NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
MAIN Q681
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q682
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q683
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q684
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q685
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q801
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q802
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q803
90M-HT400490R 90M-HT400490R
TRS. ! 2SD2390 HVT2SD2390
MAIN Q804
90M-HT200440R 90M-HT200440R
TRS. ! 2SB1560 HVT2SB1560
MAIN Q805
90M-HT400490R 90M-HT400490R
TRS. ! 2SD2390 HVT2SD2390
MAIN Q807
90M-HT200440R 90M-HT200440R
TRS. ! 2SB1560 HVT2SB1560
MAIN Q812
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q813
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q814
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q815
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q816
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q817
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q818
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q819
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q820
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q821
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q822
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q823
00MHT800931A0 00MHT800931A0
TRS. KTC3200GR HVTKTC3200GRT
MAIN Q824
90M-HT800050R 90M-HT800050R
TRS. KTC3198Y HVTKTC3198Y
T
MAIN Q825
90M-HT800050R 90M-HT800050R
TRS. KTC3198Y HVTKTC3198Y
T
MAIN Q858
90M-HT100540R 90M-HT100540R
TRS. KTA1360
Y
HVTKTA1360
Y
MAIN Q871
90M-HT100540R 90M-HT100540R
TRS. KTA1360
Y
HVTKTA1360
Y
MAIN Q872
90M-HT100540R 90M-HT100540R
TRS. KTA1360
Y
HVTKTA1360
Y
MAIN Q874
90M-HT100540R 90M-HT100540R
TRS. KTA1360
Y
HVTKTA1360
Y
MAIN Q875
90M-HT100540R 90M-HT100540R
TRS. KTA1360
Y
HVTKTA1360
Y
MAIN Q876
90M-HT100540R 90M-HT100540R
TRS. KTA1360
Y
HVTKTA1360
Y
MAIN Q877
90M-HT100540R 90M-HT100540R
TRS. KTA1360
Y
HVTKTA1360
Y
MAIN Q881
90M-HT300820R 90M-HT300820R
TRS. KTC3423Y HVTKTC3423Y
MAIN Q882
90M-HT300820R 90M-HT300820R
TRS. KTC3423Y HVTKTC3423Y
MAIN Q883
90M-HT300820R 90M-HT300820R
TRS. KTC3423Y HVTKTC3423Y
MAIN Q884
90M-HT300820R 90M-HT300820R
TRS. KTC3423Y HVTKTC3423Y
MAIN Q885
90M-HT300820R 90M-HT300820R
TRS. KTC3423Y HVTKTC3423Y
MAIN Q886
90M-HT300820R 90M-HT300820R
TRS. KTC3423Y HVTKTC3423Y
MAIN Q887
90M-HT300820R 90M-HT300820R
TRS. KTC3423Y HVTKTC3423Y
MAIN Q901
00MHT600111B0 00MHT600111B0
TRS. KTA1267
Y
HVTKTA1267Y
T
MAIN Q902
90M-BA001530R 90M-BA001530R
TRS. KTC114M HVTKRC114MT
MAIN Q903
90M-BA001460R 90M-BA001460R
TRS. KRC107M HVTKRC107MT
MAIN Q904
00MHT600111B0 00MHT600111B0
TRS. KTA1267
Y
HVTKTA1267Y
T
MAIN Q905
90M-HT800050R 90M-HT800050R
TRS. KTC3198Y HVTKTC3198Y
T
MAIN Q906
00MHT600111B0 00MHT600111B0
TRS. KTA1267
Y
HVTKTA1267Y
T
MAIN Q911
00MHT600111B0 00MHT600111B0
TRS. KTA1267
Y
HVTKTA1267Y
T
MAIN Q912
90M-HT800050R 90M-HT800050R
TRS. KTC3198Y HVTKTC3198Y
T
MAIN Q913
90M-HT800050R 90M-HT800050R
TRS. KTC3198Y HVTKTC3198Y
T
MAIN Q914
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q915
90M-BA001450R 90M-BA001450R
TRS. KRA107M HVTKRA107MT
MAIN Q916
90M-HT800050R 90M-HT800050R
TRS. KTC3198Y HVTKTC3198Y
T
MAIN Q917
90M-BA001460R 90M-BA001460R
TRS. KRC107M HVTKRC107MT
MAIN Q918
00MHT600111B0 00MHT600111B0
TRS. KTA1267
Y
HVTKTA1267Y
T
MAIN Q919
90M-HT800050R 90M-HT800050R
TRS. KTC3198Y HVTKTC3198Y
T
MAIN Q920
90M-HT800050R 90M-HT800050R
TRS. KTC3198Y HVTKTC3198Y
T
MAIN Q921
90M-BA001450R 90M-BA001450R
TRS. KRA107M HVTKRA107MT
MAIN Q923
00MHT600121A0 00MHT600121A0
TRS. KTA1268GR HVTKTA1268GRT
MAIN Q924
90M-HT800050R 90M-HT800050R
TRS. KTC3198Y HVTKTC3198Y
T
MAIN Q925
90M-HT800050R 90M-HT800050R
TRS. KTC3198Y HVTKTC3198Y
T
MAIN Q960
90M-BA001460R 90M-BA001460R
TRS. KRC107M HVTKRC107MT
MAIN Q961
90M-HT600030R 90M-HT600030R
TRS. KTA1024
Y
HVTKTA1024Y
T
MAIN Q997
90M-BA001460R 90M-BA001460R
TRS. KRC107M HVTKRC107MT
MAIN Q998
00MHT600111B0 00MHT600111B0
TRS. KTA1267
Y
HVTKTA1267Y
T
MAIN R501
nsp nsp
RES. 43K OHM 1/5W J CRD20TJ433
T
MAIN R502
nsp nsp
RES. 43K OHM 1/5W J CRD20TJ433
T
MAIN R503
nsp nsp
RES. 43K OHM 1/5W J CRD20TJ433
T
MAIN R506
nsp nsp
RES. 33K OHM 1/5W J CRD20TJ333
T
