Surround Mode Input Signal Decoding
Output Channel Front information display
L/R C
SL
SR
SBL
SBR
SubW Signal format indicators Channel status
Dolby Virtual
Speaker
Dolby Surr.EX Dolby Virtual Speaker
O ----
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Virtual Speaker
O ----
2 DIGITAL
L, C, R, SL, SR, LFE
Dolby D (2ch) Dolby Virtual Speaker
O ----
2 DIGITAL
L, R
Dolby D (2ch Surr) Dolby Virtual Speaker
O ----
2 DIGITAL 2 SURROUND
L, R, S
DTS-ES Dolby Virtual Speaker O - - - - dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 Dolby Virtual Speaker
O - - - - dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) Dolby Virtual Speaker
O - - - - dts L, C, R, SL, SR, LFE
Multi Ch-PCM Dolby Virtual Speaker
O - - - - PCM L, C, R, SL, SR, LFE
DSD (5.1ch) Dolby Virtual Speaker
O - - - - DSD L, C, R, SL, SR, LFE
DSD (2ch) Dolby Virtual Speaker O ----DSD L, R
PCM (Audio) Dolby Virtual Speaker O ----PCM L, R
HDCD Dolby Virtual Speaker O - - - - PCM, HDCD L, R
Analog Dolby Virtual Speaker
O ----ANALOG -
Multi Ch.
Movie
Music
Dolby Surr.EX Dolby Digital EX
OOOOO
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1 OOO - O
2 DIGITAL
L, C, R, SL, SR, LFE
Dolby D (2ch) Multi Channel OOOOO
2 DIGITAL
L, R
Dolby D (2ch Surr) Multi Channel OOOOO
2 DIGITAL 2 SURROUND
L, R, S
DTS-ES DTS-ES
OOOOO dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS-96/24 OOO - O dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) DTS 5.1 OOO - O dts L, C, R, SL, SR, LFE
Multi Ch-PCM Multi Ch-PCM OOO - O PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 96kHz Multi Ch-PCM 96kHz OOO - O PCM L, C, R, SL, SR, LFE
DSD (5.1ch) Multi Ch-PCM
OOO - O DSD L, C, R, SL, SR, LFE
DSD (2ch) Multi Channel OOOOO DSD L, R
PCM (Audio) Multi Channel OOOOO PCM L, R
HDCD Multi Channel OOOOO PCM, HDCD L, R
Analog Multi Channel
OOOOO ANALOG -
Dolby H.P Dolby Surr.EX Dolby H.P O ----
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby H.P O ----
2 DIGITAL
L, C, R, SL, SR, LFE
Dolby D (2ch) Dolby H.P O ----
2 DIGITAL
L, R
Dolby D (2ch Surr) Dolby H.P O ----
2 DIGITAL 2 SURROUND
L, R, S
DTS-ES Dolby H.P O - - - - dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 Dolby H.P
O - - - - dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) Dolby H.P O - - - - dts L, C, R, SL, SR, LFE
Multi Ch-PCM Dolby H.P O - - - - PCM L, C, R, SL, SR, LFE
DSD (5.1ch) Dolby H.P O - - - - DSD L, C, R, SL, SR, LFE
DSD (2ch) Dolby H.P
O ----DSD L, R
PCM (Audio) Dolby H.P O ----PCM L, R
HDCD Dolby H.P O - - - - PCM, HDCD L, R
Analog Dolby H.P O ----ANALOG -
Notes:
• Dolby Digital (2 channel L/R): Speakers for signal
with Dolby Surround are fully equipped.
• No sound is outputs from the surround speaker,
center speaker and subwoofer if the DVD disc has
no surround data.
Abbreviations
L/R : Front speakers
C : Center speaker
SL/SR : Surround speakers
SBL/SBR : Surround back speakers
SubW : Subwoofer
