7.1-channel playback

Example connections when using surround back speakers

This 7.1-channel surround system is the same as a basic 5.1-channel system but with surround back speakers.

SBL SBR

Set “Floor” - “Layout” to “5ch & SB” in the menu when connecting in this

configuration. (v

p. 253)

FR FL C SR SL

SBR SBL

When using a single surround back speaker, connect it to the SURROUND BACK

L terminal.
