Paths to be conrmed Display Settings What to conrm
12
Front Amp>>Surround Back
L1
A 2 2 S B 2
L2
* * * . * d B
Input Source : CBL/SAT
Input Mode : Auto
SURROUND mode : Multi ch STEREO
Amp assign : 9.1ch
Floor laytou : 5ch&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Pre-out Channel : Front
Speaker Select : Floor & Height
MAIN ZONE : ON
ZONE2 : OFF
・Analog input ⇒ Speaker output (Surround Back L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
13
Height
L1
A 2 4 H E I G
L2
* * * . * d B
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 9.1ch
Floor Layout : 5ch
Height Sp : 4ch
Dolby Sp : None
Height Layout : Top Front & Top Rear
Pre-out Channel : Top Rear
Speaker Select : Floor & Height
MAIN ZONE : ON
ZONE2 : OFF
・Analog input ⇒ Preout output (Height1 L/R → Top Front) (Height2 → Top Rear)
(
b
The input source can be switched to any source except CBL/SAT.)
・PREOUT output
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
