DISASSEMBLY
Flowchart
• Remove each part following the ow below.
• Reassemble the removed parts in the reverse order.
• Read "SAFETY PRECAUTIONS" before reassembling the removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the work. Failure to shape the wires correctly may cause problems such as noise.
• See "EXPLODED VIEW"
FRONT ASSY
DISASSEMBLY
1. FRONT ASSY
and "EXPLODED VIEW"
FRONT PCB
Ref. No. of EXPLODED VIEW : C 1
F_HDMI PCB
Ref. No. of EXPLODED VIEW : C 5
HDMI FFC TOP PCB
Ref. No. of EXPLODED VIEW : C 4
TOP COVER
TRANS
DISASSEMBLY
10. TRANS
and "EXPLODED VIEW"
POWER TRANS
Ref. No. of EXPLODED VIEW : C 15
RADIATOR ASSY
DISASSEMBLY
2. RADIATOR ASSY
and "EXPLODED VIEW"
5CH AMP PCB
Ref. No. of EXPLODED VIEW : C 13
4CH AMP PCB
Ref. No. of EXPLODED VIEW : C 7
GUIDE TOP PCB
Ref. No. of EXPLODED VIEW : C 9
FRONT CONT FFC PCB
Ref. No. of EXPLODED VIEW : C 10
GUIDE TRANS PCB
Ref. No. of EXPLODED VIEW : C 11
GUIDE SIDE PCB
Ref. No. of EXPLODED VIEW : C 12
DIGITAL PCB
DISASSEMBLY
4. DIGITAL PCB
and "EXPLODED VIEW"
DIGITAL PCB
Ref. No. of EXPLODED VIEW : C 46
GUIDE PCB
Ref. No. of EXPLODED VIEW : C 48
CY920 MODULE
Ref. No. of EXPLODED VIEW : C 47
REAR PANEL
DISASSEMBLY
3. REAR PANEL
and "EXPLODED VIEW"
REAR PANEL
Ref. No. of EXPLODED VIEW : M 23
VIDEO PCB
DISASSEMBLY
5. VIDEO PCB
and "EXPLODED VIEW"
VIDEO PCB
Ref. No. of EXPLODED VIEW : C 45
INPUT PCB
DISASSEMBLY
6. INPUT PCB
and "EXPLODED VIEW"
INPUT PCB
Ref. No. of EXPLODED VIEW : C 37
HDAM PCB
Ref. No. of EXPLODED VIEW : C 41
CONNECT-2 PCB
Ref. No. of EXPLODED VIEW : C 42
CONNECT-3 PCB
Ref. No. of EXPLODED VIEW : C 43
CONNECT-4 PCB
Ref. No. of EXPLODED VIEW : C 44
TUNER PCB
DISASSEMBLY
7. TUNER PCB
and "EXPLODED VIEW"
TUNER PCB
Ref. No. of EXPLODED VIEW : C 40
SPK PCB
DISASSEMBLY
8. SPK PCB
and "EXPLODED VIEW"
SPK PCB
Ref. No. of EXPLODED VIEW : C 28
SPK H2L PCB
Ref. No. of EXPLODED VIEW : C 36
FRONT CNT PCB
Ref. No. of EXPLODED VIEW : C 26
BKT PCB
Ref. No. of EXPLODED VIEW : C 25
SIDE CNT PCB
Ref. No. of EXPLODED VIEW : C 27
SMPS PCB
DISASSEMBLY
9. SMPS PCB
and "EXPLODED VIEW"
SMPS PCB
Ref. No. of EXPLODED VIEW : C 17
