Upgrade (Auro-3D)

z1 30° - 45°

GViewed from the sideH

Front speaker

Surround

speaker

Point slightly

downwards

Front height

speaker

Top surround speaker

Surround

height speaker

SHRSHL

FHL

FHR

Height speakers layout

GViewed from the topH
