SR8002/SR7002 RS-232C Control Specification Page: 10 / 32
Document Version [1.00]
Company Restricted
Command Reply from Slave
AUX2 “SRC:A”
CD/CD-R “SRC:C”
TAPE “SRC:E”
TUNER1 “SRC:F”
FM1 “SRC:G”
AM1 “SRC:H”
XM1 “SRC:J”
TOGGLE “71C:0”
OFF “71C:1”
7.1 Channel Input
ON “71C:2”
“71C:1”,(OFF)
“71C:2”(ON)
SPKR SEL “SPK:0”
SPKR-A OFF “SPK:1”
SPKR-A ON “SPK:2”
SPKR-B OFF “SPK:3”
SPEAKER Select
SPKR-B ON “SPK:4”
“SPK:ab”, a=SPK-A,b=SPK-B
“SPK:11”(A-OFF,B-OFF),
“SPK:21”(A-ON,B-OFF),
“SPK:12”(A-OFF,B-ON),
“SPK:22”(A-ON,B-ON),
TOGGLE “HDM:0”
HDMI OUT CH1 “HDM:1”
HDMI OUT CH Select
HDMI OUT CH2 “HDM:2”
“HDM:1”(CH1),
“HDM:2”(CH2)
ENABLE “HAM:1”
HDMI AUDIO MODE
THROIUGH “HAM:2”
“HAM:1”(ENABLE),
“HAM:2”(THROUGH)
DISABLE “IPC:1”
IP CONVERTER
ENABLE “IPC:2”
“IPC:1”(DISABLE),
“IPC:2”(ENABLE)
MAIN
“CM2:1”
This command is available
for SR8002 only.
COMPONENT2
SELECT
MULTI
“CM2:2”
This command is available
for SR8002 only.
“CM2:1”(MAIN),
“CM2:2”(MULTI)
VALUE “SLP:0xxx” (xx=”000”~”120”)
SLEEP
OFF “SLP:1”
“SLP:010~120” ( ON ),
“SLP:000” (OFF)
TOGGLE “MNU:0” (work same as RC)
OFF “MNU:1”
ON “MNU:2”
MENU
ENTER “MNU:3”
“MNU:1”, (Not on Menu)
“MNU:2” (On Menu )
UP “CUR:1”
DOWN “CUR:2”
LEFT “CUR:3”
CURSOR
RIGHT “CUR:4”
ACK
TRG. 1 OFF “DCT:11” (DC TRG. 1 OFF)
TRG. 1 ON “DCT:12” (DC TRG. 1 ON)
TRG. 2 OFF “DCT:21” (DC TRG.2 OFF )
DC TRG.
TRG. 2 ON “DCT:22” (DC TRG.2 ON )
“DCT:ab”
( a,b, = 1:OFF, 2:ON),
a = TRG.1, b = TRG.2,
eg.) “DCT:11” (all OFF),
“DCT:21” (TRG.1 ON),
“DCT:12” (TRG.2 ON)
“DCT:22” (all ON)
OFF “FKL:1”
FRONT KEY LOCK
ON “FKL:2”
“FKL:1” ( OFF ),
FKL:2” (ON)
