Marantz SR480 - Page 30

POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
C455RD
/01/02 nsp CER. 27 pF 50V J nsp
C456LD
/01/02 nsp CER. 100 pF 50V J nsp
C456RD
/01/02 nsp CER. 100 pF 50V J nsp
C457LD
/01/02 nsp CER. 100 pF 50V J nsp
C457RD
/01/02 nsp CER. 100 pF 50V J nsp
C458LD
/01/02 nsp CER. 100 pF 50V J nsp
C458RD
/01/02 nsp CER. 100 pF 50V J nsp
C459LD
/01/02 nsp CER. 100 pF 50V J nsp
C459RD
/01/02 nsp CER. 100 pF 50V J nsp
C460 nsp ELECT 47
µ
F 25V M nsp
C461 nsp ELECT 1
µ
F
50V J nsp
C463
nsp ELECT 47
µ
F 25V M nsp
C466
nsp CER.CHIP 100 pF 50V J nsp
C469
C470
nsp ELECT 33
µ
F 25V M nsp
C484
C485
nsp ELECT 10
µ
F 16V M nsp
C489
C491 nsp CER.CHIP 0.1
µ
F 50V Z nsp
C901SL
nsp FILM 0.047
µ
F 100V J nsp
C901SR
nsp FILM 0.047
µ
F 100V J nsp
CONNECTORS
CN451 nsp CONNECTOR 2.0MM (16P) nsp
CP601 nsp CONNECTOR 2.0MM (5P) nsp
DIODES
D450
4822 130 32778
1SS133T HD20015210
D451
4822 130 32778
1SS133T HD20015210
INTEGRATED CIRCUITS
IC450
4822 209 72748
LC7821 HC10228030
IC451
4822 209 90745
BA7625
*HC103900R
IC452
4822 209 32216
MC14053BCP
*HC104380R
IC453
4822 209 15015
MC14094BCP
*HC103850R
MISCELLANEOUS
JACK402 4822 265 11617
TERMINAL RCA 4PIN *YT001600R
JACK403 4822 267 41252
TERMINAL RCA 6PIN *YT001040R
JACK451 4822 265 11474
TERMINAL RCA 9PIN *YT001310R
JACK452 4822 265 11475
TERMINAL RCA 9PIN *YT001320R
JACK901 4822 265 11473
SPEAKER TERMINAL 2P *YT001300R
JACK902 4822 265 11472
SPEAKER TERMINAL 8P *YT001290R
TRANSISTORS
Q450
4822 130 11482
BKTA1267 *HT100330R
Q451
4822 130 11482
BKTA1267 *HT100330R
RESISTORS CHIP
R451L nsp 470
Ω
1/10W J nsp
R451R nsp 470
Ω
1/10W J nsp
R452L nsp 470
Ω
1/10W J nsp
R452R nsp 470
Ω
1/10W
J nsp
R453L
nsp 470
Ω
1/10W Jnsp
R453R nsp 470
Ω
1/10W J nsp
R454L nsp 470
Ω
1/10W Jnsp
R454R nsp 470
Ω
1/10W J nsp
R455L nsp 470
Ω
1/10W J nsp
R455R nsp 470
Ω
1/10W J nsp
R456 nsp 220
Ω
1/10W J nsp
R457 nsp
100k
Ω
1/5W J NON CHIP
nsp
R458
nsp 1k
Ω
1/10W J nsp
R463
R464
nsp 3.3k
Ω
1/10W J nsp
R467
R468 nsp 3.3k
Ω
1/10W J nsp
R469 nsp 3.3
Ω
1/10W J nsp
R470
nsp 220
Ω
1/10W J nsp
R471 nsp 100
Ω
1/10W J nsp
R472 nsp 100
Ω
1/10W J nsp
R473
nsp 75
Ω
1/10W J nsp
R478
R479 nsp 100
Ω
1/10W J nsp
R480 nsp 100
Ω
1/10W J nsp
R481
nsp 4.7
Ω
1/10W J nsp
R485
SPKR CIRCUIT BOARD
CAPACITORS
C901C nsp FILM 0.047
µ
F 100V J nsp
C901L nsp FILM 0.047
µ
F 100V J nsp
C901R nsp FILM 0.047
µ
F 100V J nsp
C902CD
/01/02 nsp CER. 2200 pF 16V X nsp
C902LD
/01/02 nsp CER. 2200 pF 16V X nsp
C902RD
/01/02 nsp CER. 2200 pF 16V X nsp
C902SLD
/01/02 nsp CER. 2200 pF 16V X nsp
C902SRD
/01/02 nsp CER. 2200 pF 16V X nsp
C903CD
/01/02 nsp CER. 2200 pF 16V X nsp
C903LD
/01/02 nsp CER. 2200 pF 16V X nsp
C903RD
/01/02 nsp CER. 2200 pF 16V X nsp
C903SLD
/01/02 nsp CER. 2200 pF 16V X nsp
C903SRD
/01/02 nsp CER. 2200 pF 16V X nsp
CONNECTORS
CN901 nsp CONNECTOR 2.5MM (11P) nsp
CP701OUT
nsp CONNECTOR 3.96MM nsp
CN01 MZ00 nsp CONNECTOR 3P nsp
COILS
L901SL 4822 157 71892
COIL J9000031 *LC106490R
L901SR 4822 157 71892
COIL J9000031 *LC106490R
RESISTORS
R901C
4822 053 10109
10
Ω
1W J METAL
GA05100010
R901L
4822 053 10109
10
Ω
1W J METAL
GA05100010
R901R
4822 053 10109
10
Ω
1W J METAL
GA05100010
R901SL 4822 053 10109
10
Ω
1W J METAL
GA05100010
R901SR 4822 053 10109
10
Ω
1W J METAL
GA05100010
R902SL 4822 053 10109
10
Ω
1W J METAL
GA05100010
R902SR 4822 053 10109
10
Ω
1W J METAL
GA05100010
VOL SEL CIRCUIT BOARD
CP151 /01 nsp CONNECTOR 3.96MM (4P) nsp
CP152 /01 nsp CONNECTOR 3.96MM (2P) nsp
F151 /01
4822 252 11371
FUSE T5A/250V *FS000610R
SW151
/01
4822 273 10322
VOLTAGE SEL. SW *SS000520R
VOLUME CIRCUIT BOARD
CAPACITORS
C501L nsp CER. 22 pF 50V J CHIP nsp
C501R nsp CER. 22 pF 50V J CHIP nsp
C502L
nsp ELECT 0.47
µ
F 50V M nsp
C502R nsp ELECT 0.47
µ
F 50V M nsp
C503L nsp ELECT 4.7
µ
F 16V M nsp
C503R nsp ELECT 4.7
µ
F 16V M nsp
C504L nsp ELECT 4.7
µ
F 16V M nsp
C504R nsp ELECT 4.7
µ
F 16V M nsp
C505L nsp CER. 100 pF 50V J CHIP nsp
C505R nsp CER. 100 pF 50V J CHIP nsp
C506L nsp ELECT 10
µ
F 16V M nsp
C506R nsp ELECT 10
µ
F 16V M nsp
C507L nsp CER. 47 pF 50V J CHIP nsp
C507R nsp CER. 47 pF 50V J CHIP nsp
C509 nsp ELECT 47
µ
F 25V M nsp
C510 nsp ELECT 47
µ
F
25V M nsp
C511 nsp CER. 100 pF 50V J CHIP nsp
C512C
nsp CER. 22 pF 50V J CHIP nsp
C512W
nsp CER. 22 pF 50V J CHIP nsp
C513C nsp ELECT 0.47
µ
F 50V M nsp
C513W
nsp ELECT 0.47
µ
F 50V M nsp
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
R610L nsp 2.2k
Ω
1/5W J METAL nsp
R610R nsp 2.2k
Ω
1/5W J METAL nsp
R611L nsp 560
Ω
1/5W J METAL nsp
R611R nsp 560
Ω
1/5W J METAL nsp
R612 nsp 220
Ω
1/5W J METAL nsp
VOLUME
VR601 4822 101 11754 ROTARY VR 100K (TREBLE/BASS) *RM000240R
VR602 4822 101 11754 ROTARY VR 100K (BALANCE) *RM000240R
VR603 4822 101 11755 ROTARY VR 100K (ENCODER) *RM000250R
AUX VIDEO CIRCUIT BOARD
CAPACITORS
C630L /01/02 nsp CER. 100 pF 50V J nsp
C630R /01/02 nsp CER. 100 pF 50V J nsp
C631L /01/02 nsp CER. 100 pF 50V J nsp
C631R /01/02 nsp CER. 100 pF 50V J nsp
C632 nsp CER. 100 pF 50V J nsp
C633 nsp ELECT 33
µ
F 16V M nsp
C634 nsp ELECT 10
µ
F 25V M nsp
C636 nsp CER 0.1
µ
F 50V Z nsp
C637 nsp CER. 0.1
µ
F 50V Z nsp
CONNECTOR
CP601 nsp CONNECTOR 2.0MM (5P) nsp
RESISTORS
R630L 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R630R 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R631 nsp 75
Ω
1/5W J METAL nsp
R632 nsp 4.7
Ω
1/5W J METAL nsp
MISCELLANEOUS
4822 265 31321 TERMINAL RCA 3PIN *YT000870R
nsp WIRE LUG #24BK200 LF 0.5/0 nsp
HP/SPK CIRCUIT BOARD
CAPACITORS
C635L nsp CER. 560 pF 50V K nsp
C635R nsp CER. 560 pF 50V K nsp
RESISTORS
R632L 4822 053 11221 470
Ω
2W J METAL GA05221020
R632R 4822 053 11221 470
Ω
2W J METAL GA05221020
R633L nsp 15k
Ω
1/5W J nsp
R633R nsp 15k
Ω
1/5W J nsp
MISCELLANEOUS
SW701 4822 276 13658 SW PUSH *SP000620R
CN701 nsp CONNECTOR (5P) nsp
JK701 4822 267 31992 JACK D6.5 *YT000830R
nsp WIRE LUG #24BK200 LF 0.5/0 nsp
INPUT CIRCUIT BOARD
CAPACITORS
C400LD /01/02 nsp CER. 100 pF 50V J nsp
C400RD /01/02 nsp CER. 100 pF 50V J nsp
C401LD /01/02 nsp CER. 100 pF 50V J nsp
C401RD /01/02 nsp CER. 100 pF 50V J nsp
C402LD /01/02 nsp CER. 100 pF 50V J nsp
C402RD /01/02 nsp CER. 100 pF 50V J nsp
C403LD /01/02 nsp CER. 100 pF 50V J nsp
C403RD /01/02 nsp CER. 100 pF 50V J nsp
C404LD /01/02 nsp CER. 100 pF 50V J nsp
C404RD /01/02 nsp CER. 100 pF 50V J nsp
C405LD /01/02 nsp CER. 100 pF 50V J nsp
C405RD /01/02 nsp CER. 100 pF 50V J nsp
C406LD /01/02 nsp CER. 27 pF 50V J nsp
C406RD /01/02 nsp CER. 27 pF 50V J nsp
C407LD /01/02 nsp CER. 100 pF 50V J nsp
C407RD /01/02 nsp CER. 100 pF 50V J nsp
C408LD /01/02 nsp CER. 100 pF 50V J nsp
C408RD /01/02 nsp CER. 100 pF 50V J nsp
C409LD /01/02 nsp CER. 100 pF 50V J nsp
C409RD /01/02 nsp CER. 100 pF 50V J nsp
C410LD /01/02 nsp CER. 27 pF 50V J nsp
C410RD /01/02 nsp CER. 27 pF 50V J nsp
C411 nsp ELECT 47
µ
F 25V M nsp
C412 nsp ELECT 1
µ
F 50V J nsp
C413LD /01/02 nsp CER. 100 pF 50V J nsp
C413RD /01/02 nsp CER. 100 pF 50V J nsp
C414 nsp ELECT 47
µ
F 25V M nsp
C417 nsp CER. 100 pF 50V J nsp
C418 nsp ELECT 47
µ
F 25V M nsp
C421 nsp ELECT 47
µ
F 25V M nsp
C422L nsp ELECT 4.7
µ
F 50V M nsp
C422R nsp ELECT 4.7
µ
F 50V M nsp
C423L nsp ELECT 4.7
µ
F 50V M nsp
C423R nsp ELECT 4.7
µ
F 50V M nsp
CONNECTORS
CN401 nsp CONNECTOR 2.0MM (8P) nsp
CN402 nsp CONNECTOR 2.0MM (8P) nsp
DIODE
D401 4822 130 32778 1SS133T HD20015210
INTEGRATED CIRCUITS
IC401 4822 209 72748 LC7821 HC10228030
IC402 4822 209 91029 KIA75559P (KIA4559P) *HC103590R
RESISTORS
R400L 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R400R 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R401L 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R401R nsp 470
Ω
1/10W J METAL nsp
R402L nsp 470
Ω
1/10W J METAL nsp
R402R nsp 470
Ω
1/10W J METAL nsp
R403L nsp 470
Ω
1/10W J METAL nsp
R403R nsp 470
Ω
1/10W J METAL nsp
R404L nsp 470
Ω
1/10W J METAL nsp
R404R nsp 470
Ω
1/10W J METAL nsp
R405L nsp 1k
Ω
1/10W J METAL nsp
R405R nsp 1k
Ω
1/10W J METAL nsp
R406 nsp 220
Ω
1/5W J METAL nsp
R407 nsp 100k
Ω
1/5W J nsp
R408 nsp 220
Ω
1/5W J METAL nsp
R410 nsp 220
Ω
1/10W J METAL nsp
R411 nsp 220
Ω
1/10W J METAL nsp
R413 nsp 1k
Ω
1/5W J METAL nsp
R414 nsp 1k
Ω
1/10W J METAL nsp
R415 nsp 1k
Ω
1/10W J METAL nsp
R416L nsp 100k
Ω
1/5W J nsp
R416R nsp 100k
Ω
1/5W J nsp
R419L nsp 100k
Ω
1/5W J nsp
R419R nsp 100k
Ω
1/5W J nsp
R431L nsp 1k
Ω
1/5W J METAL nsp
R431R nsp 1k
Ω
1/10W J METAL nsp
R433L 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R433R nsp 470
Ω
1/10W J METAL nsp
R435L nsp 47k
Ω
1/5W J nsp
R435R nsp 47k
Ω
1/5W J nsp
INPUT&VIDEO CIRCUIT BOARD
CAPACITORS
C450LD /01/02 nsp CER. 100 pF 50V J nsp
C450RD /01/02 nsp CER. 100 pF 50V J nsp
C451LD /01/02 nsp CER. 100 pF 50V J nsp
C451RD /01/02 nsp CER. 100 pF 50V J nsp
C452LD /01/02 nsp CER. 100 pF 50V J nsp
C452RD /01/02 nsp CER. 100 pF 50V J nsp
C453LD /01/02 nsp CER. 100 pF 50V J nsp
C453RD /01/02 nsp CER. 100 pF 50V J nsp
C454LD /01/02 nsp CER. 100 pF 50V J nsp
C454RD /01/02 nsp CER. 100 pF 50V J nsp
C455LD /01/02 nsp CER. 27 pF 50V J nsp
