Marantz SR5009 - Surround Back Speakers

o
When 7.1-channel speakers are installed using
surround back speakers
.
z1
z2
z3
FL
SW
C
SL
SBL
FR
SR
SBR
Listening
position
z
1:22° - 30°
z
2:90° - 110°
z
3:135° - 150°
When using a single surround back speaker, place it directly behind the listening
position.
o
When 7.1-channel speakers are installed using
front height speakers
.
z1
z2
z3
FHL FHR
FL
SW
C
SL
FR
SR
z
1:22° - 30°
z
2:22° - 45°
z
3:90° - 110°
o
When 5.1-channel speakers are installed
.
z1
z2
FL
SW
C
SL
FR
SR
z
1:22° - 30°
z
2:120°
