Marantz SR480 - Page 29

POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
C514C nsp ELECT 4.7
µ
F 16V M nsp
C514W nsp ELECT 4.7
µ
F 16V M nsp
C515C nsp ELECT 4.7
µ
F 16V M nsp
C515W nsp ELECT 4.7
µ
F 16V M nsp
C516C nsp CER. 100 pF 50V J CHIP nsp
C516W nsp CER. 100 pF 50V J CHIP nsp
C517C nsp CER. 47 pF 50V J CHIP nsp
C517W nsp CER. 47 pF 50V J CHIP nsp
C518C nsp ELECT 10
µ
F 16V M nsp
C518W nsp ELECT 10
µ
F 16V M nsp
C519 nsp ELECT 47
µ
F 25V M nsp
C521 nsp ELECT 47
µ
F 25V M nsp
C523SL nsp ELECT 0.47
µ
F 50V M nsp
C523SR nsp ELECT 0.47
µ
F 50V M nsp
C524SL nsp CER. 22 pF 50V J CHIP nsp
C524SR nsp CER. 22 pF 50V J CHIP nsp
C525SL nsp ELECT 4.7
µ
F 16V M nsp
C525SR nsp ELECT 4.7
µ
F 16V M nsp
C526SL nsp ELECT 4.7
µ
F 16V M nsp
C526SR nsp ELECT 4.7
µ
F 16V M nsp
C527SL nsp CER. 100 pF 50V J CHIP nsp
C527SR nsp CER. 100 pF 50V J CHIP nsp
C528SL nsp CER. 47 pF 50V J CHIP nsp
C528SR nsp CER. 47 pF 50V J CHIP nsp
C529SL nsp ELECT 10
µ
F 16V M nsp
C529SR nsp ELECT 10
µ
F 16V M nsp
C530 nsp ELECT 47
µ
F 25V M nsp
C532 nsp ELECT 47
µ
F 25V M nsp
C534 nsp CER. 100 pF 50V J CHIP nsp
C534C nsp CER. 100 pF 50V J CHIP nsp
C534L nsp CER. 100 pF 50V J CHIP nsp
C534R nsp CER. 100 pF 50V J CHIP nsp
C534SL nsp CER. 100 pF 50V J CHIP nsp
C534SR nsp CER. 100 pF 50V J CHIP nsp
C534W nsp CER. 100 pF 50V J CHIP nsp
C535
nsp ELECT 47
µ
F 25V M nsp
C540
C541 /01/02 nsp CER. 100 pF 50V J CHIP nsp
C542 nsp ELECT 4.7
µ
F 16V M nsp
C543 nsp CER. 100 pF 50V J CHIP nsp
C544 nsp ELECT 10
µ
F 16V M nsp
C545 /01/02 nsp CER. 100 pF 50V J CHIP nsp
C546 nsp ELECT 4.7
µ
F 16V M nsp
C547 nsp CER. 100 pF 50V J CHIP nsp
C548 nsp ELECT 10
µ
F 16V M nsp
C549 /01/02 nsp CER. 100 pF 50V J CHIP nsp
C550 nsp ELECT 4.7
µ
F 16V M nsp
C551 nsp CER. 100 pF 50V J CHIP nsp
C552 nsp ELECT 1
µ
F 50V M nsp
C553 /01/02 nsp CER. 100 pF 50V J CHIP nsp
C554 nsp ELECT 4.7
µ
F 16V M nsp
C555 nsp CER. 100 pF 50V J CHIP nsp
C556 nsp ELECT 1
µ
F 50V M nsp
C557 /01/02 nsp CER. 100 pF 50V J CHIP nsp
C558 nsp ELECT 4.7
µ
F 16V M nsp
C559 nsp CER. 100 pF 50V J CHIP nsp
C560 nsp ELECT 10
µ
F 16V M nsp
C561 /01/02 nsp CER. 100 pF 50V J CHIP nsp
C562 nsp ELECT 4.7
µ
F 16V M nsp
C563 nsp CER. 100 pF 50V J CHIP nsp
C564 nsp ELECT 10
µ
F 16V M nsp
C570 nsp CER. 0.1
µ
F 50V J CHIP nsp
C571 nsp CER. 0.1
µ
F 50V J CHIP nsp
CONNECTORS
CN501 nsp CONNECTOR 2.0MM (12P) nsp
CN502 nsp CONNECTOR 2.0MM (15P) nsp
CN504 nsp CONNECTOR (10P) nsp
CP503 nsp CONNECTOR 2.0MM (10P) nsp
CN505 nsp CONNECTOR 2.0MM (12P) nsp
CN02 MZ00 nsp CONNECTOR 2.0MM (3P) nsp
DIODES
D501 4822 130 82703 ZENER UZ5.1V BSB *HD301080R
D502 4822 130 32778 1SS133T HD20015210
D503 4822 130 32778 1SS133T HD20015210
INTEGRATED CIRCUITS
IC501 4822 209 31618 LC7536 *HC104390R
IC502 4822 209 91029 KIA4559P *HC103590R
IC503 4822 209 91029 KIA4559P *HC103590R
IC504 4822 209 31618 LC7536 *HC104390R
IC505 4822 209 91029 KIA4559P *HC103590R
IC506 4822 209 91029 KIA4559P *HC103590R
IC507 4822 209 31618 LC7536 *HC104390R
IC508
4822 209 91029 KIA4559P *HC103590R
IC512
TRANSISTORS
Q501 4822 130 62787 DTA114YS *BA000720R
Q502 4822 130 11489 KTD1302 *HT400370R
Q503 4822 130 11489 KTD1302 *HT400370R
Q504 4822 130 62787 DTA114YS *BA000720R
Q505 4822 130 11489 KTD1302 *HT400370R
Q506 4822 130 62787 DTA114YS *BA000720R
Q507 4822 130 11489 KTD1302 *HT400370R
Q508 4822 130 62787 DTA114YS *BA000720R
Q509 4822 130 11489 KTD1302 *HT400370R
Q510 4822 130 11489 KTD1302 *HT400370R
Q511 4822 130 43546 2SK117Y HF201172B0
Q512 4822 130 43546 2SK117Y HF201172B0
Q513 4822 130 43546 2SK117Y HF201172B0
RESISOTORS
R501L nsp 820k
Ω
1/10W J CHIP nsp
R501R nsp 820k
Ω
1/10W J CHIP nsp
R502L nsp 100k
Ω
1/10W J CHIP nsp
R502R nsp 100k
Ω
1/10W J CHIP nsp
R503L nsp 10k
Ω
1/10W J CHIP nsp
R503R nsp 10k
Ω
1/10W J CHIP nsp
R504L nsp 1k
Ω
1/10W J CHIP nsp
R504R nsp 1k
Ω
1/10W J CHIP nsp
R505 nsp 1k
Ω
1/5W J METAL nsp
R506 nsp 1k
Ω
1/5W J METAL nsp
R507 nsp 1k
Ω
1/5W J METAL nsp
R508 nsp 2.2k
Ω
1/5W J METAL nsp
R509 nsp 47
Ω
1/5W J METAL nsp
R510 nsp 47
Ω
1/5W J METAL nsp
R511L nsp 1k
Ω
1/5W J METAL nsp
R511R nsp 1k
Ω
1/5W J METAL nsp
R512C nsp 820k
Ω
1/10W J CHIP nsp
R512W nsp 820k
Ω
1/10W J CHIP nsp
R513C nsp 100k
Ω
1/10W J CHIP nsp
R513W nsp 100k
Ω
1/10W J CHIP nsp
R514C nsp 2k
Ω
1/10W J CHIP nsp
R514W nsp 2k
Ω
1/10W J CHIP nsp
R515C nsp 12k
Ω
1/10W J CHIP nsp
R515W nsp 10k
Ω
1/10W J CHIP nsp
R516C nsp 2.2k
Ω
1/10W J CHIP nsp
R516W nsp 2.2k
Ω
1/10W J CHIP nsp
R517C nsp 3.3k
Ω
1/10W J CHIP nsp
R517W nsp 3.3k
Ω
1/10W J CHIP nsp
R518 nsp 47
Ω
1/5W J METAL nsp
R520 nsp 47
Ω
1/5W J METAL nsp
R522 nsp 1.5k
Ω
1/5W J METAL nsp
R523 nsp 3.3M
Ω
1/10W J CHIP nsp
R524 nsp 100k
Ω
1/5W J nsp
R527 nsp 1k
Ω
1/5W J METAL nsp
R528SL nsp 820k
Ω
1/10W J CHIP nsp
R528SR nsp 820k
Ω
1/10W J CHIP nsp
R529SL nsp 100k
Ω
1/10W J CHIP nsp
R529SR nsp 100k
Ω
1/10W J CHIP nsp
R530SL nsp 2k
Ω
1/10W J CHIP nsp
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
DIODES
D301
4822 130 32778
1SS133T HD20015210
D311
INTEGRATED CIRCUITS
IC301
4822 209 17499
µ
PD78044FGF-088-3B9 DWP478
*HU100320R
LEDS
LED301
4822 130 11464
SLR-56URCF14 *HI100780R
LED306
TRANSISTORS
Q301
4822 130 11483
BKTC3199
QP13010103
Q302
4822 130 62787
DTA114YS *BA000720R
Q303
4822 130 62503
DTC114YS *BA000210R
Q312
RESISOTORS
R301 nsp 100k
Ω
1/5W J nsp
R302 nsp 100k
Ω
1/5W J nsp
R303 nsp 10k
Ω
1/5W J nsp
R304 nsp 330k
Ω
1/5W J METAL nsp
R305L SR480 nsp 47k
Ω
1/5W J nsp
R306H PM488 nsp 47k
Ω
1/5W J nsp
R307L SR480U nsp 47k
Ω
1/5W J nsp
R308H
SR480/01
Nsp 47k
Ω
1/5W J nsp
R308H
SR480/02
Nsp 47k
Ω
1/5W J nsp
R309L PM488 Nsp 47k
Ω
1/5W J Nsp
R309L
SR480/01
Nsp 47k
Ω
1/5W J Nsp
R309L
SR480U Nsp 47k
Ω
1/5W J Nsp
R310H
SR480/02
Nsp 47k
Ω
1/5W J nsp
R311 nsp 100k
Ω
1/5W J nsp
R312 SR480 nsp 10k
Ω
1/5W J nsp
R313 SR480 nsp 10k
Ω
1/5W Jnsp
R314 SR480 nsp 10k
Ω
1/5W J nsp
R315 nsp 100k
Ω
1/5W J nsp
R316 nsp 100k
Ω
1/5W J nsp
R317
nsp 68k
Ω
1/5W J nsp
R318 nsp 68k
Ω
1/5W J nsp
R319
4822 052 10471
470
Ω
1/5W J METAL
GG05471160
R320 nsp 47k
Ω
1/5W J nsp
R321 nsp 330
Ω
1/5W J METAL nsp
R322
nsp 220
Ω
1/5W J METAL nsp
R327
R328 nsp
nsp 100k
Ω
1/5W J nsp
R335
R336
nsp 4.7k
Ω
1/5W J METAL nsp
R339 nsp
R340
PM488 nsp 47k
Ω
1/5W J nsp
R345
R347
PM488 nsp 47k
Ω
1/5W J nsp
R348 nsp 47k
Ω
1/5W
J nsp
R613 nsp 220
Ω
1/5W J METAL nsp
SWITCH
SW301 SR480/02 4822 276 13661
TACK SW *SP000610R
SW302 SR480/02 4822 276 13661
TACK SW *SP000610R
SW303 SR480/02 4822 276 13661
TACK SW *SP000610R
SW304
SR480
4822 276 13661
TACK SW *SP000610R
SW305 4822 276 13661
TACK SW *SP000610R
SW306
SR480
4822 276 14109
TACK SW *SP000900R
SW307 4822 276 13661
TACK SW *SP000610R
SW308
SR480
4822 276 14109
TACK SW *SP000900R
SW309
SR480
4822 276 13661
TACK SW *SP000610R
SW310
SR480
4822 276 13661
TACK SW *SP000610R
SW311
SR480
4822 276 13661
TACK SW *SP000610R
SW312 4822 276 14109
TACK SW *SP000900R
SW313 4822 276 14109
TACK SW *SP000900R
SW314 4822 276 13661
TACK SW *SP000610R
SW315 4822 276 13661
TACK SW *SP000610R
SW316
4822 276 14109
TACK SW *SP000900R
SW319
SW320
4822 276 13661
TACK SW *SP000610R
SW331
MISCELLANEOUS
RMC
4822 130 11639
MODULE CRV1G343-185BD (3P)
*HW100440R
XTAL301
4822 242 73769
RESONATOR CST4M19 *FQ000110R
FL
4822 135 00289
FL DISPLAY
*HQ300340R
VOL. ENC CIRCUIT BOARD
C320 nsp CER. CAP. 820 pF 50V K nsp
C321 nsp CER. CAP. 820 pF 50V K nsp
VOL.ENC 4822 277 11645
S/W ROTARY ENCODER *SR000080R
POWER SW CIRCUIT BOARD
CN751 nsp CONNECTOR (2P) nsp
SW752 4822 276 13807
SW ESB-8279V *SP000680R
TONE CIRCUIT BOARD
CAPACITORS
C601L nsp ELECT 4.7
µ
F 16V M nsp
C601R nsp ELECT 4.7
µ
F 16V M nsp
C602L nsp CER. 100 pF 50V J nsp
C602R nsp CER. 100 pF 50V J nsp
C603L nsp CER. 47 pF 50V J nsp
C603R nsp CER. 47 pF 50V J nsp
C604L nsp ELECT 4.7
µ
F 16V M nsp
C604R nsp ELECT 4.7
µ
F 16V M nsp
C605L nsp ELECT 4.7
µ
F 16V M nsp
C605R nsp ELECT 4.7
µ
F 16V M nsp
C606L nsp FILM 0.018
µ
F 63V J nsp
C606R nsp FILM 0.018
µ
F 63V J nsp
C607L nsp FILM 0.082
µ
F 63V J nsp
C607R nsp FILM 0.082
µ
F 63V J nsp
C608L nsp FILM 0.0033
µ
F 63V J nsp
C608R nsp FILM 0.0033
µ
F 63V J nsp
C609L nsp FILM 0.018
µ
F 63V J nsp
C609R nsp FILM 0.018
µ
F 63V J nsp
C610
nsp ELECT 47
µ
F
16V M nsp
C611 nsp ELECT 47
µ
F 16V M nsp
C612L nsp CER. 220 pF 50V K nsp
C612R nsp CER. 220 pF 50V K nsp
CONNECTOR
CP602 nsp CONNECTOR (10P) 300MM nsp
INTEGRATED CIRCUIT
IC601
4822 209 73064
NJM2068 HC10053090
RESISTORS
R601L nsp 1k
Ω
1/5W J METAL nsp
R601R nsp 1k
Ω
1/5W J METAL nsp
R602L nsp 100k
Ω
1/5W J nsp
R602R nsp 100k
Ω
1/5W J nsp
R603L nsp 1M
Ω
1/5W J nsp
R603R nsp 1M
Ω
1/5W J nsp
R604L
nsp 47k
Ω
1/5W J nsp
R604R nsp 47k
Ω
1/5W J nsp
R605L
4822 052 10471
470
Ω
1/5W J METAL
GG05471160
R605R
4822 052 10471
470
Ω
1/5W J METAL
GG05471160
R606L nsp 100k
Ω
1/5W Jnsp
R606R nsp 100k
Ω
1/5W
J nsp
R607L nsp 2.2k
Ω
1/5W J METAL nsp
R607R nsp 2.2k
Ω
1/5W J METAL nsp
R608L nsp 22k
Ω
1/5W Jnsp
R608R nsp 22k
Ω
1/5W J nsp
R609L nsp 3.9k
Ω
1/5W J METAL nsp
R609R nsp 3.9k
Ω
1/5W J METAL nsp
5558
