52
ENGLISH DEUTSCH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS SVENSKA
For speaker impedance and speaker cable connections, see page 5.
6.1-channel (Surround back speaker) connection
If using only one surround back speaker (with a 6.1-channel connection), connect to the “L” side of the
SURR. BACK/AMP ASSIGN terminal.
For speaker settings in this case, see “When 6.1ch (Surround back speaker) installed” (vpage50).
For 6.1-channel (Surround back speaker) playback, set “Set up “Amp Assign”” (vpage54) to “Normal”.
FL FR
C
SB
SL
SR
SW
Connect
5.1-channel connection
For 5.1-channel playback, set “Set up “Amp Assign”” (vpage54) to “Normal”.
FL FR
C
SL
SR
SW
