MAINCPU(IC105)Version,DSP(IC111)Version,
HDMICPU(IC61),VersionandSegmentCheck
Mode.
1. 機に電源コードを接続します。
2. POWERON/OFF(STANDBY) ボタンを押し、本機の電
源を入れます。
3. AUTO,EXIT,CLEAR 3 つのボタンを同時に 3 秒以上
押します。
4. FL "SERVICEMODE" 2 秒表示し、次にモデル名と
MAIN マイコン (IC105) を表示します。
5. ENTER ボタンを押すと、ソフトウエアシリアルナン
バーが表示されます。
6. ENTER ボタンを押すと、TIDSP(IC111)B1
Code が表示されます。
7. ENTER ボタンを押すと、TIDSP(IC111)B2
Code が表示されます。
8. ENTER ボタンを押すと、HDMICPU(IC61)のバー
ジョンが表示されます。
SR5004 :AH1
V090727 1N
4. SERVICE MODE
MAIN CPU (IC105) Version, DSP (IC111) Version,
HDMI CPU (IC61), Version and Segment Check
Mode.
1. Connect the mains cord into the unit.
2. Press the POWER ON/OFF (STANDBY) button for turn
on the unit.
3. Press the AUTO, EXIT and CLEAR buttons
simultaneously more then 3 seconds.
4. The FL display shows “SERVICE MODE” for 2 seconds
then shows the model name and the software version of
the MAIN CPU (IC105) is displayed the format below.
5. Press the ENTER button again, the software serial
Number of the unit is displayed.
6. Press the ENTER button again, the TI DSP (IC111) B1
code is displayed.
7. Press the ENTER button again, the TI DSP (IC111) B2
code is displayed.
8. Press the ENTER button again, the software version of
the HDMI CPU (IC61) is displayed.
BLU-RAY : AH1
SERV I CE MODE
SR5004 :AH1
V090727 1N
SR
5
004
MZ XXXXXXXXXX
SR5004
B1 10907092
SR5004
B2 20902161
SR5004
HDM I Ve r . hXX
Year
Month Date
Destination
仕向け
Version
バージョン
