Marantz SR5400 - Electrical Parts List; Resistors; Capacitors; Fuses and Safety Notes

SR5400/K/N/U, PS5400/F
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
1 /F1N/K1G nsp 27AW154020 KNOB MASTER KNOB (GOLD) HGK1A089ZA
1 /K1S/N1S 27AW154030 27AW154030 KNOB MASTER KNOB (SILVER) HGK1A089XA
1 /N1B/U1B 27AW154010 27AW154010 KNOB MASTER KNOB (BLACK) HGK1A089YA
2 /F1N nsp 27AW248110 PANEL FRONT AL PANEL (F GOLD) CKM1A134VC24
2 /K1G nsp 27AW248110 PANEL FRONT AL PANEL (GOLD) CKM1A134ZC24
2 /K1S/N1S 27AW248210 27AW248210 PANEL FRONT AL PANEL (SILVER) CKM1A134ZC40
2 /N1B 27AW248010 27AW248010 PANEL FRONT AL PANEL (BLACK) CKM1A134ZC23
2 /U1B nsp 27AW248020 PANEL FRONT AL PANEL (U BLACK) CKM1A134YC23
3 /F1N nsp 27AW158040 WINDOW FIP WINDOW CGU1A306X
3 /K1G/N1B
/U1B
27AW158010 27AW158010 WINDOW FIP WINDOW CGU1A306Z
3 /K1S/N1S 27AW158210 27AW158210 WINDOW FIP WINDOW CGU1A306Y
4 /F1N/K1G nsp 27AW105120CHASSIS FRONT MOLD CHASSIS (GOLD) CGW1A358RFZD4
4 /K1S/N1S 27AW105220 27AW105220 CHASSIS FRONT MOLD CHASSIS (SILVER) CGW1A358R6ZG13
4 /N1B/U1B 27AW105020 27AW105020 CHASSIS FRONT MOLD CHASSIS (BLACK) CGW1A358ZK92
5 /F1N/K1G nsp 27AW270110 BUTTON FUNCTION BUTTON (GOLD) CBT1A876RFD4
5 /K1S/N1S 27AW270210 27AW270210 BUTTON FUNCTION BUTTON (SILVER) CBT1A876R6G13
5 /N1B/U1B 27AW270010 27AW270010 BUTTON FUNCTION BUTTON (BLACK) CBT1A876K92
6 nsp nsp CUSHION FOR LEG (RUBBER) KHG1A050
7 /F1N/K1G
/N1B/U1B
243W057010 243W057010 LEG FOOT CKL2A042H11
7 /K1S/N1S 243W057210 243W057210 LEG FOOT CKL2A042H46
8 /F nsp nsp PCB ASSY FRONT PCB ASSY PS5400/F1 COP11590E
8 /K nsp nsp PCB ASSY FRONT PCB ASSY SR5400/K1 COP11590D
8 /N nsp nsp PCB ASSY FRONT PCB ASSY SR5400/N1 COP11590B
8 /U nsp nsp PCB ASSY FRONT PCB ASSY SR5400/U1 COP11590C
9 /F nsp *TS001980R TRANSF. MAINS POWER PS5400/F1 CLT5W008ZJ
9 /K nsp *TS001990R TRANSF. MAINS POWER SR5400/K1 CLT5W008ZH
9 /N *TS002000R *TS002000R TRANSF. MAINS POWER SR5400/N1 CLT5W008ZE
9 /U nsp *TS002010R TRANSF. MAINS POWER SR5400/U1 CLT5W008ZU
10 /F1N/K1G
/N1B/U1B
24AW251010 24AW251010 BADGE NEW MZ BADGE CGB1A117
10 /K1S/N1S 24AW251020 24AW251020 BADGE NEW MZ BADGE SILVER CGB1A117G
11 27AW355010 27AW355010 LENS STANDBY LENS CGL1A216
13 /F1N/K1G nsp 27AW270140 BUTTON POWER SW BUTTON (GOLD) CBC1A146RFD4
13 /K1S/N1S 27AW270240 27AW270240 BUTTON POWER SW BUTTON (SILVER) CBC1A146R6G13
13 /N1B 27AW270040 27AW270040 BUTTON POWER SW BUTTON (BLACK) CBC1A146K92
14 /F/K/N nsp nsp BRACKET POWER SW BRACKET CMD1A493
17 /U1B nsp 27AW270030 BUTTON POWER SW BUTTON TACT (BLACK) CBT1A877K92
18 nsp nsp HOLDER FL DISPLAY HOLDER CMD1A374
19 nsp nsp HOLDER PCB HOLDER CHE1A030
20 nsp nsp CHASSIS MAIN CHASSIS CUA1A230
21 nsp nsp HEATSINK MAIN HEAT SINK CMY1A208
22 /F nsp nsp PCB ASSY INPUT PCB ASSY PS5400/F1 COP11592E
22 /K nsp nsp PCB ASSY INPUT PCB ASSY SR5400/K1 COP11592D
22 /N nsp nsp PCB ASSY INPUT PCB ASSY SR5400/N1 COP11592B
22 /U nsp nsp PCB ASSY INPUT PCB ASSY SR5400/U1 COP11592C
23 nsp nsp BRACKET BRACKET FOR PCB 1F-3F CMD1A492
25 /F nsp nsp PCB ASSY DSP PCB ASSY PS5400/F1 COP11593E
25 /K nsp nsp PCB ASSY DSP PCB ASSY SR5400/K1 COP11593D
25 /N nsp nsp PCB ASSY DSP PCB ASSY SR5400/N1 COP11593B
25 /U nsp nsp PCB ASSY DSP PCB ASSY SR5400/U1 COP11593C
26 nsp nsp PCB ASSY COMPONENT PCB ASSY SR5400 COP11595B
27 /K nsp *AV000330R TUNER KST-MB014MA1-8A (CHINA) CNVKSTMB014MA1A
27 /N *AV000340R *AV000340R TUNER KST-MB114LA1-8 (EUR) CNVKSTMB114LA18
27 /U nsp *AV000350R TUNER KST-MB014MA0-8 (USA) CNVKSTMB014MA08
28 /F1N nsp nsp PANEL REAR PANEL (F GL) CKF4A257Z
28 /K1G nsp nsp PANEL REAR PANEL (K GL) CKF3A257Z
28 /K1S nsp nsp PANEL REAR PANEL (K SILVER) CKF3A257Y
28 /N1B nsp nsp PANEL REAR PANEL (N BL) CKF1A257Z
28 /N1S nsp nsp PANEL REAR PANEL (N SILVER) CKF1A257X
28 /U1B nsp nsp PANEL REAR PANEL (U BL) CKF2A257Z
29 nsp nsp PCB ASSY AMP PCB ASSY SR5400 COP11591D
31 nsp nsp BRACKET BRACKET FOR POWER AMP PCB CMD1A490
32 nsp nsp BRACKET BRACKET FOR HEATSINK TOP CMD1A491K92
34 /F nsp nsp PCB ASSY POWER PCB ASSY PS5400/F1 COP11594E
34 /K nsp nsp PCB ASSY POWER PCB ASSY SR5400/K1 COP11594D
34 /N nsp nsp PCB ASSY POWER PCB ASSY SR5400/N1 COP11594B
57
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
