Marantz SR6010 - Page 26

Paths to be conrmed Display Settings What to conrm
5
Analog A/D
(MAIN ZONE)
L1
A 0 6 A D
L2
* * * . * d B
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : MULTI CH STEREO
Amp assign : 7.1ch
Floor Layout : 5ch&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Speaker Select : Floor
Speaker Cong ALL Speaker = Small/SW = Yes(2ch)
MAIN ZONE : ON
ZONE2 : OFF
・Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・Analog input ⇒ Preout output, SW(20Hz) (Front L/R, Center, Surround L/R, Surround Back L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
6
Analog Amp Assign
(Amp Assign：ZONE2)
L1
A 0 7 Z 2 A S S
L2
* * * . * d B
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z2 Source : Source
Amp assign : 5.1ch + ZONE2
MAIN ZONE : ON
ZONE2 : ON
・Analog input ⇒ Speaker input (Surround Back L/R → ZONE2 L/R)
・Analog input ⇒ Preout input (ZONE2 L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
7
Amp Assign
(Bi-Amp)
L1
A 1 1 B i A M P
L2
* * * . * d B
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 5.1ch + Bi-Amp
MAIN ZONE : ON
ZONE2 : OFF
・Analog input ⇒ Speaker output (Surround Back L/R → Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
8
Front Height
L1
A 1 4 F H
L2
* * * . * d B
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 7.1ch
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Speaker Select : Floor & Height
MAIN ZONE : ON
ZONE2 : OFF
・Analog input ⇒ Speaker output (Height1 L/R → Front Height)
・Analog input ⇒ Preout output (Height1 L/R → Front Height)
(
b
The input source can be switched to any source except CBL/SAT.)
・PREOUT output
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
9
Front Wide
L1
A 1 5 F W
L2
* * * . * d B
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 7.1ch
Floor Layout : 5ch&FW
Height Sp : None
Dolby Sp : None
Speaker Select : Front
MAIN ZONE : ON
ZONE2 : OFF
・Analog input ⇒ Speaker output (Front Wide L/R)
・Analog input ⇒ Preout output (Front Wide L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
・PREOUT output
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
10
Ext.In
L1
A 1 9 7 . 1 I N
L2
* * * . * d B
Input Source : CBL/SAT
Input Mode : 7.1ch IN
SURROUND mode : 7.1ch In
Amp assign : 7.1ch
Floor Layout : 5ch&SB
Height Sp : None
Dolby Sp : None
MAIN ZONE : ON
ZONE2 : OFF
・7.1ch input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・7.1ch input ⇒ Pre output (Front L/R, Center, Surround L/R, Surround Back L/R, Subwoofer)
11
Front Amp>>Front Wide
L1
A 2 1 F W 2
L2
* * * . * d B
Input Source : CBL/SAT
Input Mode : Auto
SURROUND mode : Multi ch STEREO
Amp assign : 9.1ch
Floor Layout : 5ch&SB&FW
Height Sp : None
Dolby Sp : None
Pre-out Channel : Front
Speaker Select : Floor
MAIN ZONE : ON
ZONE2 : OFF
・Analog input ⇒ Speaker output (Front Wide L/R)
・Analog input ⇒ Preout output (Front Wide L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
g.05a
g.05b
g.06
g.07a
g.07b
g.08a
g.08b
g.09a
g.09b
g.10
g.11a
g.11b
26
