Marantz SR480 Service Manual

POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
R52D /02 nsp 10k
Ω
1/5W J nsp
R53D /02 nsp 10k
Ω
1/5W J nsp
R56D SR480 nsp 2.2M
Ω
1/5W J nsp
R57L/R /02 nsp 1.5k
Ω
1/5W J METAL nsp
R6 SR480 nsp 100k
Ω
1/5W J nsp
R7 SR480 nsp 10k
Ω
1/5W J nsp
R8 SR480 nsp 270
Ω
1/5W J METAL nsp
R9 SR480 nsp 560
Ω
1/5W J METAL nsp
SEMI FIXED VARIABLE
RESISTORS
VR1 SR480 4822 101 11855 5K(B)-H *RA000810R
VR2 SR480 4822 100 12294 50K(B)-H *RA000670R
VR3 SR480 4822 101 11757 200K(B)-H *RA000710R
MISCELLANEOUS
ANT1 /01/02 4822 265 11478 TERMINAL ANT *YT001360R
ANT1 U nsp TERMINAL ANT *YT001350R
FE1 U nsp FM TUNER FTA3-506HB *AW000140R
FE1 /01/02 4822 210 10843 FM TUNER FTH4-460H *AW000150R
L1C /01/02 4822 157 71893 COIL 20.8MH *LC106500R
T1 SR480 4822 157 71881 AM-ANT *TC000150R
T2 SR480 4822 157 71888 AM-OSC *TC000160R
T3 SR480 4822 157 71896 AM-IFT *TC000200R
T4 SR480 4822 146 10773 FM-DET-A *TC000250R
T5 SR480 4822 146 10772 FM-DET-B *TC000260R
T6L/R SR480 4822 157 11049 MPX(19/38kHz) *TC000270R
TC1 SR480 4822 125 60227 TRIM CAP. 10 pF *CT000080R
VD1 SR480 4822 125 11115 VARACTOR SVC321 SPA-C *HD400150R
VD2 SR480 4822 125 11115 VARACTOR SVC321 SPA-C *HD400150R
X1 SR480 4822 242 10735 X-TAL 7.2MHz *JX000390R
X2 SR480 4822 242 81117 CSB456F CRYSTAL FQ04563010
X3D /02 4822 242 11045 4.332MHZ HC49U CRYSTAL *JX000560R
MAIN CIRCUIT BOARD
CAPACITORS
C102 nsp CER. 0.0047
µ
F 250V nsp
C103 nsp FILM 0.047
µ
F 100V J nsp
C104 nsp FILM 0.047
µ
F 100V J nsp
C105 nsp FILM 0.047
µ
F 100V J nsp
C106 /01 nsp ELECT 220
µ
F 50V M nsp
C107 nsp ELECT 220
µ
F 25V E nsp
C108 nsp ELECT 1
µ
F 50V M nsp
C109 nsp CER. 0.1
µ
F 50V Z nsp
C110 nsp FILM 0.22
µ
F 63V K nsp
C111
nsp FILM 0.1
µ
F 250V K nsp
C115
C116 4822 124 12419 ELECT 10000
µ
F 63V M *EA000880R
C117 4822 124 12419 ELECT 10000
µ
F 63V M *EA000880R
C118
nsp FILM 0.047
µ
F 100V J nsp
C122
C123 5322 124 22229 ELECT 1000
µ
F 35V M EA10803510
C124 5322 124 22229 ELECT 1000
µ
F 35V M EA10803510
C125 nsp FILM 0.047
µ
F 100V J nsp
C126 nsp FILM 0.047
µ
F 100V J nsp
C127 nsp FILM 0.047
µ
F 100V J nsp
!C128 4822 124 12421 ELECT 1000
µ
F 25V M *EA000870R
C129 nsp ELECT 1
µ
F 50V M nsp
C130 nsp CER. 0.1
µ
F 50V Z nsp
C131 nsp ELECT 1
µ
F 50V M nsp
C132 nsp CER. 0.1
µ
F 50V Z nsp
C133 nsp ELECT 1
µ
F 50V M nsp
C134 nsp CER. 0.1
µ
F 50V Z nsp
C135 nsp ELECT 1
µ
F 50V M nsp
C136 nsp ELECT 470
µ
F 6.3V E nsp
C137 MZ01 nsp ELECT 47
µ
F 25V M nsp
C138 MZ01 nsp ELECT 47
µ
F 25V M nsp
C139 MZ01 nsp ELECT 22
µ
F 16V M nsp
C140 MZ01 nsp ELECT 22
µ
F 16V M nsp
C141 MZ01 nsp ELECT 22
µ
F 16V M nsp
C142 MZ01 nsp ELECT 0.33
µ
F 50V E nsp
C143 MZ01 nsp FILM 0.068
µ
F 50V J nsp
C144 MZ01 nsp FILM 0.068
µ
F 50V J nsp
C145 nsp ELECT 47
µ
F 50V M nsp
C146 nsp ELECT 10
µ
F 50V M nsp
CONNECTORS
CP100 SR480 nsp CONNECTOR 2.5MM (15P) nsp
CP101 nsp CONNECTOR 3.96MM (2P) nsp
CP102 nsp CONNECTOR 3.96MM (2P) nsp
CP103 nsp CONNECTOR 3.96MM (4P) nsp
CP104 nsp CONNECTOR 2.5MM (6P) nsp
CP105 nsp CONNECTOR 2.5MM (4P) nsp
CP106 nsp CONNECTOR 2.0MM (9P) nsp
CP107 nsp CONNECTOR 2.5MM (2P) nsp
CP108 U nsp CONNECTOR 7.92MM (2P) nsp
CP108 /01/02 nsp CONNECTOR 7.92MM(2P) 7A nsp
CP201 nsp CONNECTOR 2.5MM (8P) nsp
CP202 nsp CONNECTOR 2.5MM (7P) nsp
CP301 nsp CONNECTOR FPC 1.25MM (25P) nsp
CP401 nsp CONNECTOR 2.0MM (8P) nsp
CP402 nsp CONNECTOR 2.0MM (8P) nsp
CP451 nsp CONNECTOR 2.0MM (16P) nsp
CP501 nsp CONNECTOR 2.0MM (12P) nsp
CP502 nsp CONNECTOR 2.0MM (15P) nsp
CP801 nsp CONNECTOR 2.0MM (14P) nsp
CP802 nsp CONNECTOR 2.0MM (14P) nsp
CP901 nsp CONNECTOR 2.5MM (11P) nsp
DIODES
D101
4822 130 31878 1N4003 HD200010AR
D105
D106 4822 130 32778 1SS133T HD20015210
D107 4822 130 11642 KBPC2504W RECTIFIER BRIDGE *HE200200R
D108
4822 130 31878 1N4003 HD200010AR
D115
D116 /01 4822 130 10878 ZENER UZ12V *HD301300R
D117 4822 130 32778 1SS133T HD20015210
D118 4822 130 70043 ZENER UZ4V3 *HD301070R
D119 4822 130 70046 ZENER UZ9V1 *HD301100R
D120 4822 130 11636 ZENER UZ30V *HD301650R
D121 4822 130 32778 1SS133T HD20015210
D122 4822 130 70046 ZENER UZ9V1 *HD301100R
D123 /01 4822 130 32778 1SS133T HD20015210
D124 /01 4822 130 32778 1SS133T HD20015210
FUSES
F101 /01/02 4822 252 11371 T5A/250V *FS000610R
F101 U nsp SB6.3A/125V *FS000620R
F102D /01/02 4822 070 32002 T2A/25V *FS000490R
F103 U nsp SB315MA/125V *FS000340R
F103 /01/02 4822 070 33151 T315MA/250V *FS000510R
F104 U nsp SB1A/125V *FS000240R
F104 /01/02 4822 070 31002 T1A/250V *FS000280R
F105 U nsp SB1A/125V *FS000240R
F105 /01/02 4822 070 31002 T1A/250V *FS000280R
F106 U nsp NB250MA/125V *FS000430R
F106 /01/02 4822 252 11372 T250MA/250V *FS000630R
F107 U nsp NB250MA/125V *FS000430R
F107 /01/02 4822 252 11372 T250MA/250V *FS000630R
INTEGRATED CIRCUITS
IC101 4822 209 90086 KIA7805 *HC300140R
IC102 4822 209 91033 KIA7815 *HC300150R
IC103 4822 209 17165 KIA7915 *HC300200R
IC104 4822 209 91031 KIA7806 *HC300120R
IC105 MZ01 4822 209 91029 KIA4559P *HC103590R
TRANSISTORS
Q101 4822 130 62503 DTC114YS *BA000210R
Q102 /01 4822 130 11637 2SD2059 *HT400360R
Q103 4822 130 11638 MPSA56 *HT100440R
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
R218C nsp 4.7k
Ω
1/5W J METAL nsp
R218L nsp 4.7k
Ω
1/5W J METAL nsp
R218R nsp 4.7k
Ω
1/5W J METAL nsp
R218SL nsp 4.7k
Ω
1/5W J METAL nsp
R218SR nsp 4.7k
Ω
1/5W J METAL nsp
R219C nsp 560
Ω
1/5W J METAL nsp
R219L nsp 560
Ω
1/5W J METAL nsp
R219R nsp 560
Ω
1/5W J METAL nsp
R219SL nsp 560
Ω
1/5W J METAL nsp
R219SR nsp 560
Ω
1/5W J METAL nsp
R220C nsp 4.7k
Ω
1/5W J METAL nsp
R220L nsp 4.7k
Ω
1/5W J METAL nsp
R220R nsp 4.7k
Ω
1/5W J METAL nsp
R220SL nsp 4.7k
Ω
1/5W J METAL nsp
R220SR nsp 4.7k
Ω
1/5W J METAL nsp
R221C nsp 82
Ω
1/5W J METAL nsp
R221L nsp 82
Ω
1/5W J METAL nsp
R221R nsp 82
Ω
1/5W J METAL nsp
R221SL nsp 82
Ω
1/5W J METAL nsp
R221SR nsp 82
Ω
1/5W J METAL nsp
R222C nsp 82
Ω
1/5W J METAL nsp
R222L nsp 82
Ω
1/5W J METAL nsp
R222R nsp 82
Ω
1/5W J METAL nsp
R222SL nsp 82
Ω
1/5W J METAL nsp
R222SR nsp 82
Ω
1/5W J METAL nsp
R223C nsp 22k
Ω
1/5W J nsp
R223L nsp 22k
Ω
1/5W J nsp
R223R nsp 22k
Ω
1/5W J nsp
R223SL nsp 22k
Ω
1/5W J nsp
R223SR nsp 22k
Ω
1/5W J nsp
R224C nsp 22k
Ω
1/5W J nsp
R224L nsp 22k
Ω
1/5W J nsp
R224R nsp 22k
Ω
1/5W J nsp
R224SL nsp 22k
Ω
1/5W J nsp
R224SR nsp 22k
Ω
1/5W J nsp
R225C nsp 2k
Ω
1/5W J nsp
R225L nsp 2k
Ω
1/5W J nsp
R225R nsp 2k
Ω
1/5W J nsp
R225SL nsp 2k
Ω
1/5W J nsp
R225SR nsp 2k
Ω
1/5W J nsp
R226C nsp 620
Ω
1/5W J METAL nsp
R226L nsp 620
Ω
1/5W J METAL nsp
R226R nsp 620
Ω
1/5W J METAL nsp
R226SL nsp 620
Ω
1/5W J METAL nsp
R226SR nsp 620
Ω
1/5W J METAL nsp
R227C nsp 1.2k
Ω
1/5W J METAL nsp
R227L nsp 1.2k
Ω
1/5W J METAL nsp
R227R nsp 1.2k
Ω
1/5W J METAL nsp
R227SL nsp 1.2k
Ω
1/5W J METAL nsp
R227SR nsp 1.2k
Ω
1/5W J METAL nsp
R228C nsp 100
Ω
1/5W J METAL nsp
R228L nsp 100
Ω
1/5W J METAL nsp
R228R nsp 100
Ω
1/5W J METAL nsp
R228SL nsp 100
Ω
1/5W J METAL nsp
R228SR nsp 100
Ω
1/5W J METAL nsp
R229C nsp 100
Ω
1/5W J METAL nsp
R229L nsp 100
Ω
1/5W J METAL nsp
R229R nsp 100
Ω
1/5W J METAL nsp
R229SL nsp 100
Ω
1/5W J METAL nsp
R229SR nsp 100
Ω
1/5W J METAL nsp
R230C nsp 82
Ω
1/5W J METAL nsp
R230L nsp 82
Ω
1/5W J METAL nsp
R230R nsp 82
Ω
1/5W J METAL nsp
R230SL nsp 82
Ω
1/5W J METAL nsp
R230SR nsp 82
Ω
1/5W J METAL nsp
R231C nsp 3.3
Ω
1/5W J METAL nsp
R231L nsp 3.3
Ω
1/5W J METAL nsp
R231R nsp 3.3
Ω
1/5W J METAL nsp
R231SL nsp 3.3
Ω
1/5W J METAL nsp
R231SR nsp 3.3
Ω
1/5W J METAL nsp
R232C nsp 3.3
Ω
1/5W J METAL nsp
R232L nsp 3.3
Ω
1/5W J METAL nsp
R232R nsp 3.3
Ω
1/5W J METAL nsp
R232SL nsp 3.3
Ω
1/5W J METAL nsp
R232SR nsp 3.3
Ω
1/5W J METAL nsp
R233C nsp 1.8k
Ω
1/5W J METAL nsp
R233L nsp 1.8k
Ω
1/5W J METAL nsp
R233R nsp 1.8k
Ω
1/5W J METAL nsp
R233SL nsp 1.8k
Ω
1/5W J METAL nsp
R233SR nsp 1.8k
Ω
1/5W J METAL nsp
R234C nsp 2k
Ω
1/5W J nsp
R234L nsp 2k
Ω
1/5W J nsp
R234R nsp 2k
Ω
1/5W J nsp
R234SL nsp 2k
Ω
1/5W J nsp
R234SR nsp 2k
Ω
1/5W J nsp
R235C nsp 910
Ω
1/5W J METAL nsp
R235L nsp 910
Ω
1/5W J METAL nsp
R235R nsp 910
Ω
1/5W J METAL nsp
R235SL nsp 910
Ω
1/5W J METAL nsp
R235SR nsp 910
Ω
1/5W J METAL nsp
R236C nsp 6.8k
Ω
1/5W J nsp
R236L nsp 6.8k
Ω
1/5W J nsp
R236R nsp 6.8k
Ω
1/5W J nsp
R236SL nsp 6.8k
Ω
1/5W J nsp
R236SR nsp 6.8k
Ω
1/5W J nsp
R237C nsp 39
Ω
1/5W J METAL nsp
R237L nsp 39
Ω
1/5W J METAL nsp
R237R nsp 39
Ω
1/5W J METAL nsp
R238C nsp 39
Ω
1/5W J METAL nsp
R238L nsp 39
Ω
1/5W J METAL nsp
R238R nsp 39
Ω
1/5W J METAL nsp
R239C nsp 39
Ω
1/5W J METAL nsp
R239L nsp 39
Ω
1/5W J METAL nsp
R239R nsp 39
Ω
1/5W J METAL nsp
R240C nsp 39
Ω
1/5W J METAL nsp
R240L nsp 39
Ω
1/5W J METAL nsp
R240R nsp 39
Ω
1/5W J METAL nsp
R243 nsp 560
Ω
1/5W J METAL nsp
R245L nsp 22k
Ω
1/5W J nsp
R245R nsp 22k
Ω
1/5W J nsp
R246 nsp 560
Ω
1/5W J METAL nsp
MPR201C
4822 117 13662 0.27
Ω
5W CEMENT *GO000004R
MPR201C
4822 117 13662 0.27
Ω
5W CEMENT *GO000004R
MPR201MPR
4822 117 13662 0.27
Ω
5W CEMENT *GO000004R
MPR201SL
4822 117 13662 0.27
Ω
5W CEMENT *GO000004R
MPR201SMPR
4822 117 13662 0.27
Ω
5W CEMENT *GO000004R
THERMISTORS
TH201C 4822 117 13557 THERMISTOR NTC5D-302KPC *HH000080R
TH201L 4822 117 13557 THERMISTOR NTC5D-302KPC *HH000080R
TH201R 4822 117 13557 THERMISTOR NTC5D-302KPC *HH000080R
TH201SL 4822 117 13557 THERMISTOR NTC5D-302KPC *HH000080R
TH201SR 4822 117 13557 THERMISTOR NTC5D-302KPC *HH000080R
FRONT CIRCUIT BOARD
CAPACITORS
C301 nsp ELECT 100
µ
F 6.3V M nsp
C302 nsp CER. 0.1
µ
F 50V Z nsp
C303 4822 124 11552 DOUBLE LAYER 0.047 F 5.5V *EX000020R
C304 nsp ELECT 0.68
µ
F 5 0V M nsp
C305 nsp ELECT1 0
µ
F 50V M nsp
C306 nsp CER. 820 pF 50V K nsp
C307 nsp ELECT 10
µ
F 50V M nsp
C308 nsp FILM 0.047
µ
F 100V J nsp
C309 nsp FILM 0.047
µ
F 100V J nsp
CONNECTORS
CN302 nsp CONNECTOR (9P) nsp
CN303 nsp CONNECTOR (3P) nsp
CP301 nsp CONNECTOR FPC 1.25MM (25P) nsp
54 51

Marantz SR480 Specifications

General

Brand	Marantz
Model	SR480
Category	Receiver
Language	English
