2-1.6. Conrmation items for the video system
See the block diagram g.XXth.
Paths to be conrmed Display Settings What to conrm
1
Analog Video
L1
V 0 1 V I D E O
L2
* * * . * d B
Input Source : CBL/SAT
Video Convert (IP Scaler) : OFF, All sources
MAIN ZONE : ON
ZONE2 : ON
・Component input ⇒ Component output
・CVBS input ⇒ CVBS output
(
b
The input source can be switched to any source except CBL/SAT.)
2
Video Convert
(Analog or HDMI ⇒ HDMI)
L1
V 0 2 C O N V
L2
* * * . * d B
Input Source : CBL/SAT
Video Convert (IP Scaler) : ON, All sources
IP Scaler : "Analog & HDMI", All sources
Resolution : "Auto", All sources
MAIN ZONE : ON
ZONE2 : OFF
・CVBS input ⇒ IP Scaler ⇒ HDMI output.
・Component input ⇒ IP Scaler ⇒ HDMI output.
・HDMI input ⇒ IP Scaler ⇒ HDMI output.
・ETHERNET input ⇒ IP Scaler ⇒ HDMI output.
(
b
The input source can be switched to any source except CBL/SAT.)
3
HDMI pass
(MAIN ZONE)
L1
V 0 3 H D M I
L2
* * * . * d B
Input Source : CBL/SAT
Video Convert (IP Scaler): OFF MAIN ZONE : ON, All sources
ZONE2 : OFF
・HDMI input ⇒ HDMI output(MAIN)
(
b
The input source can be switched to any source except CBL/SAT.)
4
HDMI CEC
L1
V 0 4 C E O
L2
* * * . * d B
Input Source : CBL/SAT
HDMI Control : ON
MAIN ZONE : ON
ZONE2 : OFF
・ When the power supply of a TV is put in the standby mode, make sure that the power supply of this unit is also put in the
standby mode.
・The ARC path can also be checked (check this using the TV input source).
(
b
The input source can be switched to any source except CBL/SAT.)
5
HDMI Audio
(Audio :AVR)
L1
V 0 5 H - A V R
L2
* * * . * d B
Input Source : CBL/SAT
HDMI Control : OFF
HDMI Audio : AVR (if checking the audio output from AVR)
・HDMI input (PCM, DolbyDigital, DTS) ⇒ Speaker output.
・HDMI input(HD audio) ⇒ Speaker output.
(
b
The input source can be switched to any source except CBL/SAT.)
6
HDMI Audio
(Audio :TV)
L1
V 0 6 H - T V
L2
* * * . * d B
Input Source : CBL/SAT
HDMI Control : OFF
HDMI Audio : AVR (if checking the audio output from AVR)
・HDMI input(PCM, DolbyDigital, DTS) ⇒ HDMI output (audio output from connected TV)
(
b
The input source can be switched to any source except CBL/SAT.)
7
GUI
L1
V 0 7 M E N U
L2
* * * . * d B
Input Source : CBL/SAT
Video Convert (IP Scaler) : ON, All sources
IP Scaler : "Analog & HDMI", All sources
Resolution : "AUTO", All sources
Setup Menu : ON
MAIN ZONE : ON
ZONE2 : OFF
・GUI display ⇒ HDMI output.
(
b
The input source can be switched to any source except CBL/SAT.)
8
HDMI
(ZONE2)
L1
V 0 8 Z 2 H D
L2
* * * . * d B
Input Source : CBL/SAT
ZONE2 Source : Source
MAIN ZONE : ON
ZONE2 : ON
・HDMI input ⇒ HDMI output (ZONE2)
(
b
The input source can be switched to any source except CBL/SAT.)
g.14
g.15a
g.15b
g.16
g.17
g.18a
g.18b
g.18c
g.19a
g.19b
g.20
g.21
28
