Marantz SR6011 - Diagnostic Mode

DIAGNOSTIC MODE
Service Path Check Mode
1.1. Actions
This function is convenient for conrming problem paths in the product and checking the paths after repairing.
The Video and Audio paths can be checked.
The backup data is not rewritten.
1.2. Starting up
While holding down buttons "
ZONE2 SOURCE
" and "
STATUS
" simultaneously, press the power button to turn on the power.
Select the "
1. SERVICE CHECK
" using the "
TUNER PRESET CH+
" button, then press the "
STATUS
" button then to conrm.
The "
TUNED
", "
STEREO
" and "
RDS
" segments are lit in this mode.
1.3. Canceling diagnostic mode
Press the power button to turn off the power.
1.4. Selecting items to check
Press the
q
button to switch between video items and audio items.
Press the
w
or
e
button to select the previous or next item.
The unit Remote control unit
Actions
q w e q w e
Audio ⇔ Video PREVIOUS NEXT Audio ⇔ Video PREVIOUS NEXT
Button DIMMER TUNER PRESET CH- TUNER PRESET CH+ SLEEP CURSOR
0
CURSOR
1
1.5. Audio system conrmation items
See the block diagram g.XXth.
Paths to be conrmed Display Settings What to conrm
1 Analog g.01
A01ANLG
***.*dB
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : DIRECT
Amp assign : 9.1ch
Floor Layout : 5.1&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : On
ZONE2 : Off
・ Analog input ⇒ Speaker output (Front L/R)
・ Analog input ⇒ Pre OUT output (Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
2
DIGITAL
(MAIN)
g.02a
g.02b
A2DIG.
***.*dB
Input Source : CBL/SAT
Input Mode : DIGITAL (xed)
Sound mode : MULTI CH STEREO
Amp assign : 9.1ch
Floor Layout : 5.1&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Speaker Select : Floor
Speaker Cong ALL Speaker = Small / SW = Yes(2ch)
MAIN ZONE : On
ZONE2 : Off
・ Digital input ⇒ Speaker output (Front L/R, Center, Surround L/R, S.Back L/R)
・ Digital input ⇒ Pre output (Front L/R, Center, Surround L/R, S.Back L/R, Subwoofer1/2)
(
b
The input source can be switched to any source except CBL/SAT.)
