9.1-channel playback

This system, which is based on a 5.1-channel system, plays back up to 9.1-channels at the same time.

You can connect speakers for up to 11-channels for MAIN ZONE. When you connect speakers for 10 or more channels, the output speakers

automatically switch according to the input signal and sound mode.

Example connection when using surround back and front wide speakers

FWL FWR

SBL SBR

FR FL C SR SL

SBR SBL FWR FWL

Set “Floor” - “Layout” to “5ch & SB & FW” in the menu when connecting in this configuration. (v p. 253)
