3-5. TUNER STEP mode (U / N only)
3-5.1. Actions
This is a special mode that enables the reception frequency STEP of the ANALOG TUNER to be changed.
3-5.2. Starting up
While holding down buttons "
ZONE2 SOURCE
" and "
STATUS
" simultaneously, press the power button
to turn on the power.
Select the "
5TUNER FREQ
" using the "
TUNER PRESET CH +/-
" button, then press the "
STATUS
"
button then to conrm.
3-5.3. Displays
Start up this unit in TUNER STEP mode, select the desired option using the "
TUNER PRESET CH +-
"
button, then enter using the "
STATUS
" button.
The following information is displayed in the following order.
(1) AM9 kHz / FM50 kHz is selected
L1
TunerFRQ
L2
AM9/
L3
FM50
"
TUNER PRESET CH +
" "
TUNER PRESET CH -
"
(2) AM10 kHz / FM200 kHz is selected
L1
TunerFRQ
L2
AM10/
L3
FM200
"
STATUS
"
(3) Press the power button to turn off the power.
(4) Press the power button to turn on the power.
