Marantz SR4600 - Page 70

84
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
REG. IC91
90M-HC300650R 90M-HC300650R
IC L7812
(
ST
)
HVIL7812CP
REG. IC92
90M-HC300660R 90M-HC300660R
IC L7912
(
ST
)
HVIL7912CP
REG. IC93
90M-HC300680R 90M-HC300680R
IC L7805 HVIL7805CP
REG. J901
nsp nsp
CORD SN95/PB5, 0.6 C3A206
REG. J902
nsp nsp
CORD SN95/PB5, 0.6 C3A206
REG. J911
nsp nsp
CORD SN95/PB5, 0.6 C3A206
REG. J912
nsp nsp
CORD SN95/PB5, 0.6 C3A206
REG. J913
nsp nsp
CORD SN95/PB5, 0.6 C3A206
REG. J921
nsp nsp
CORD SN95/PB5, 0.6 C3A206
REG. J922
nsp nsp
CORD SN95/PB5, 0.6 C3A206
REG. J931
nsp nsp
CORD SN95/PB5, 0.6 C3A206
REG. J941
nsp nsp
CORD SN95/PB5, 0.6 C3A206
REG. R912
nsp nsp
RES. 15K OHM 1/5W J CRD20TJ153
T
REG. R913
nsp nsp
RES. 15K OHM 1/5W J CRD20TJ153
T
TACT PWB
(
CUP11819Z-9
)
TACT SW96
/
U1B
nsp 90M-SP001210R
SW SKHV10910G TAC
T
CST1A012Z
T
TACT SW96
/
U1S
nsp 90M-SP001210R
SW SKHV10910G TAC
T
CST1A012Z
T
POWER TRANSF.1 PWB
(
CUP11619Z-5
)
TRANS.1 BN96
nsp nsp
CORD WIRE ASS'Y CWB1C908150BM
TRANS.1 C107
nsp nsp
CER. CAP. 0.01UF 50V ZF CCKT1H103ZF
TRANS.1 C108
nsp nsp
CER. CAP. 0.01UF 50V ZF CCKT1H103ZF
TRANS.1 C109
nsp nsp
FILM CAP. 0.01UF 50V J HCQI1H103JZT
TRANS.1 C110
nsp nsp
FILM CAP. 0.01UF 50V J HCQI1H103JZT
TRANS.1 C111
nsp nsp
CER. CAP. 0.01UF 50V ZF CCKT1H103ZF
TRANS.1 C112
nsp nsp
CER. CAP. 0.01UF 50V ZF CCKT1H103ZF
TRANS.1 C117
nsp 00MOA47601640
ELECT CAP. 47UF 16V CCEA1CH470T
TRANS.1 C118
nsp nsp
CER. CAP. 0.01UF 50V ZF CCKT1H103ZF
TRANS.1 C119
nsp 00MOA47605020
ELECT CAP. 47UF 50V CCEA1HH470T
TRANS.1 C120
nsp 00MOA47605020
ELECT CAP. 47UF 50V CCEA1HH470T
TRANS.1 C121
nsp nsp
CER. CAP. 0.01UF 50V ZF CCKT1H103ZF
TRANS.1 C122
nsp 00MOA10705020
ELECT CAP. 100UF 50V CCEA1HH101T
TRANS.1 C123
nsp 00MOA47701620
ELECT CAP. 470UF 16V CCEA1CH471T
TRANS.1 CN14
nsp nsp
CONN. WAFER, STRAIGHT, 7PIN CJP07GA19Z
Y
TRANS.1 CN99
nsp nsp
CONN. WAFER CJP03GA01Z
Y
TRANS.1 D102
90M-HD302190R 90M-HD302190R
ZENER DIODE 30V 1/2
W
HVDMTZJ30B
T
TRANS.1 D104
nsp 90M-HD201730R
DIODE 1N4003 KVD1N4003S
T
TRANS.1 D105
nsp 90M-HD201730R
DIODE 1N4003 KVD1N4003S
T
TRANS.1 D108
nsp 90M-HD201730R
DIODE 1N4003 KVD1N4003S
T
TRANS.1 D111
90M-HD302150R 90M-HD302150R
ZENER DIODE 6.8V 1/2
W
HVDMTZJ6.8B
T
TRANS.1 J631
nsp nsp
CORD SN95/PB5, 0.6 C3A206
TRANS.1 J632
nsp nsp
CORD SN95/PB5, 0.6 C3A206
TRANS.1 Q131
00MHT600141B0 00MHT600141B0
TRS. KTA1271
Y
HVTKTA1271Y
T
TRANS.1 R101
nsp nsp
RES. 3.3 OHM 1/4
W
KRD25FJ3R3
T
TRANS.1 R104
90M-NH000080R 90M-NH000080R
FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
TRANS.1 R105
90M-NH000080R 90M-NH000080R
FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
TRANS.1 R106
/
A1B
nsp 90M-NH000150R
FUSE RES. ! 0.15 OHM, 1W J KRQ1AJR15H
TRANS.1 R106
/
A1S
nsp 90M-NH000150R
FUSE RES. ! 0.15 OHM, 1W J KRQ1AJR15H
TRANS.1 R106
/
N1B
90M-NH000150R 90M-NH000150R
FUSE RES. ! 0.15 OHM, 1W J KRQ1AJR15H
TRANS.1 R106
/
N1G
90M-NH000150R 90M-NH000150R
FUSE RES. ! 0.15 OHM, 1W J KRQ1AJR15H
TRANS.1 R106
/
N1S
90M-NH000150R 90M-NH000150R
FUSE RES. ! 0.15 OHM, 1W J KRQ1AJR15H
TRANS.1 R106
/
U1B
nsp 90M-NH000080R
FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
TRANS.1 R106
/
U1S
nsp 90M-NH000080R
FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
TRANS.1 R107
/
A1B
nsp 90M-NH000150R
FUSE RES. ! 0.15 OHM, 1W J KRQ1AJR15H
TRANS.1 R107
/
A1S
nsp 90M-NH000150R
FUSE RES. ! 0.15 OHM, 1W J KRQ1AJR15H
TRANS.1 R107
/
N1B
90M-NH000150R 90M-NH000150R
FUSE RES. ! 0.15 OHM, 1W J KRQ1AJR15H
TRANS.1 R107
/
N1G
90M-NH000150R 90M-NH000150R
FUSE RES. ! 0.15 OHM, 1W J KRQ1AJR15H
TRANS.1 R107
/
N1S
90M-NH000150R 90M-NH000150R
FUSE RES. ! 0.15 OHM, 1W J KRQ1AJR15H
TRANS.1 R107
/
U1B
nsp 90M-NH000080R
FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
TRANS.1 R107
/
U1S
nsp 90M-NH000080R
FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
TRANS.1 R108
nsp nsp
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
TRANS.1 R109
nsp nsp
RES. 10 OHM 1/5W J CRD20TJ100
T
TRANS.1 R110
nsp nsp
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
TRANS.1 R112
nsp nsp
RES. 1.2K OHM 1/5W J CRD20TJ122
T
TRANS.1 R113
nsp nsp
RES. 47K OHM 1/5W J CRD20TJ473
T
POWER TRANSF.2 PWB
(
CUP11619Z-7
)
TRANS.2 C921
nsp nsp
FILM CAP. 0.12UF 50V J HCQI1H124JZT
TRANS.2 C922
nsp nsp
FILM CAP. 0.12UF 50V J HCQI1H124JZT
