SR8002/SR7002 RS-232C Control Specification Page: 23 / 32
Document Version [1.00]
Company Restricted
Status request Status answer and feedback
Digital Signal Format “SIG:?”
x =
‘0’ :No detect
’1’ :D DIGITAL AC-3
‘2’ : D DIGITAL AC-3 PL
‘3’ : D DIGITAL SURR. EX
‘4’ : DTS
‘5’ : DTS ES DISCREATE
‘6’ : DTS ES MATRIX
‘7’ : AAC
‘8’ : MPEG
‘9’ : M-PCM
‘A’ : PCM
‘B’ : HDCD
‘C’ : DSD
‘D’ : DTS 96/24
‘E’ : reserved
‘F’ : OTHER
‘G’ : DD PLUS
‘H’ : DD THROU HD
‘I’ : DTS HD MSTR
‘J’ : DTS HD HI RES
‘K’ : DTS HD EXPRESS
“SIG:x”
x = signal
Sampling Frequency “SFQ:?”
x =
‘0’ : Out of range
‘1’ : 32kHz
‘2’ : 44.1kHz
‘3’ : 48kHz
‘4’ : 88.2kHz
‘5’ : 96kHz
‘6’ : 176.4kHz
‘7’ : 192kHz
‘F’ : Input isn’t Digital (=Analog)
“SFQ:x”
x = Freq.
Channel Status “CHS:?”
xy = “00”: Not available
‘x’ = ‘8’ ~ ‘F’
bit3 : 1
Bit2 : LFE
bit1 : Surr. L
bit0 : Surr. R
‘y’ = ‘0’ ~ ‘F’
bit3 : Surr Back
bit2 : Front L
bit1 : Front R
bit0 : Center
“CHS:xy”
xy = Ch.Stat
