Marantz SR7010 - Page 70

n
Example connection when using two sets of Dolby Atmos Enabled speakers
.
C
SBL
SBR
SW
FWL
FWR
SL SR
FL
FR
FDL FDR
SDL SDR
0
Set “Height” - “Dolby Sp” to “4ch” in the menu when connecting in this
configuration. (v
p. 253)
.
SW
FR FL C SR SL
SBR SBL FWR FWL
SDR SDL
HEIGHT 2
z
FDR FDL
HEIGHT 1
z
Power amplifier
z
You can change the combination of the HEIGHT1 and HEIGHT2 channels in the
settings. (v
p. 72)
