Marantz SR4600 - Page 69

83
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
MAIN R964
90M-GO000012R 90M-GO000012R
RES. 0.1 OHM 5W CRF5EKR10H
MAIN R965
nsp nsp
RES. 8.2K OHM 1/5W J CRD20TJ822
T
MAIN R966
nsp nsp
RES. 1 OHM 1/5W J CRD20TJ1R0T
MAIN R967
nsp nsp
RES. 560K OHM 1/5W J CRD20TJ564
T
MAIN R968
nsp nsp
RES. 3.9K OHM 1/5W J CRD20TJ392
T
MAIN R969
nsp nsp
RES. 15K OHM 1/5W J CRD20TJ153
T
MAIN R970
nsp nsp
RES. 470K OHM 1/5W J CRD20TJ474
T
MAIN R971
nsp nsp
RES. 15K OHM 1/5W J CRD20TJ153
T
MAIN R972
nsp nsp
RES. 39K OHM 1/5W J CRD20TJ393
T
MAIN R974
nsp nsp
RES. 330 OHM 1/5W J CRD20TJ331
T
MAIN R975
nsp nsp
RES. 330 OHM 1/5W J CRD20TJ331
T
MAIN R976
nsp nsp
RES. 330 OHM 1/5W J CRD20TJ331
T
MAIN R977
nsp nsp
RES. 330 OHM 1/5W J CRD20TJ331
T
MAIN R978
nsp nsp
RES. 330 OHM 1/5W J CRD20TJ331
T
MAIN R979
nsp nsp
RES. 39K OHM 1/5W J CRD20TJ393
T
MAIN R980
nsp nsp
RES. 15K OHM 1/5W J CRD20TJ153
T
MAIN R981
nsp nsp
RES. 56 OHM 1/4W J CRD25TJ560
T
MAIN R990
nsp nsp
RES. 10 OHM 1W CRG1ANJ100H
MAIN R993
nsp nsp
RES. 10 OHM 1W CRG1ANJ100H
MAIN R994
nsp nsp
RES. 10 OHM 1W CRG1ANJ100H
MAIN R995
nsp nsp
RES. 10 OHM 1W CRG1ANJ100H
MAIN R996
nsp nsp
RES. 10 OHM 1W CRG1ANJ100H
MAIN R997
nsp nsp
RES. 10 OHM 1W CRG1ANJ100H
MAIN R999
nsp nsp
RES. 10 OHM 1W CRG1ANJ100H
MAIN RY94
90M-LY000340R 90M-LY000340R
RELAY ! SDT-S-112DMR HSL1A008ZE
MAIN RY95
00MLY2024049
0
00MLY2024049
0
RELAY 5GPA-28 DC24 HSL3B013ZE
MAIN RY96
00MLY2024049
0
00MLY2024049
0
RELAY 5GPA-28 DC24 HSL3B013ZE
MAIN T902
/
A1B
nsp 90M-TS002210R
TRANSF. ! SUB TRANSFORMER CLT5I004ZE
MAIN T902
/
A1S
nsp 90M-TS002210R
TRANSF. ! SUB TRANSFORMER CLT5I004ZE
MAIN T902
/
N1B
90M-TS002210R 90M-TS002210R
TRANSF. ! SUB TRANSFORMER CLT5I004ZE
MAIN T902
/
N1G
90M-TS002210R 90M-TS002210R
TRANSF. ! SUB TRANSFORMER CLT5I004ZE
MAIN T902
/
N1S
90M-TS002210R 90M-TS002210R
TRANSF. ! SUB TRANSFORMER CLT5I004ZE
MAIN T902
/
U1B
nsp 90M-TS002190R
TRANSF. ! SUB TRANSFORMER CLT5I004ZU
MAIN T902
/
U1S
nsp 90M-TS002190R
TRANSF. ! SUB TRANSFORMER CLT5I004ZU
MAIN TH91
90M-HP000060R 90M-HP000060R
TERMINAL P42T7D330BW20 KRTP42T7D330B
PUSH S/W PWB
P-SW C877
/
A1B
nsp 90M-DK100800R
CER. CAP. ! DKS471ME KCKDKS471ME
P-SW C877
/
A1S
nsp 90M-DK100800R
CER. CAP. ! DKS471ME KCKDKS471ME
P-SW C877
/
N1B
90M-DK100800R 90M-DK100800R
CER. CAP. ! DKS471ME KCKDKS471ME
P-SW C877
/
N1G
90M-DK100800R 90M-DK100800R
CER. CAP. ! DKS471ME KCKDKS471ME
P-SW C877
/
N1S
90M-DK100800R 90M-DK100800R
CER. CAP. ! DKS471ME KCKDKS471ME
P-SW CN88
/
A1B
nsp nsp
CONN. MOLEX35328-02 KJP02GA89ZM
P-SW CN88
/
A1S
nsp nsp
CONN. MOLEX35328-02 KJP02GA89ZM
P-SW CN88
/
N1B
nsp nsp
CONN. MOLEX35328-02 KJP02GA89ZM
P-SW CN88
/
N1G
nsp nsp
CONN. MOLEX35328-02 KJP02GA89ZM
P-SW CN88
/
N1S
nsp nsp
CONN. MOLEX35328-02 KJP02GA89ZM
P-SW SW97
/
A1B
nsp 90M-SP001250R
SW ! JPP1197CSA64 KSH1A001ZV
P-SW SW97
/
A1S
nsp 90M-SP001250R
SW ! JPP1197CSA64 KSH1A001ZV
P-SW SW97
/
N1B
90M-SP001250R 90M-SP001250R
SW ! JPP1197CSA64 KSH1A001ZV
P-SW SW97
/
N1G
90M-SP001250R 90M-SP001250R
SW ! JPP1197CSA64 KSH1A001ZV
P-SW SW97
/
N1S
90M-SP001250R 90M-SP001250R
SW ! JPP1197CSA64 KSH1A001ZV
REGULATOR PWB
(
CUP11822Z
)
REG. C922
nsp 00MOA10702520
ELECT CAP. 100UF 25V CCEA1EH101T
REG. C923
nsp 00MOA10702520
ELECT CAP. 100UF 25V CCEA1EH101T
REG. C924
nsp 00MOA10702520
ELECT CAP. 100UF 25V CCEA1EH101T
REG. C925
nsp nsp
CER. CAP. 0.022UF 50V ZF CCKT1H223ZF
REG. C926
nsp nsp
CER. CAP. 0.022UF 50V ZF CCKT1H223ZF
REG. C927
nsp nsp
CER. CAP. 0.022UF 50V ZF CCKT1H223ZF
REG. C928
nsp 00MOA68801620
ELECT CAP. 6800UF 16
V
CCEA1CH682E
REG. C929
nsp 00MOA22802520
ELECT CAP. 2200UF 25
V
CCEA1EH222E
REG. C930
nsp 00MOA22802520
ELECT CAP. 2200UF 25
V
CCEA1EH222E
REG. CN96
nsp nsp
CONN. WAFER, STRAIGHT, 8PIN CJP08GA01Z
Y
REG. CN98
90M-YP100240R 90M-YP100240R
CONN. WAFER BJP08GB131Z
K
REG. D904
nsp 90M-HD201730R
DIODE 1N4003 KVD1N4003S
T
REG. D905
nsp 90M-HD201730R
DIODE 1N4003 KVD1N4003S
T
REG. D906
nsp 90M-HD201730R
DIODE 1N4003 KVD1N4003S
T
REG. D907
nsp 90M-HD201730R
DIODE 1N4003 KVD1N4003S
T
