Marantz SR480 - Page 28

POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
Q104 4822 130 62503 DTC114YS *BA000210R
Q105 4822 130 11482 BKTA1267 *HT100330R
Q106 4822 130 42431 2SC1740S HT317402F0
Q107 4822 130 42431 2SC1740S HT317402F0
Q108 4822 130 62503 DTC114YS *BA000210R
Q109 4822 130 62787 DTA114YS *BA000720R
RESISTORS
R101 U 3.3M
Ω
1/2W J METAL nsp
R102 nsp 2.2k
Ω
1/5W J METAL nsp
R103 nsp 2.2k
Ω
1/5W J METAL nsp
R104 nsp 1k
Ω
1/5W J METAL nsp
R105 nsp 10k
Ω
1/5W J nsp
R106 nsp 56
Ω
1/5W J METAL nsp
R107 /01 4822 117 11859 2.2k
Ω
2W J METAL NK05222020
R108 nsp 5.6
Ω
2W J METAL nsp
R109 U/02 4822 053 11109 10
Ω
2W J METAL GA05100020
R110 U/02 4822 053 11109 10
Ω
2W J METAL GA05100020
R111 nsp 100k
Ω
1/5W J nsp
R112 nsp 68k
Ω
1/5W J nsp
R113 nsp 3.3k
Ω
1/5W J METAL nsp
R114 nsp 1.5k
Ω
1/5W J METAL nsp
R115 nsp 1k
Ω
1/5W J METAL nsp
R116 nsp 4.7k
Ω
1/5W J METAL nsp
R117 MZ01 nsp 220
Ω
1/5W J METAL nsp
R118 MZ01 nsp 220
Ω
1/5W J METAL nsp
R119 MZ01 nsp 100k
Ω
1/5W J nsp
R120 MZ01 nsp 100k
Ω
1/5W J nsp
R121 MZ01 nsp 22k
Ω
1/5W J nsp
R122 MZ01 nsp 22k
Ω
1/5W J nsp
R123 MZ01 nsp 22k
Ω
1/5W J nsp
R124 MZ01 nsp 10k
Ω
1/5W J nsp
R125 MZ01 nsp 12k
Ω
1/5W J nsp
R126 MZ01 nsp 47k
Ω
1/5W J nsp
R127 nsp 24k
Ω
1/5W J nsp
R128 nsp 24k
Ω
1/5W J nsp
R129 nsp 24k
Ω
1/5W J nsp
R130 nsp 100k
Ω
1/5W J nsp
R131 nsp 82k
Ω
1/5W J nsp
R132 nsp 1k
Ω
1/5W J METAL nsp
R133 /01 4822 117 11859 2.2k
Ω
2W J METAL NK05222020
MISCELLANEOUS
RLY101 4822 280 80794 SDT-SS-112DM *LY000120R
TR101 U nsp ST-BY TRANS 120V *TS000790R
TR101 /02 4822 146 11109 ST-BY TRANS 230V *TS000800R
TR101 /01 4822 146 11163 ST-BY TRANS 120/220V *TS000970R
AMP CIRCUIT BOARD
CAPACITORS
C201C nsp ELECT 47
µ
F 16V M nsp
C201L nsp ELECT 47
µ
F 16V M nsp
C201R nsp ELECT 47
µ
F 16V M nsp
C201SL nsp ELECT 47
µ
F 16V M nsp
C201SR nsp ELECT 47
µ
F 16V M nsp
C202C nsp CER. 100 pF 50V J nsp
C202L nsp CER. 100 pF 50V J nsp
C202R nsp CER. 100 pF 50V J nsp
C202SL nsp CER. 270 pF 50V K nsp
C202SR nsp CER. 270 pF 50V K nsp
C204C nsp ELECT 1
µ
F 50V M nsp
C204L nsp ELECT 1
µ
F 50V M nsp
C204R nsp ELECT 1
µ
F 50V M nsp
C204SL nsp ELECT 1
µ
F 50V M nsp
C204SR nsp ELECT 1
µ
F 50V M nsp
C205C nsp ELECT 22
µ
F 16V M nsp
C205L nsp ELECT 22
µ
F 16V M nsp
C205R nsp ELECT 22
µ
F 16V M nsp
C205SL nsp ELECT 22
µ
F 16V M nsp
C205SR nsp ELECT 22
µ
F 16V M nsp
C206C nsp ELECT 220
µ
F 10V M nsp
C206L nsp ELECT 220
µ
F 10V M nsp
C206R nsp ELECT 220
µ
F 10V M nsp
C206SL nsp ELECT 220
µ
F 10V M nsp
C206SR nsp ELECT 220
µ
F 10V M nsp
C209C nsp ELECT 10
µ
F 50V M nsp
C209L nsp ELECT 10
µ
F 50V M nsp
C209R nsp ELECT 10
µ
F 50V M nsp
C209SL nsp ELECT 10
µ
F 50V M nsp
C209SR nsp ELECT 10
µ
F 50V M nsp
C210C nsp ELECT 470
µ
F 63V M nsp
C210L nsp ELECT 470
µ
F 63V M nsp
C210R nsp ELECT 470
µ
F 63V M nsp
C210SL nsp ELECT 470
µ
F 63V M nsp
C210SR nsp ELECT 470
µ
F 63V M nsp
C211C nsp ELECT 470
µ
F 63V M nsp
C211L nsp ELECT 470
µ
F 63V M nsp
C211R nsp ELECT 470
µ
F 63V M nsp
C211SL nsp ELECT 470
µ
F 63V M nsp
C211SR nsp ELECT 470
µ
F 63V M nsp
C212C nsp ELECT 10
µ
F 50V M nsp
C212L nsp ELECT 10
µ
F 50V M nsp
C212R nsp ELECT 10
µ
F 50V M nsp
C212SL nsp ELECT 10
µ
F 50V M nsp
C212SR nsp ELECT 10
µ
F 50V M nsp
C214C nsp CER. 1 pF 50V K nsp
C214L nsp CER. 1 pF 50V K nsp
C214R nsp CER. 1 pF 50V K nsp
C214SL nsp CER. 1 pF 50V K nsp
C214SR nsp CER. 1 pF 50V K nsp
C215C nsp CER. 180 pF 50V K nsp
C215L nsp CER. 180 pF 50V K nsp
C215R nsp CER. 180 pF 50V K nsp
C215SL nsp CER. 180 pF 50V K nsp
C215SR nsp CER. 180 pF 50V K nsp
C216L nsp ELECT 10
µ
F 50V M nsp
C216R nsp ELECT 10
µ
F 50V M nsp
C218 nsp ELECT 47
µ
F 50V M nsp
CONNECTORS
CN201 nsp CONNECTOR CTM 0708 5254 nsp
CN202 nsp CONNECTOR CTM 0708 5254 nsp
CP201 nsp CONNECTOR 2.0MM (10P) nsp
CP202 nsp CONNECTOR 3.96MM nsp
DIODES
D201C 4822 130 32778 1SS133T HD20015210
D201L 4822 130 32778 1SS133T HD20015210
D201R 4822 130 32778 1SS133T HD20015210
D201SL 4822 130 32778 1SS133T HD20015210
D201SR 4822 130 32778 1SS133T HD20015210
D202C 4822 130 32778 1SS133T HD20015210
D202L 4822 130 32778 1SS133T HD20015210
D202R 4822 130 32778 1SS133T HD20015210
D202SL 4822 130 32778 1SS133T HD20015210
D202SR 4822 130 32778 1SS133T HD20015210
COILS
L201C 4822 157 71892 COIL J9000031 *LC106490R
L201L 4822 157 71892 COIL J9000031 *LC106490R
L201R 4822 157 71892 COIL J9000031 *LC106490R
TRANSISTORS
Q201C 4822 130 11484 KTA1268 *HT100340R
Q201L 4822 130 11484 KTA1268 *HT100340R
Q201R 4822 130 11484 KTA1268 *HT100340R
Q201SL 4822 130 11484 KTA1268 *HT100340R
Q201SR 4822 130 11484 KTA1268 *HT100340R
Q202C 4822 130 11484 KTA1268 *HT100340R
Q202L 4822 130 11484 KTA1268 *HT100340R
Q202R 4822 130 11484 KTA1268 *HT100340R
Q202SL 4822 130 11484 KTA1268 *HT100340R
Q202SR 4822 130 11484 KTA1268 *HT100340R
Q203C 4822 130 11484 KTA1268 *HT100340R
Q203L 4822 130 11484 KTA1268 *HT100340R
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
Q203R 4822 130 11484 KTA1268 *HT100340R
Q203SL 4822 130 11484 KTA1268 *HT100340R
Q203SR 4822 130 11484 KTA1268 *HT100340R
Q204C 4822 130 11484 KTA1268 *HT100340R
Q204L 4822 130 11484 KTA1268 *HT100340R
Q204R 4822 130 11484 KTA1268 *HT100340R
Q204SL 4822 130 11484 KTA1268 *HT100340R
Q204SR 4822 130 11484 KTA1268 *HT100340R
Q205C 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
Q205L 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
Q205R 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
Q205SL 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
Q205SR 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
Q206C 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
Q206L 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
Q206R 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
Q206SL 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
Q206SR 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
Q207C 4822 130 11484 KTA1268 *HT100340R
Q207L 4822 130 11484 KTA1268 *HT100340R
Q207R 4822 130 11484 KTA1268 *HT100340R
Q207SL 4822 130 11484 KTA1268 *HT100340R
Q207SR 4822 130 11484 KTA1268 *HT100340R
Q208C 4822 130 11485 2SA1360 *HT100350R
Q208L 4822 130 11485 2SA1360 *HT100350R
Q208R 4822 130 11485 2SA1360 *HT100350R
Q208SL 4822 130 11485 2SA1360 *HT100350R
Q208SR 4822 130 11485 2SA1360 *HT100350R
Q209C 4822 130 61009 2SC3423 *HT300500R
Q209L 4822 130 61009 2SC3423 *HT300500R
Q209R 4822 130 61009 2SC3423 *HT300500R
Q209SL 4822 130 61009 2SC3423 *HT300500R
Q209SR 4822 130 61009 2SC3423 *HT300500R
Q210C 4822 130 42431 2SC1740 HT317402F0
Q210L 4822 130 42431 2SC1740 HT317402F0
Q210R 4822 130 42431 2SC1740 HT317402F0
Q210SL 4822 130 42431 2SC1740 HT317402F0
Q210SR 4822 130 42431 2SC1740 HT317402F0
Q211C 4822 130 10856 2SC4883 *HT300450R
Q211L 4822 130 10856 2SC4883 *HT300450R
Q211R 4822 130 10856 2SC4883 *HT300450R
Q211SL 4822 130 10856 2SC4883 *HT300450R
Q211SR 4822 130 10856 2SC4883 *HT300450R
Q212C 4822 130 10855 2SA1859 *HT100270R
Q212L 4822 130 10855 2SA1859 *HT100270R
Q212R 4822 130 10855 2SA1859 *HT100270R
Q212SL 4822 130 10855 2SA1859 *HT100270R
Q212SR 4822 130 10855 2SA1859 *HT100270R
Q213C 4822 130 41743 2SA1491Y *HT100280R
Q213L 4822 130 41743 2SA1491Y *HT100280R
Q213R 4822 130 41743 2SA1491Y *HT100280R
Q213SL 4822 130 41743 2SA1491Y *HT100280R
Q213SR 4822 130 41743 2SA1491Y *HT100280R
Q214C 4822 130 41744 2SC3855Y *HT300460R
Q214L 4822 130 41744 2SC3855Y *HT300460R
Q214R 4822 130 41744 2SC3855Y *HT300460R
Q214SL 4822 130 41744 2SC3855Y *HT300460R
Q214SR 4822 130 41744 2SC3855Y *HT300460R
Q215C 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
Q215L 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
Q215R 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
Q215SL 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
Q215SR 4822 130 43233 KTC3200 (KTC2240BL) HT322402A1
RESISTORS
R201C nsp 1k
Ω
1/5W J METAL nsp
R201L nsp 1k
Ω
1/5W J METAL nsp
R201R nsp 1k
Ω
1/5W J METAL nsp
R201SL nsp 1k
Ω
1/5W J METAL nsp
R201SR nsp 1k
Ω
1/5W J METAL nsp
R202C nsp 33k
Ω
1/5W J nsp
R202L nsp 33k
Ω
1/5W J nsp
R202R nsp 33k
Ω
1/5W J nsp
R202SL nsp 33k
Ω
1/5W J nsp
R202SR nsp 33k
Ω
1/5W J nsp
R203C nsp 180
Ω
1/5W J METAL nsp
R203L nsp 180
Ω
1/5W J METAL nsp
R203R nsp 180
Ω
1/5W J METAL nsp
R203SL nsp 180
Ω
1/5W J METAL nsp
R203SR nsp 180
Ω
1/5W J METAL nsp
R204C nsp 180
Ω
1/5W J METAL nsp
R204L nsp 180
Ω
1/5W J METAL nsp
R204R nsp 180
Ω
1/5W J METAL nsp
R204SL nsp 180
Ω
1/5W J METAL nsp
R204SR nsp 180
Ω
1/5W J METAL nsp
R205C nsp 1.5k
Ω
1/5W J METAL nsp
R205L nsp 1.5k
Ω
1/5W J METAL nsp
R205R nsp 1.5k
Ω
1/5W J METAL nsp
R205SL nsp 1.5k
Ω
1/5W J METAL nsp
R205SR nsp 1.5k
Ω
1/5W J METAL nsp
R206C nsp 1.5k
Ω
1/5W J METAL nsp
R206L nsp 1.5k
Ω
1/5W J METAL nsp
R206R nsp 1.5k
Ω
1/5W J METAL nsp
R206SL nsp 1.5k
Ω
1/5W J METAL nsp
R206SR nsp 1.5k
Ω
1/5W J METAL nsp
R208C nsp 15k
Ω
1/5W J nsp
R208L nsp 15k
Ω
1/5W J nsp
R208R nsp 15k
Ω
1/5W J nsp
R208SL nsp 15k
Ω
1/5W J nsp
R208SR nsp 15k
Ω
1/5W J nsp
R209C nsp 220
Ω
1/5W J METAL nsp
R209L nsp 220
Ω
1/5W J METAL nsp
R209R nsp 220
Ω
1/5W J METAL nsp
R209SL nsp 220
Ω
1/5W J METAL nsp
R209SR nsp 220
Ω
1/5W J METAL nsp
R210C nsp 10k
Ω
1/5W J nsp
R210L nsp 10k
Ω
1/5W J nsp
R210R nsp 10k
Ω
1/5W J nsp
R210SL nsp 10k
Ω
1/5W J nsp
R210SR nsp 10k
Ω
1/5W J nsp
R211C nsp 33k
Ω
1/5W J nsp
R211L nsp 33k
Ω
1/5W J nsp
R211R nsp 33k
Ω
1/5W J nsp
R211SL nsp 33k
Ω
1/5W J nsp
R211SR nsp 33k
Ω
1/5W J nsp
R212C nsp 1.5k
Ω
1/5W J METAL nsp
R212L nsp 1.5k
Ω
1/5W J METAL nsp
R212R nsp 1.5k
Ω
1/5W J METAL nsp
R212SL nsp 1.5k
Ω
1/5W J METAL nsp
R212SR nsp 1.5k
Ω
1/5W J METAL nsp
R213C nsp 33k
Ω
1/5W J nsp
R213L nsp 33k
Ω
1/5W J nsp
R213R nsp 33k
Ω
1/5W J nsp
R213SL nsp 33k
Ω
1/5W J nsp
R213SR nsp 33k
Ω
1/5W J nsp
R214C nsp 560
Ω
1/5W J METAL nsp
R214L nsp 560
Ω
1/5W J METAL nsp
R214R nsp 560
Ω
1/5W J METAL nsp
R214SL nsp 560
Ω
1/5W J METAL nsp
R214SR nsp 560
Ω
1/5W J METAL nsp
R215C nsp JUMPER nsp
R215L nsp JUMPER nsp
R215R nsp JUMPER nsp
R215SL nsp JUMPER nsp
R215SR nsp JUMPER nsp
R216C nsp 560
Ω
1/5W J METAL nsp
R216L nsp 560
Ω
1/5W J METAL nsp
R216R nsp 560
Ω
1/5W J METAL nsp
R216SL nsp 560
Ω
1/5W J METAL nsp
R216SR nsp 560
Ω
1/5W J METAL nsp
R217C nsp 560
Ω
1/5W J METAL nsp
R217L nsp 560
Ω
1/5W J METAL nsp
R217R nsp 560
Ω
1/5W J METAL nsp
R217SL nsp 560
Ω
1/5W J METAL nsp
R217SR nsp 560
Ω
1/5W J METAL nsp
52 53
