y
T
MAIN Q545
90M-HT800050R 90M-HT800050R
TRS. KTC3198Y HVTKTC3198Y
T
MAIN Q556
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q557
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q558
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q559
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q560
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q561
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q562
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q563
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q564
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q565
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q601
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q602
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q603
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q604
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q605
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q652
90M-HT200440R 90M-HT200440R
TRS. ! 2SB1560 HVT2SB1560
MAIN Q653
90M-HT200440R 90M-HT200440R
TRS. ! 2SB1560 HVT2SB1560
MAIN Q654
90M-HT200440R 90M-HT200440R
TRS. ! 2SB1560 HVT2SB1560
MAIN Q655
90M-HT200440R 90M-HT200440R
TRS. ! 2SB1560 HVT2SB1560
MAIN Q657
90M-HT400490R 90M-HT400490R
TRS. ! 2SD2390 HVT2SD2390
MAIN Q658
90M-HT400490R 90M-HT400490R
TRS. ! 2SD2390 HVT2SD2390
MAIN Q659
90M-HT400490R 90M-HT400490R
TRS. ! 2SD2390 HVT2SD2390
MAIN Q660
90M-HT400490R 90M-HT400490R
TRS. ! 2SD2390 HVT2SD2390
MAIN Q661
90M-HT200440R 90M-HT200440R
TRS. ! 2SB1560 HVT2SB1560
MAIN Q670
90M-HT400490R 90M-HT400490R
TRS. ! 2SD2390 HVT2SD2390
