Marantz SR6011 - Page 147

Paths to be conrmed Display Settings What to conrm
3
DIGITAL
(ZONE2)
g.03a
g.03b
g.03c
A03Z2DIG
***.*dB
Input Source : Online Music
Input Mode : Auto
Sound mode : STEREO
Amp assign : 7.1ch + ZONE2
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : On
ZONE2 : On
・ Digital(PCM) input ⇒ Speaker output (Height2 (ZONE2) L/R)
・ Digital(PCM) input ⇒ Pre OUT output (ZONE2 L/R)
(
b
The input source can be switched to any source except Online Music.)
4 HDMI
g.04a
g.04b
g.04c
A05HDMI
***.*dB
Input Source : CBL/SAT
Input Mode : HDMI (xed)
Sound mode : STEREO
Amp assign : 9.1ch
Floor Layout : 5ch&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : On
ZONE2 : Off
・ HDMI input ⇒ Speaker output (Front L/R)
・ HDMI input ⇒ Pre OUT output (Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
5
Analog AD
(MAIN ZONE)
g.05a
g.05b
A06AD
***.*dB
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : MULTI CH STEREO
Amp assign : 9.1ch
Floor Layout : 5ch&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Speaker Select : Floor & Height
Speaker Cong ALL Speaker = Small/SW = Yes(2ch)
MAIN ZONE : On
ZONE2 : Off
・ Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, S.Back L/R, Height1 L/R)
・ Analog input ⇒ Speaker output, SW(20Hz) (Front L/R, Center, Surround L/R, S.Back L/R,
Height1 L/R, Subwoofer1/2)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
6
Analog Amp Assign
(Amp Assign :
ZONE2)
g.06
A07Z2ASS
***.*dB
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z2 Source : Source
Amp assign : 7.1ch + ZONE2
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : On
ZONE2 : On
・ Analog input ⇒ Speaker output (Height2 (ZONE2) L/R)
・ Analog input ⇒ Pre OUT output (ZONE2 L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
7
Amp Assign
(Amp Assign :
BiAMP)
g.07a
g.07b
A11BiAMP
***.*dB
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 7.1ch + BiAMP
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : On
ZONE2 : Off
・Analog input ⇒ Speaker output (Height1 L/R (Top Front))
・Analog input ⇒ Speaker output (Height2 L/R (Top Front))
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
147
