85
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
TRANS.2 C923
nsp nsp
FILM CAP. 0.12UF 50V J HCQI1H124JZT
TRANS.2 C924
nsp nsp
FILM CAP. 0.022UF 50V J HCQI1H223JZT
TRANS.2 C925
nsp nsp
FILM CAP. 0.022UF 50V J HCQI1H223JZT
TRANS.2 C926
nsp nsp
FILM CAP. 0.022UF 50V J HCQI1H223JZT
TRANS.2 C927
nsp nsp
FILM CAP. 0.022UF 50V J HCQI1H223JZT
TRANS.2 C931
nsp nsp
FILM CAP. 0.047UF 50V J HCQI1H473JZT
TRANS.2 C932
nsp nsp
FILM CAP. 0.047UF 50V J HCQI1H473JZT
TRANS.2 CN20
nsp nsp
CONN. MOLEX35313-0310 KJP03GA90ZM
TRANS.2 CN93
nsp nsp
CONN. WAFER, STRAIGHT, 2PIN CJP02GA01Z
Y
TRANS.2 D990
nsp 90M-HD201730R
DIODE 1N4003 KVD1N4003S
T
TRANS.2 J877
nsp nsp
CORD SN95/PB5, 0.6 C3A206
TRANS.2 J878
nsp nsp
CORD SN95/PB5, 0.6 C3A206
TRANS.2 R997
nsp nsp
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
TRANS.2 R998
nsp nsp
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
TRANS.2 RL11
00MLY2024052
0
00MLY2024052
0
RELAY ! PCLH-203D1SP HSL4B018ZU
POWER TRANSF.3 PWB
(
CUP11619Z-8
)
TRANS.3 BN21
nsp nsp
CORD WIRE ASS'Y CWB1E908070MM
TRANS.3 D991
90M-HE200250R 90M-HE200250R
DIODE ! GBJ1504 HVDGBJ1504
TRANS.3 J875
nsp nsp
CORD SN95/PB5, 0.6 C3A206
TRANS.3 J876
nsp nsp
CORD SN95/PB5, 0.6 C3A206
VIDEO PWB
(
CUP11619Z-3
)
VIDEO BK51
nsp nsp
TERMINAL PLATE, EARTH CMC1A111
VIDEO C501
nsp nsp
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C502
nsp nsp
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C503
nsp nsp
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C504
nsp nsp
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C505
nsp nsp
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C506
nsp nsp
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C507
nsp nsp
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C508
nsp nsp
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C509
nsp nsp
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C510
nsp nsp
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C511
nsp nsp
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C512
nsp nsp
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C513
nsp nsp
CER. CAP. 68PF 50V J HCBS1H680JT
VIDEO C514
nsp nsp
CER. CAP. 68PF 50V J HCBS1H680JT
VIDEO C515
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C516
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C517
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C518
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C519
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C520
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C522
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C523
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C524
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C525
nsp 00MOA47700620
ELECT CAP. 470UF 6.3V CCEA0JH471T
VIDEO C526
nsp nsp
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C527
nsp 00MOA47700620
ELECT CAP. 470UF 6.3V CCEA0JH471T
VIDEO C528
nsp nsp
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C529
nsp nsp
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C530
nsp nsp
CER. CAP. 0.022UF 50V
Z
HCBS1H223ZFT
VIDEO C531
nsp nsp
CER. CAP. 0.022UF 50V
Z
HCBS1H223ZFT
VIDEO C532
nsp nsp
CER. CAP. 0.022UF 50V
Z
HCBS1H223ZFT
VIDEO C533
nsp nsp
CER. CAP. 0.022UF 50V
Z
HCBS1H223ZFT
VIDEO C534
nsp nsp
CER. CAP. 0.022UF 50V
Z
HCBS1H223ZFT
VIDEO C535
nsp nsp
CER. CAP. 0.022UF 50V
Z
HCBS1H223ZFT
VIDEO C536
nsp 00MOA10701620
ELECT CAP. 100UF 16V ZF CCEA1CH101T
VIDEO C537
nsp 00MOA10701620
ELECT CAP. 100UF 16V ZF CCEA1CH101T
VIDEO C538
nsp 00MOA10701620
ELECT CAP. 100UF 16V ZF CCEA1CH101T
VIDEO C539
nsp 00MOA10701620
ELECT CAP. 100UF 16V ZF CCEA1CH101T
VIDEO C540
nsp 00MOA10701620
ELECT CAP. 100UF 16V ZF CCEA1CH101T
VIDEO C541
nsp 00MOA10701620
ELECT CAP. 100UF 16V ZF CCEA1CH101T
VIDEO C542
nsp 00MOA10701620
ELECT CAP. 100UF 16V ZF CCEA1CH101T
VIDEO C543
nsp 00MOA10701620
ELECT CAP. 100UF 16V ZF CCEA1CH101T
VIDEO C544
nsp nsp
CER. CAP. 0.022UF 50V
Z
HCBS1H223ZFT
VIDEO C545
nsp nsp
CER. CAP. 0.022UF 50V ZF CCKT1H223ZF
VIDEO C546
nsp 00MOA10603540
ELECT CAP. 10UF 35V CCEA1VH100T
