Marantz SR480 - Page 31

POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
INTEGRATED CIRCUITS
IC801 4822 209 83804 LC4966 HC10150030
IC802 4822 209 17502 NJW1102AGF1 *HC104850R
IC803 4822 209 17503 NJU9702G *HC104870R
IC804 4822 209 17504 TC9299P *HC104860R
IC805 4822 209 91029 KIA4559P *HC103590R
IC806 4822 209 91029 KIA4559P *HC103590R
IC807 4822 209 32554 LC78213 HC10310030
TRANSISTORS
Q801 4822 130 62503 DTC114YS *BA000210R
Q802 4822 130 62787 DTA114YS *BA000720R
Q803 4822 130 62503 DTC114YS *BA000210R
RESISTORS
R801L nsp 1k
Ω
1/5W J METAL nsp
R801R nsp 1k
Ω
1/5W J METAL nsp
R802L nsp 100k
Ω
1/5W J nsp
R802R nsp 100k
Ω
1/5W J nsp
R803 nsp 100
Ω
1/5W J METAL nsp
R804 nsp 150k
Ω
1/5W J nsp
R805 nsp 100
Ω
1/5W J METAL nsp
R806 nsp 47k
Ω
1/5W J nsp
R807 nsp 15k
Ω
1/5W J nsp
R808 nsp 7.5k
Ω
1/5W J nsp
R809 nsp 47k
Ω
1/5W J nsp
R810 nsp 15k
Ω
1/5W J nsp
R811 nsp 7.5k
Ω
1/5W J nsp
R812 nsp 22k
Ω
1/5W J nsp
R813 nsp 22k
Ω
1/5W J nsp
R814 nsp 4.7M
Ω
1/5W J nsp
R815 nsp 100
Ω
1/5W J METAL nsp
R816 nsp 100k
Ω
1/5W J nsp
R817 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R818L 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R818R 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R819L nsp 100k
Ω
1/5W J nsp
R819R nsp 100k
Ω
1/5W J nsp
R820C 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R820S 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R821C nsp 47k
Ω
1/5W J nsp
R821S nsp 47k
Ω
1/5W J nsp
R822 nsp 10k
Ω
1/5W J nsp
R823 nsp 20k
Ω
1/5W J nsp
R824 nsp 43k
Ω
1/5W J nsp
R825 nsp 10k
Ω
1/5W J nsp
R826 nsp 4.7k
Ω
1/5W J METAL nsp
R827 nsp 100k
Ω
1/5W J nsp
R828 nsp 15k
Ω
1/5W J nsp
R829 nsp 22k
Ω
1/5W J nsp
R830 nsp 15k
Ω
1/5W J nsp
R831 nsp 330k
Ω
1/5W J nsp
R832 nsp 47
Ω
1/5W J METAL nsp
R833 nsp 1M
Ω
1/5W J nsp
R834 nsp 1k
Ω
1/5W J METAL nsp
R835 nsp 1k
Ω
1/5W J METAL nsp
R836 nsp 1k
Ω
1/5W J METAL nsp
R837 nsp 15k
Ω
1/5W J nsp
R838 nsp 10k
Ω
1/5W J nsp
R839 nsp 22
Ω
1/5W J METAL nsp
R840 nsp 15k
Ω
1/5W J nsp
R841 nsp 22
Ω
1/5W J METAL nsp
R842 nsp 15k
Ω
1/5W J nsp
R843 nsp 10k
Ω
1/5W J nsp
R844 nsp 820
Ω
1/5W J METAL nsp
R845 nsp 820
Ω
1/5W J METAL nsp
R846 nsp 1k
Ω
1/5W J METAL nsp
R847 nsp 1k
Ω
1/5W J METAL nsp
R848 nsp 1k
Ω
1/5W J METAL nsp
R849C 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R849SL 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R849SR 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R850C nsp 56k
Ω
1/5W J nsp
R850SL nsp 100k
Ω
1/5W J nsp
R850SR nsp 100k
Ω
1/5W J nsp
R851C nsp 4.7k
Ω
1/5W J METAL nsp
R851SL nsp 4.7k
Ω
1/5W J METAL nsp
R851SR nsp 4.7k
Ω
1/5W J METAL nsp
R852C nsp 10k
Ω
1/5W J nsp
R852SL nsp 10k
Ω
1/5W J nsp
R852SR nsp 10k
Ω
1/5W J nsp
R853C nsp 100k
Ω
1/5W J nsp
R853SL nsp 10k
Ω
1/5W J nsp
R853SR nsp 10k
Ω
1/5W J nsp
R854
nsp 150
Ω
1/5W J METAL nsp
R857
R858 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R859 nsp 1k
Ω
1/5W J METAL nsp
R860 nsp 1k
Ω
1/5W J METAL nsp
R861 nsp 1k
Ω
1/5W J METAL nsp
!R862 4822 052 10471 470
Ω
1/5W J METAL GG05471160
R863 nsp 100k
Ω
1/5W J nsp
RESONATOR
XTAL801 4822 242 81969 RESONATOR CSA2.00MG *FQ000270R
SUBWOOFER CIRCUIT BOARD
RESISTORS
RM04 MZ00 nsp 10k
Ω
1/5W J nsp
RM01 MZ00 nsp 33k
Ω
1/5W J nsp
RM02 MZ00 nsp 33k
Ω
1/5W J nsp
RM03 MZ00 nsp 33k
Ω
1/5W J nsp
CAPACITORS
CM02 MZ00 nsp FILM 0.22
µ
F 63V J nsp
CM01 MZ00 nsp FILM 0.47
µ
F 63V J nsp
CONNECTORS
CP01 MZ00 nsp CONNECTOR 2.5MM (3P) nsp
CP02 MZ00 nsp CONNECTOR 2.5MM (3P) nsp
TRANSISTOR
QM01 MZ00 4822 130 63211 DTA114TS BA10003210
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
R530SR
nsp 2k
Ω
1/10W J CHIP nsp
R531SL
nsp 12k
Ω
1/10W J CHIP nsp
R531SR
nsp 12k
Ω
1/10W J CHIP nsp
R532SL
nsp 2.2k
Ω
1/10W J CHIP nsp
R532SR
nsp 2.2k
Ω
1/10W J CHIP nsp
R533 nsp 47
Ω
1/5W J CHIP nsp
R533SL
nsp 3.3k
Ω
1/10W J CHIP nsp
R533SR
nsp 3.3k
Ω
1/10W J CHIP nsp
R534SL
nsp 1.5k
Ω
1/10W J CHIP nsp
R534SR
nsp 1.5k
Ω
1/10W J CHIP nsp
R535 nsp 47
Ω
1/5W J CHIP nsp
R535SL
nsp 3.3M
Ω
1/10W J CHIP nsp
R535SR
nsp 3.3M
Ω
1/10W J CHIP nsp
R540C nsp 1k
Ω
1/10W J CHIP nsp
R540L nsp 1k
Ω
1/10W J CHIP nsp
R540R nsp 1k
Ω
1/10W J CHIP nsp
R540SL
nsp 1k
Ω
1/10W J CHIP nsp
R540SR
nsp 1k
Ω
1/10W J CHIP nsp
R540W
nsp 1k
Ω
1/10W J CHIP nsp
R541 nsp 12k
Ω
1/10W J CHIP nsp
R544 SR480 nsp 15k
Ω
1/5W J nsp
R546 nsp 15k
Ω
1/5W J nsp
R548 nsp 12k
Ω
1/10W J CHIP nsp
R551
SR480 nsp 47
Ω
1/5W J METAL nsp
R556
R557 nsp 4.7k
Ω
1/10W J CHIP nsp
R558 nsp 47k
Ω
1/10W J CHIP nsp
R559 nsp 47k
Ω
1/10W J CHIP nsp
R560
nsp 4.7k
Ω
1/10W J CHIP nsp
R563
R564 nsp 47k
Ω
1/10W J CHIP nsp
R565 nsp 47k
Ω
1/10W J CHIP nsp
R567 nsp 4.7k
Ω
1/10W J CHIP nsp
R568 nsp 47k
Ω
1/10W J CHIP nsp
R569 nsp 47k
Ω
1/10W J CHIP nsp
R570 nsp 4.7k
Ω
1/10W J CHIP nsp
R571 nsp 47k
Ω
1/10W J CHIP nsp
R572 nsp 47k
Ω
1/10W J CHIP nsp
R573 nsp 4.7k
Ω
1/10W J CHIP nsp
R574 nsp 47k
Ω
1/10W J CHIP nsp
R575 nsp 47k
Ω
1/10W J CHIP nsp
R577C nsp 3.3k
Ω
1/10W J CHIP nsp
R577L nsp 3.3k
Ω
1/10W J CHIP nsp
R577R nsp 3.3k
Ω
1/10W J CHIP nsp
R577SL
nsp 3.3k
Ω
1/10W J CHIP nsp
R577SR
nsp 3.3k
Ω
1/10W J CHIP nsp
R577W
nsp 3.3k
Ω
1/10W J CHIP nsp
SURROUND CIRCUIT BOARD
CAPACITORS
C801 nsp ELECT 47
µ
F 16V M nsp
C802 nsp ELECT 47
µ
F 16V M nsp
C803 nsp CER. 0.1
µ
F 50V Z nsp
C804L nsp ELECT 47
µ
F 16V M nsp
C804R nsp ELECT 47
µ
F 16V M nsp
C805 nsp
FILM 680 pF 50V J STYLOR
nsp
C806 nsp FILM 0.1
µ
F 63V J nsp
C807 nsp FILM 0.1
µ
F 63V J nsp
C808 nsp
FILM 680 pF 50V J STYLOR
nsp
C809 nsp FILM 0.1
µ
F 63V J nsp
C810 nsp FILM 0.1
µ
F 63V J nsp
C811 nsp ELECT 10
µ
F 50V M nsp
C812 nsp ELECT 10
µ
F 50V M nsp
C813 nsp ELECT 22
µ
F 16V M nsp
C814 nsp ELECT 220
µ
F 16V M nsp
C815 nsp ELECT 47
µ
F 16V M nsp
C816 nsp FILM 0.0047
µ
F 100V J nsp
C817 nsp ELECT 22
µ
F 16V M nsp
C818 nsp ELECT 100
µ
F 10V M nsp
C819L nsp ELECT 1
µ
F 50V M nsp
C819R nsp ELECT 1
µ
F 50V M nsp
C820C nsp ELECT 1
µ
F 50V M nsp
C820S nsp ELECT 1
µ
F 50V M nsp
C821 nsp FILM 0.1
µ
F 63V J nsp
C822 nsp ELECT 1
µ
F 50V M nsp
C823 nsp ELECT 220
µ
F 10V M nsp
C824 nsp CER. 560 pF 50V K nsp
C825 nsp FILM 0.001
µ
F 100V J nsp
C826 nsp FILM 0.0056
µ
F 100V J nsp
C827 nsp FILM 0.047
µ
F 100V J nsp
C828 nsp FILM 0.68
µ
F 63V J nsp
C829 nsp FILM 0.22
µ
F 63V J nsp
C830 nsp FILM 0.22
µ
F 63V J nsp
C831 nsp ELECT 4.7
µ
F 50V M nsp
C832 nsp ELECT 4.7
µ
F 50V M nsp
C833 nsp FILM 0.22
µ
F 63V J nsp
C834 nsp FILM 0.22
µ
F 63V J nsp
C835 nsp FILM 0.1
µ
F 63V J nsp
C836 nsp FILM 0.047
µ
F 100V J nsp
C837 nsp FILM 0.047
µ
F 100V J nsp
C838 nsp FILM 0.1
µ
F 63V J nsp
C839 nsp FILM 0.1
µ
F 63V J nsp
C840 nsp FILM 0.022
µ
F 100V J nsp
C841 nsp FILM 0.022
µ
F 100V J nsp
C842 nsp FILM 0.1
µ
F 63V J nsp
C843 nsp CER. 0.1
µ
F 50V Z nsp
C844 nsp CER. 220 pF 50V K nsp
C845 nsp CER. 220 pF 50V K nsp
C846 nsp CER. 100 pF 50V J nsp
C847 nsp CER. 100 pF 50V J nsp
C848 nsp CER. 100 pF 50V J nsp
C849 nsp ELECT 1
µ
F 50V M nsp
C850 nsp CER. 560 pF 50V K nsp
C851 nsp FILM 0.1
µ
F 63V J nsp
C852 nsp FILM 0.0056
µ
F 100V J nsp
C853 nsp FILM 0.047
µ
F 100V J nsp
C854 nsp FILM 0.047
µ
F 100V J nsp
C855 nsp ELECT 47
µ
F 16V M nsp
C856 nsp FILM 0.1
µ
F 63V J nsp
C857 nsp CER. 560 pF 50V K nsp
C858 nsp FILM 0.0022
µ
F 100V J nsp
C859 nsp ELECT 220
µ
F 10V M nsp
C860 nsp CER. 0.1
µ
F 50V Z nsp
C861 nsp ELECT 47
µ
F 16V M nsp
C862 nsp CER. 0.1
µ
F 50V Z nsp
C863 nsp ELECT 47
µ
F 16V M nsp
C864 nsp CER. 0.1
µ
F 50V Z nsp
C865 nsp CER. 100 pF 50V J nsp
C866 nsp CER. 100 pF 50V J nsp
C867 nsp CER. 100 pF 50V J nsp
C868C nsp ELECT 1
µ
F 50V M nsp
C868SL
nsp ELECT 0.47
µ
F 50V M nsp
C868SR
nsp ELECT 0.47
µ
F 50V M nsp
C869C nsp CER. 47 pF 50V J nsp
C869SL
nsp CER. 680 pF 50V K nsp
C869SR
nsp CER. 680 pF 50V K nsp
C870C nsp ELECT 1
µ
F
50V M nsp
C870SL
nsp ELECT 0.47
µ
F 50V M nsp
C870SR
nsp ELECT 0.47
µ
F 50V M nsp
C871
nsp ELECT 47
µ
F 16V M nsp
C876
C877 nsp ELECT 1
µ
F 50V M nsp
C878 nsp CER. 100 pF 50V J nsp
CONNECTORS
CN505 nsp CONNECTOR WIRE (12P) nsp
CN801 nsp CONNECTOR 2.0MM (14P) nsp
CN802 nsp CONNECTOR 2.0MM (14P) nsp
DIODES
D801
4822 130 11641
ZENER UZ11V
*HD301640R
D802
4822 130 32778
1SS133T HD20015210
