7.1-channel (surround back)
This 7.1-channel surround system is the same as a basic 5.1-channel system but with surround back speakers.
Sound modes such as Dolby Pro Logic gx are supported.
.
FL
SW
SL
FR
SR
SBRSBL
.
FLFR C SR SL SBR SBL
SW
When using a single surround back speaker, connect it to the SURROUND BACK L
terminal.
