1.4. Error display
See the table below for descriptions of the displayed errors and countermeasures for these.
If multiple errors occur, only one item is displayed.
The priority order is
w
,
e
,
r
,
t
,
y
,
q
.
Condition States Display TROUBLE SHOOTING
q
Firm Check
Error
The model name, brand name and region information written in the rmware are compared
to the region settings in the PCB. This error is displayed if the information does not match.
" ▲ " is not displayed if rmware information is correct.
L1
FIRM
L2
ERROR
L3
L1
M:*****
–
L1
DSP
–
L2
********
L2
********
L3
BL-**.**
L3
L1
A.PLD
–
L1
V.PLD
–
L2 L2
L3
********
L3
********
L1
GUI
–
L1
PIMG
–
L2 L2
L3
**.**
L3
**.**
• Check the resistor for setting the region [R1524, 1525, DIGI-
TAL PCB].
• Write the rmware for the correct region.
PIMG Error indication
• Check the circuits around the Logic[U1053] and
SFROM[U1048]. If there appear to be no problems, [U1053]
or [U1048] is faulty.
w
IP SCALER Er-
ror
An error occurs in Loop back Test of the DDR memory which is performed during the initial
setting of i/p Scaler(ADV8003).
L1
IP
L2
SCALER
L3
ERR 01
• Check the circuits around the IP SCALER [U1026, DIGITAL
PCB] and DDR2 [U1028/1029].
If there appear to be no problems, [U1026] or [U1028/1029]
is faulty.
During the initial setting of i/p Scaler (ADV8003) , there is not the reply of the Loop back Test
result of the DDR memory .
L3
ERR 02
e
GUI Serial
Flash Error
If the MCU version is not supported by the GUI Serial Flash (ADV8003),
" ▼ " is displayed as the rst character of the GUI rmware version.
If GUI Serial Flash is damaged, " ▲ " is displayed as the rst character.
L1
GUI VER.
L2
ERROR
L3
• Check the rmware version.
r
DIR Error
This error is displayed if there is no response from the DIR.
L1
DIR
L2
ERROR
L3
01
• Check the DIR [U1040, DIGITAL PCB] and surrounding cir-
cuits.
